- Page 1 Xvent 405-INST-UK-001 v1.0 – 09 Jul 2020 www.glazingvision.co.uk +44 (0)1379 658300 info@glazingvision.co.uk...
-
Page 2: Table Of Contents
405-INST-UK-001 v1.0 – 09 Jul 2020 Contents Section Description Page Introduction Safety Information Pre-Installation Preparation Upstand Top Trim Installation Fitting the Lifting Equipment Installation Procedure Interior Finishing Need assistance? +44 (0)1379 658300 info@glazingvision.co.uk Page 2 of 13... -
Page 3: Introduction
Introduction Thank you for purchasing a Glazing Vision Xvent. In order to ensure that it gives you many years of service it is important that before commencing any work you read these instructions fully and ensure that they are strictly followed for a successful and trouble free installation. -
Page 4: Safety Information
These products can be very heavy. Extreme care must be taken during handling and installation. Full consideration should be given to how you will safely transport your rooflight product from the delivery vehicle to the installation location. Glazing Vision strongly recommends that specialist, mechanical lifting equipment is employed. - Page 5 The following warnings are here to prevent personal injury and damage to the product. Please follow them explicitly. General: • The product must be properly installed and commissioned in accordance with this manual before it is used. The Xvent must be commissioned by Glazing Vision personnel or Approved Installers. •...
-
Page 6: Pre-Installation Preparation
PSU can be fitted to the unit, failure to connect this unit or wiring direct to the mains will invalidate the product warranty. The switch used to control the operation of the Xvent is a two button wall mounted control switch. This switch will allow you to operate and stop at any position between the fully open and closed positions. - Page 7 ± 2 mm. Check that the cable exit hole has been included in the upstand (refer to Glazing Vision’s sales drawings for the location). Also check the diagonals to ensure that the upstand has been constructed square.
-
Page 8: Upstand Top Trim Installation
405-INST-UK-001 v1.0 – 09 Jul 2020 Upstand Top Trim Installation Begin by cutting the upstand top trim to the lengths required for all sides of the upstand. The corner joints can either be mitred (45°) or straight cut with notches (see image below). If the material requires bending to suit the pitch of the upstand, this can be achieved by screwing the section to the upstand as below and gently tapping the horizontal part using a clean rubber mallet. -
Page 9: Fitting The Lifting Equipment
The lifting frame is usually (but not always) attached to the product prior to dispatch. Once the product is installed, please return the lifting equipment to Glazing Vision. The lifting frame is fully configurable and will fit any size of product. Use Glazing Vision’s drawing of the lifting frame to assist with identifying parts and how they fit together. -
Page 10: Installation Procedure
405-INST-UK-001 v1.0 – 09 Jul 2020 Installation Procedure Step 1 Remove all packaging from the product including polyfoam glass protection and low tack tape. When removing the packaging, try to keep it intact as much as possible, so that after installation it can be re-used to protect the product until project completion and final handover. - Page 11 Once satisfied that everything is correctly positioned, carefully release the weight of the product. Remove the crane and lifting frame. Once the product is installed, please return the lifting equipment to Glazing Vision. Step 5 Drill Ø3 mm pilot holes into the upstand through the pre-drilled holes in the product’s framework (concealed by the clip on cover).
- Page 12 Voltage adjustment is via a screw potentiometer accessed through the front cover (remove small plastic plug first). The PSU is external to the Xvent and can be mounted some way from the product, possibly resulting in a slight volt drop. This is a common reason for a slightly lower voltage at the battery terminals and requires adjusting.
-
Page 13: Interior Finishing
Glazing Vision does not specify the finishes permitted except for the following stipulations: • The finish must be built up to the internal dimension of the product – see Glazing Vision’s sales drawings. • No interior metal component (for example edging strips for plastering) may touch any part of the product framework that is the outer colour (RAL 7015 grey as standard).
Need help?
Do you have a question about the Xvent and is the answer not in the manual?
