tekton 4685 Operator's Manual

Hand crank air hose reel

Advertisement

Quick Links

MODEL #4685 SPECIFICATIONS
Air hose capacity: 3/8" x 50' (15.25M)
Reel air inlet (F): 1/4" NPT
Max. working
pressure:
300 PSI (20.68 BAR)
Read and understand entire manual before assembling or using hose reel. Failure to follow instructions or warnings
could result in personal injury and/or property damage. This product contains chemicals known to the State of
California to cause cancer and birth defects or other reproductive harm. Wash hands thoroughly after handling.
HAND CRANK
AIR HOSE REEL
OPERATOR'S MANUAL
STORE THIS MANUAL IN A SAFE
PLACE FOR FUTURE REFERENCE
NEED HELP?
Save time, contact us rst.
888-648-8665
support@tektontools.com
®
MODEL #4687 SPECIFICATIONS
Air hose capacity: 3/8" x 100' (30.5M)
Reel air inlet (F): 1/4" NPT
Max. working
pressure:
300 PSI (20.68 BAR)
Models
4685
4687

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4685 and is the answer not in the manual?

Questions and answers

Summary of Contents for tekton 4685

  • Page 1 AIR HOSE REEL OPERATOR’S MANUAL STORE THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE MODEL #4685 SPECIFICATIONS MODEL #4687 SPECIFICATIONS Air hose capacity: 3/8" x 50' (15.25M) Air hose capacity: 3/8" x 100' (30.5M) Reel air inlet (F): 1/4" NPT Reel air inlet (F): 1/4"...
  • Page 2 Important Safety Rules • DO NOT EXCEED 300 PSI incoming air pressure (from compressor). • Wear impact-resistant eye protection that meets ANSI Spec. Z87.1 in work area at all times. FIG. 1 HANDLE CRANK ASSEMBLY Unit is shipped without handle installed. To install handle, assemble parts 1-7 as shown in FIG.
  • Page 4 1 YEAR REPLACEMENT GUARANTEE This product is guaranteed for 1 YEAR. If it does not meet your expectations, we will replace it or provide replacement parts free of charge. To arrange for shipping of your replacement product or parts, or if you have any other questions, email us at support@tektontools.com or call us at 1-888-648-8665.

This manual is also suitable for:

4687
