Front Panel

Figure 2: Commander Site Controller - Front Panel
System Status Display — The backlit, rectangular display on
■
the front panel of the Commander Site Controller
CPU A Indicators and Controls — The indicators and controls
■
in this section of the front panel are specific to CPU A. A
detailed description follows in the next section.
CPU A Device Port LEDs (RX/TX) — Displays activity for
■
devices connected to serial ports of CPU A
S C
ITE ONTROLLER
Commander Site Controller Hardware Installation Guide
D
IAGRAMS
CPU A Indicators and Controls
CPU A Device
Port LEDs (RX/TX)
System
Status Display
