- Page 1 Xvent 405-OM-UK-001 v1.0 – 09 Jul 2020 www.glazingvision.co.uk +44 (0)1379 658300 info@glazingvision.co.uk...
-
Page 2: Table Of Contents
405-OM-UK-001 v1.0 – 09 Jul 2020 Contents Section Description Page Introduction Safety Information Basic Operation Controls and Operation Manual Override Troubleshooting Glass Specification and Breakage Instructions Routine Testing and Maintenance Disposal at End of Life Security and Certification Serial Number Warranty Information Maintenance Log Need assistance? +44 (0)1379 658300 info@glazingvision.co.uk... -
Page 3: Introduction
Introduction Thank you for purchasing a Glazing Vision Xvent. We hope that it gives you many years of service. The Xvent is an opening rooflight designed to vent smoke as an Automatically Opening Vent (AOV) and to provide day-to-day ventilation. The lid opens to an angle of 45°... -
Page 4: Safety Information
Regular cleaning and maintenance must be carried out according to the guidelines described in this manual. • Glazing Vision strongly recommends that any work is carried out by suitably qualified individuals (e.g. Glazing Vision trained personnel or contractors, or an experienced electro-mechanical service engineer). - Page 5 Should any cables or electrical components break or become damaged, have them repaired or replaced immediately. Deteriorated insulation of electrical parts or overloading may cause an electric shock or fire. For more information or assistance please contact Glazing Vision. Need assistance? +44 (0)1379 658300 info@glazingvision.co.uk...
-
Page 6: Basic Operation
45º under the control of the wall mount control switch. The Xvent is fitted with an ambient air temperature sensor as standard which is part of the bezel assembly fitted to the inside edge of the product. This sensor serves as a backup to the fire alarm system. If the sensor detects ambient air temperature of 72ºC (162°F) or more it will trigger fire behaviour. -
Page 7: Controls And Operation
405-OM-UK-001 v1.0 – 09 Jul 2020 Controls and Operation Various options are available at time of order. If specific data is required for your product, please refer to your order confirmation or contact your supplier for assistance. Control Switch The standard operation of the unit is via the supplied wall mounted control switch and can be operated using two different methods as explained below: Status light Figure 1 –... - Page 8 Building Management System Integration (Optional) The product can be connected to building management systems. Please contact Glazing Vision for further details if required. Need assistance? +44 (0)1379 658300 info@glazingvision.co.uk...
-
Page 9: Manual Override
Stuck Open If the Xvent is stuck in the open position and will not close electrically, the mechanisms can be removed to allow the lid to be closed manually. Manual override needs to be done externally, so access to the rooftop will be required (ensure that all necessary safety precautions are followed). - Page 10 Two support legs (stocked by Glazing Vision) should be fitted to hold the lid in position allowing the Xvent to be safely worked on. Support legs must be fitted on both sides of the lid to ensure that there is adequate support, and it is critical that the height adjustment and clamp bolts are sufficiently tightened to prevent the legs from slipping (when working take care not to knock the support legs out of place).
- Page 11 Stuck Closed If the Xvent is stuck in the closed position and will not open electrically, the mechanisms can be disconnected to allow the lid to be opened manually. As the building will be watertight, manually overriding the Xvent from the closed position is best done when an engineer is on hand to resolve the issue.
-
Page 12: Troubleshooting
Troubleshooting The Xvent control board monitors the operation of the product. If a fault is detected, the control board will disable the unit to prevent possible damage. Fault and standard conditions are indicated by the status light on the control switch. The following table shows the various status light displays and their meanings. -
Page 13: Glass Specification And Breakage Instructions
Due to the safety critical nature of this product, a Glazing Vision engineer must attend to re-initialise the Xvent if all attempts to reset the product fail. Glass Specification and Breakage Instructions Glass Specification Various options are available at time of order. -
Page 14: Routine Testing And Maintenance
Xvent manually using the wall mounted control switch. In this way it is possible to walk to each Xvent in the building, confirm that it has opened to the fire open position, and then check that the Xvent closes with no faults present (i.e. -
Page 15: Disposal At End Of Life
Disposal at End of Life Glazing Vision design products with ease of recyclability at end of life in mind. Many of the main components used are widely recyclable and we encourage you to recycle the unit and/or dispose of the component parts responsibly, in accordance with the guidance from your local authority. -
Page 16: Security And Certification
Security and Certification The Xvent is designed with security as a priority. The mechanisms cannot be back driven. It is tested to LPS2081 Issue 1:2015. It is approved by the Loss Prevention Certification Board (Cert/LPCB ref: 1347a) and Secured by Design:... -
Page 17: Maintenance Log
405-OM-UK-001 v1.0 – 09 Jul 2020 Maintenance Log Project Address: …………………………………………………………………………………………………………………………………. Unit Serial Number: ……………………………………………………………………………………………………………………………... Work Completed Notes Name Date Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no... - Page 18 405-OM-UK-001 v1.0 – 09 Jul 2020 Work Completed Notes Name Date Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no Battery Replacement yes/no Cleaning Requirements yes/no Annual Requirements yes/no...
