- Page 1 User manual Column drill SB 55 SV Keep for future reference! Stand 26.11.08, SB 55 SV, Drills Page 1 of 37...
-
Page 2: Table Of Contents
Environmental conditions ................18 Operating material .................... 19 Emissions......................19 ASSEMLY ......................20 Delivery volume ....................20 Transport ......................20 Storage ......................20 Positioning and assembly ................20 3.4.1 Claims to installation location..............20 Stand 26.11.08, SB 55 SV, Drills Page 2 of 37... - Page 3 Preparation ....................27 5.1.2 Recommissioning ..................27 Inspection and attendance ................28 5.2.1 Daily work ....................28 5.2.2 Weekly work ....................28 5.2.3 Monthly work .....................28 Semi – yearly work ..................28 5.2.4 Maintenance ...................... 28 Stand 26.11.08, SB 55 SV, Drills Page 3 of 37...
- Page 4 10 REPLACEMENT PART LIST ................33 10.1 Replacement part list stand ................33 11 CIRCUIT DIAGRAM ..................34 11.1 Circuit diagram SB 55 SV ................. 34 12 APPENDIX ......................35 12.1 Copyright......................35 12.2 Product follow - up ................... 35 13 EG –...
-
Page 5: Safety
Support / Information If you are unable to solve a problem using this manual, please contact us for advice: Epple Maschinen GmbH Service und Support Auf der Breite 2-14 D-73349 Wiesensteig Stand 26.11.08, SB 55 SV, Drills Page 5 of 37... -
Page 6: Safety Notes (Waring Notes)
No dangerous or Information! harmful consequences for personal or objects. In case of specific dangers, we replace the pictogram by General Injuries to hand Dangerous, danger electrical tension Stand 26.11.08, SB 55 SV, Drills Page 6 of 37... -
Page 7: More, Used Pictograms
1.1.2 More, used pictograms Wear Wear Engaging Draft mains Wear ear protection protection forbidden plug protection gloves glasses Wear Wear safety Mind the Your contact protective shoes environment person suit Stand 26.11.08, SB 55 SV, Drills Page 7 of 37... -
Page 8: Proper Use
If the machine is used in any way other than as described above, modified without authorisation of Epple Maschinen GmbH or operated with different process data, then it is being used improperly. We do not take any liabilities for damage caused by improper use. We would like... -
Page 9: Danger, Which Can Emanate You From Drill
The machine only can be used with functioning safety equipment. The machine must be disconnected directly if you notice damaged or failure safety equipment. All special units that are mounted from the operator have to include the Stand 26.11.08, SB 55 SV, Drills Page 9 of 37... -
Page 10: Qualification Of Personnel
Control whether the personnel observes the operation manual and whether it is close to the machine Check that the staff is aware of safety and dangers in the workplace and that they observe the operating manual Stand 26.11.08, SB 55 SV, Drills Page 10 of 37... -
Page 11: The User Must
The failure/ cause of the failure is abolished You have checked the machine and fell confident that there is no danger for personnel or property values Stand 26.11.08, SB 55 SV, Drills Page 11 of 37... -
Page 12: Emergency Stop Control
Observe additionally to the user manual the safety and warning notes at the machine. Warning notes that only are to find in the user manual and not at the machine have additionally absolute validation and are to observe implicitly. Stand 26.11.08, SB 55 SV, Drills Page 12 of 37... -
Page 13: Safety Check Of The Machine
Stop the machine directly after use of the STOP control emergency Stop control. Belt cover you open the belt cover the motor disconnects or rather the motor does not start with opened cover. Stand 26.11.08, SB 55 SV, Drills Page 13 of 37... -
Page 14: Personal Protective Equipment For Special Work
Broken protective has to be modernized. Always announce missing protective and only begin to work if the protective is complete. Caution! Contaminated, defiled protectives can release indispositions. Clear them up after every use and at least once a week. Stand 26.11.08, SB 55 SV, Drills Page 14 of 37... -
Page 15: Safety During Use Of The Drill
Refresh the operation manual only in consultation with the manufacturer. Only instruct the operation personnel if all changes are approved. Document the instruction in an adequate way. Stand 26.11.08, SB 55 SV, Drills Page 15 of 37... -
Page 16: Breaking And Assuring The Machine
1.11 Accident report Inform your superior directly about accidents or “nearly accidents”. So – called „nearly accidents“ can have different causes and need an detailed analysis. Stand 26.11.08, SB 55 SV, Drills Page 16 of 37... -
Page 17: Electricity
– off the machine in an emergency. The machine must be out off gear immediately by failure in the electrical supply. You will find more information in chapter maintenance. Stand 26.11.08, SB 55 SV, Drills Page 17 of 37... -
