- Page 1 Model 5409 ® SWIVEL BENCH VISE OPERATOR’S MANUAL STORE THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE NEED HELP? WARNING: WEAR IMPACT-RESISTANT Save time, contact us first. P R O T E C T I V E 888-648-8665 EYEWEAR IN WORK AREA AT ALL TIMES.
- Page 2 VISE SPECIFICATIONS #5409 - 8in. Swivel Bench Vise Jaw width 8 in. Jaw opening 6-3/8 in. Throat depth 3-7/16 in. Swivel 360º Pipe jaw capacity 1-1/4 to 2-1/2 in. Weight 40.2 lb. Anvil size 3-3/4 in (square) Mounting holes (3) 11/16 in.
- Page 3 SETUP AND MAINTENANCE • Keep machined surfaces and all moving parts clean and free of dirt, chips, and foreign materials. • Use multipurpose grease to keep moving parts lubricated. • Routinely apply mineral oil to machined surfaces to prevent surface rust. MOUNTING VISE 1.
- Page 4 SAFETY INSTRUCTIONS WARNING: Misuse of vise can cause serious injury. Vise must be installed and used properly. Follow all instructions below. WHEN USING VISE ALWAYS make sure the workbench top is secure. ALWAYS use eye, face, and ear protection. ALWAYS keep moving parts lubricated with multipurpose grease. ALWAYS keep workpiece centered in jaws.
