  • Page 1 TX6355 Sentro Wireless...

  • Page 3: Table Of Contents

    Connecting in Hazardous Disposal Areas Maintenance Records Setup and Calibration Maintenance and Controls and Indicators Calibration Log Software Menus Disclaimers Navigation Trademarks Power-up Document History Main Menu Contact Details 4.5.1 Calibrate 4.5.2 TX6355 Setup 4.5.3 Modbus Address www.trolex.com P5596.1600 rev B...

  • Page 4: Product Overview

    Strata specific digital wireless output signal • Battery powered operation from built in battery pack • Heavy duty housing to IP65, EMC compliant • Simple, easy to use menu structure • Easy integration into legacy wireless networks www.trolex.com P5596.1600 rev B...

  • Page 5: Application

    TX6355.06 Australia certified - 6V dc from built in battery pack A choice of Sentro eModules for sensing a range of toxic and flammable gases. See pages 9 to 14 for details of compatible Sentro eModules. www.trolex.com P5596.1600 rev B...

  • Page 6: Dimensions

    Dimensions www.trolex.com P5596.1600 rev B...

  • Page 7: Technical Information

    Alarms Programmable General alarms and High alarms with an LED indicator. The two adjustable alarm setpoints are preset during manufacture to default values appropriate to the type of sensor, determined by the sensing module being used. www.trolex.com P5596.1600 rev B...

  • Page 8: Electrical Details

    Current consumption 40 to 45 days life from internal batteries when suitable eModules fitted. (see section 1.7.2) Mounting By attachment point on the top of the Sentro Wireless housing - will accept a standard 25 mm strap www.trolex.com P5596.1600 rev B...

  • Page 9: Sentro Emodules

    The alarm signals can be set to illuminate built-in flashing LED indicators eModule Gas Sensor 1.7.1 Sentro eModules For information and advice on the full range of Sentro eModules contact the Trolex Sales Team: sales@trolex.com 1.7.2 MSHA Certified eModules Sentro Wireless TX6355 is certified by MSHA for use with the following eModules: www.trolex.com...
  • Page 10 P5596.1600 rev B...
  • Page 11 TX6355 User Manual www.trolex.com P5596.1600 rev B...

  • Page 12: Certification

    Gas Detectors, Approved 13 January 2011” • UL 61010-1 “UL Standards for Safety Electrical Equipment for Measurement, Control, and Laboratory Use; Part 1: General Requirements – Third Edition; Reprint with revisions through and including July 15, 2015”. www.trolex.com P5596.1600 rev B...

  • Page 13: South Africa (Masc)

    2. The other screw terminals 1, 2, 3, 6 on J6 Output Board shall not be used in the hazardous area. 3. Only Trolex manufactured gas sensing modules (“eModules”) identified by the top level part number “TX6350.06” shall be fitted.
  • Page 14 Ingress Protection (IP54). 7. The batteries must be removed to de-energise the unit before it is transported / relocated. Ex-Certified e-Modules: Appropriate TX6350 e-Modules may be fitted as assessed www.trolex.com P5596.1600 rev B...

  • Page 15: Installation

    The response of catalytic combustion gas sensors can be affected by air borne contaminants which will reduce the sensitivity. Substances such as silicones, tetraethyl lead, sulphur compounds and phosphate esters can cause permanent degradation (poisoning). Halogenated hydrocarbons may also cause temporary inhibition. www.trolex.com P5596.1600 rev B...

  • Page 16: Tools And Test Equipment Required

    It is also important to recognise that the characteristics of the gas source can be influenced by many factors; including the relative density or buoyancy of the gas, the pressure at the point of release, the ambient temperature and the ventilation of the site. www.trolex.com P5596.1600 rev B...

  • Page 17: Connections

    Trolex recommends that the Sentro Wireless Gas Detector is positioned a minimum of 6 m (20 ft) and no more than 245 m (800 ft) from a Strata CommTrac C node for the Sentro Wireless Gas Detector to work effectively.

  • Page 18: Setup And Calibration

    Setup and Calibration Controls and Indicators www.trolex.com P5596.1600 rev B...
  • Page 19 TX6355 User Manual www.trolex.com P5596.1600 rev B...

  • Page 20: Software Menus

    4.2 Software Menus www.trolex.com P5596.1600 rev B...

  • Page 21: Navigation

    To access the L (Next) and R (Select/Change) buttons you need to remove the front cover. Use a cross head screwdriver to remove the four screws securing the front cover and swing it out of the way. www.trolex.com P5596.1600 rev B...

