ITW Mima GIROTEC TWIN Operating Instructions Manual

Semi-automatic machines
Hide thumbs
Table of Contents

Advertisement

Quick Links

OPERATING INSTRUCTIONS (1-6)
GIROTEC TWIN
GIROTEC STR
V3.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GIROTEC TWIN and is the answer not in the manual?

Questions and answers

Related Manuals for ITW Mima GIROTEC TWIN

Summary of Contents for ITW Mima GIROTEC TWIN

  • Page 1 OPERATING INSTRUCTIONS (1-6) GIROTEC TWIN GIROTEC STR V3.0...
  • Page 2 380kg 160kg Max. weight of film roll 2x3kg Rollcage Dimenstions Girotec Twin/STR 720/810/1900mm Max. pallet dimensions in Girotec STR 1000*1200*1850/2050mm Rotation Area (RA) Girotec Twin 1700mm 2055mm Electrical supply 220-240v/50Hz Girotec Twin power supply 24v, battery charger 220-240v/50Hz V3.0 TWIN...

  • Page 3: Table Of Contents

    1. MACHINE MAIN COMPONENTS In case questions appears, contact your local distributor. Authorized representative: 2. OPERATION 2.1 Control panel ITW Mima Packaging systems Finland Tel:+358 2 4376111 2.2 Preparations Technical support 2.3 Mount the film roll www.mimaitw.com 2.4 Adjust film tension 2.5 Adjust the wrapping settings...

  • Page 4: Machine Main Components

    MACHINE MAIN COMPONENTS GIROTEC TWIN: GIROTEC STR: 1. Boom 1. Boom 2. Rotary arm 2. Rotary arm 3. Film distributor 3. Film distributor 4. Film roll 4. Film roll 5. Bottom frame 5. Bottom frame 6. Operating panel 6. Operating panel 7.

  • Page 5: Operation

    OPERATION 2.2 Preparations 2.1 Control panel 1. Emergency stop 1. Open 2. Plus Top wrapping layers, overlapping locking device adjustment (much, medium, less)and (twin model only) selection of language 3. Plus bottom wrappings 4. Battery charging status 5. Wrapping height display 6.

  • Page 6: Mount The Film Roll

    OPERATION 2.3 Mount the 2.5 Adjust the film roll wrapping settings 1. Press the film roll 1. Select wrapping mode up to the lowest You may select any of surface of the film three different wrapping distributor modes: 2. Pull a length of - First wrapping height of film off the film roll 77cm.

  • Page 7: Wrapping

    OPERATION 2.6 Wrapping 1. Complete machine can be moved by forklift or pallet truck next to the rollcages. (twin model only) 2. Move rollcage to one of two wrapping stations and fix it in the rollcage holder. 3. Press Reset button 4.

  • Page 8: Safety

    SAFETY 5.1 General 5.4 Safety notes Please read the operating instructions 1. Never enter the area carefully before operating the between the tower and the machine. The machine has automatic pallet while the machine is functions which could endanger the in operation.
  • Page 9 Description of machinery: Semi-Automatic wrapping machine Machine types: Girotec TWIN Girotec STR Authorized representative: ITW MIMA Packaging Systems Ruskontie 16 FI – 21250 MASKU This machinery has been designed and manufactured using the provisions of EN 415-6 Safety of packaging machines. 29.08.2011...

This manual is also suitable for:

Girotec str