Page 18: Technical Data
1.920 mm Weight 450 kg Necessary working room Width 1.500 mm Depth 1.500 mm Height 2.500 mm Environmental conditions 5 – 45°C Temperature ramnge Air humidity Up to max. 75% Stand 26.11.08, SB 55 SV, Drills Page 18 of 37... -
Page 19: Operating Material
Operating material To advance the durability of the column drill SB 55 SV we advice you a regular oil change. Epple Maschinen © advices you the oils of the following manufacturers: Feed gear Necessary amount: ca. 0,3 L ESSO – NURAY 100 B.P –... -
Page 20: Assemly
See that the installation location is not limited for the use, attendance and maintenance. Guarantee a boundless and free amenability of the mains plug and all operation unit of the machine. Stand 26.11.08, SB 55 SV, Drills Page 20 of 37... -
Page 21: Assembly
The use of dissolvers, diluents for cell lacquer or other cleansing agents that may attack the lacquer are improper Lubricate all bare machine parts. Use therefore an acid – free lubricant Stand 26.11.08, SB 55 SV, Drills Page 21 of 37... -
Page 22: Sight Check/ Manual Function Check
Accomplish a safety check at the machine (view point 1.7 safety check of the machine) Check the running direction of the centre sleeve. Front – sided the machine was adjusted at clockwise direction turning field. Stand 26.11.08, SB 55 SV, Drills Page 22 of 37... -
Page 23: Handling
Depth Stop and display Chip protection Belt cover Control elements of the table and column are the: Table height adjustment Table pivoting arrangement Table tilting arrangement Stand 26.11.08, SB 55 SV, Drills Page 23 of 37... -
Page 24: Activate The Machine
Adjust the tool to the material height Read the scale Add the drilling depth Adjust the arrester clamp of the scale at the real drilling depth Arrest the clamping. Stand 26.11.08, SB 55 SV, Drills Page 24 of 37... -
Page 25: Turn, Swivel, Tilt Table
Only work with orderly tool Only use Step drills, HSS drills, hole saws or reamers that are adequate for the material Observe a centric run of the tool Stand 26.11.08, SB 55 SV, Drills Page 25 of 37... -
Page 26: Fixing The Work Part In The Vice
Beat the ejection chock in direction of centre sleeve with a plastic hammer Do not move over the centre sleeve with interposed ejection chock upwards to eject the tool. Stand 26.11.08, SB 55 SV, Drills Page 26 of 37... -
Page 27: Maintenance
1.7. Warning! Assure before starting the machine that no danger for body and life exists and the machine possesses no defects. Stand 26.11.08, SB 55 SV, Drills Page 27 of 37... -
Page 28: Inspection And Attendance
Adequate and technical blameless tool Only original replacement parts or replacement parts which are freed assertively and in written form by the Epple Maschinen GmbH may be obstructed. Stand 26.11.08, SB 55 SV, Drills Page 28 of 37... -
Page 29: Failures
Renew drill Drill cants Pressure at centre sleeve too Abate pressure high Drill chuck does Drill chuck / collet not catch into Clean collet and drill chuck contaminated or oiled adaptor Stand 26.11.08, SB 55 SV, Drills Page 29 of 37... -
Page 30: Exploded Drawing
Exploded drawing Exploded drawing actuator Stand 26.11.08, SB 55 SV, Drills Page 30 of 37... -
Page 31: Replacement Part List
32 Plate 68 Bracket centre sleeve grip 33 Distance part 69 Hand lever 34 Speed display 70 Hand lever head 35 driving speed lever 71 Cover electric cabinet 36 Ball knob Stand 26.11.08, SB 55 SV, Drills Page 31 of 37... -
Page 32: Exploded Drawing
Exploded drawing Exploded drawing stand Stand 26.11.08, SB 55 SV, Drills Page 32 of 37... -
Page 33: Replacement Part List
Ball bearing Column bearung down Bolt Gear rack 10 Worm gear shaft Table 11 Ball bearing Column bearing up 12 Plate Ball bearing 13 Grip Teethed wheel 14 Crank grip Stand 26.11.08, SB 55 SV, Drills Page 33 of 37... -
Page 34: Circuit Diagram
11 Circuit diagram 11.1 Circuit diagram SB 55 SV Stand 26.11.08, SB 55 SV, Drills Page 34 of 37... -
Page 35: Appendix
Machine type Serial – No. Date of purchase Ca. running time per day Epple Maschinen GmbH Auf der Breite 2-14 73349 Wiesensteig Fax: 07335 9243 300 E-Mail: info@epple.com Stand 26.11.08, SB 55 SV, Drills Page 35 of 37... -
Page 36: Eg - Declaration Of Conformity
Epple Maschinen GmbH Auf der Breite 2-14 73349 Wiesensteig declares herewith, that the machine of the type SB 55 SV agrees with the following claims: Safety of tool machines – drilling machines EN12717:2001 and works accordant to the following guide lines:... -
Page 37: Acceptance Certificate
Emergency Stop switch/ control checked: Earth conductor test accomplished: Mechanic corresponding to examine statement Note Mechanical operating parts checked: Show window oil checked: Date of acceptance signature of the examiner Stand 26.11.08, SB 55 SV, Drills Page 37 of 37...
