P A N E L E X P L A N A T I O N - Draytek Vigor2912 Series Quick Start Manual

2 . P a n e l E
2 . P a n e l E
V i g o r 2 9 1 2
V i g o r 2 9 1 2
LED
ACT (Activity)
WCF
QoS
DoS
LAN (P4~P1)
WAN(W2~W1)
VPN
USB
x p l a n a t i o n
x p l a n a t i o n
Status
Blinking
Off
On
Off
On
Off
On
Blinking
On
Off
Blinking
On
Off
Blinking
On
On
Blinking
Explanation
The router is powered on and running
normally.
The router is powered off.
The Web Content Filter is active. (It is
enabled from Firewall >> General Setup).
The Web Content Filter is inactive.
The QoS function is active.
The QoS function is inactive.
The DoS/DDoS function is active.
It will blink while detecting an attack.
The port is connected.
The port is disconnected.
The data is transmitting.
Internet connection is ready.
Internet connection is not ready.
The data is transmitting.
The VPN tunnel is active.
USB device is connected and ready for use.
The data is transmitting.