  • Page 22: Power-Up

    Start-up Screen displays basic information about the system including the software version, driver version and output type. Power On After five seconds the Main Display will appear. The Main Display displays the current gas concentration level and the gas being detected. www.trolex.com P5596.1600 rev B...

  • Page 23: Main Menu

    The Sentro Wireless will automatically return to the Main Display if no keys are pressed within 30 seconds. The time limit is extended to 8 minutes during Calibrate to allow the gas value displayed on the LCD screen time to stabilise. www.trolex.com P5596.1600 rev B...

  • Page 24: Calibrate

    Open the valve and apply clean air at a rate of 0.5 litre/min. Wait for the reading to settle at a stable value. Press R to Zero the displayed value. Wait for the reading to stabilise at zero. www.trolex.com P5596.1600 rev B...
  • Page 25 DO NOT match follow the instructions in the section Calibrate Span - Using Test Gas of a Different Value. Using suitable tubing connect a cylinder of test gas to the gas hood fitted to the Sentro eModule. www.trolex.com P5596.1600 rev B...
  • Page 26 When the last digit is set, press R to select Done and return to the Calibrate Menu. Continue with Calibrate Span as described in the previous section Calibrate Span - Using Test Gas of Current Value. www.trolex.com P5596.1600 rev B...

  • Page 27: Tx6355 Setup

    This displays basic information about the system including the main software version, system date, system time, driver versions and output formats. From the TX6355 Setup Menu press L, navigate to the System Information and press R to display the System Information. www.trolex.com P5596.1600 rev B...
  • Page 28 From the Set Backlight Menu press R to set the Backlight Illumination to On or Off as required. Press L to move to Save or Cancel as required. Press R to confirm the selection and return to the Display Setup Menu. www.trolex.com P5596.1600 rev B...
  • Page 29 This enables you to carry-out the setup of the Alerts. From the TX6355 Setup Menu press L, navigate to Alert Setup and press R to enter the Alert Setup Menu. The available menus are as follows: • Visual Alert • Confidence Alarm • Exit www.trolex.com P5596.1600 rev B...
  • Page 30 Press R to confirm the selection and return to the Alert Setup Menu. Exit From the Alert Setup Menu press L, navigate to Exit and press R to confirm the selection and return to the TX6355 Setup Menu. www.trolex.com P5596.1600 rev B...
  • Page 31 Save or Cancel as required and press R to confirm the selection. 4.5.2.5 Exit From the TX6355 Setup Menu press L, navigate to Exit, press R to confirm the selection and return to the Main Menu. www.trolex.com P5596.1600 rev B...

  • Page 32: Modbus Address

    Press R to Increase or Decrease the Modbus Address as required. Press L and navigate to select Save or Cancel as required. Press R to confirm the selection and return to the Output Setup Menu. www.trolex.com P5596.1600 rev B...
  • Page 33 Press L to navigate to Increase or Decrease as required. Press R to Increase or Decrease as required. Press L and select Save or Cancel as required. Press R to confirm the selection and return to the Output Setup Menu. www.trolex.com P5596.1600 rev B...

  • Page 34: Module Setup

    From the Module Setup Menu press L, navigate to Setpoint 1 or Setpoint 2 and press R to enter the Setpoint 1 or Setpoint 2 Setup Menu. The available menus are as follows: • Activation • Level • Exit www.trolex.com P5596.1600 rev B...
  • Page 35 From the Setpoint 1 or Setpoint 2 Setup Menu press L, navigate to Level and press Press R to increment the digits as required. Press L to move to the next digit. Repeat for all digits and press L. www.trolex.com P5596.1600 rev B...
  • Page 36 From the Module Setup Menu press L, navigate to STEL & TWA and press R to enter the STEL & TWA Setup Menu. www.trolex.com P5596.1600 rev B...
  • Page 37 From the STEL & TWA Setup Menu press L, navigate to Reset STEL & TWA and press R. The STEL & TWA are now reset. Press R to select Done and return to the STEL & TWA Setup Menu. www.trolex.com P5596.1600 rev B...

  • Page 38: Commtrac

    • Comms • Firmware Versions • CN RSSI • Xmit Freq • Voltages • I/O #1 • I/O #2 • Location Msg Interval • Sensor Msg Interval • Sensor Polling Interval • Mute Alarm • Exit www.trolex.com P5596.1600 rev B...
  • Page 39 CN RSSI and press R to enter the CN RSSI Menu. This displays the strength of the wireless signal the gas detector is receiving from the CommTrac node. The value displayed will be between -100 (weak signal) to 0 (strong signal). www.trolex.com P5596.1600 rev B...
  • Page 40 OPERATING FREQUENCY OUTSIDE OF THIS RANGE. This parameter is configured during manufacture. It is user configurable but Trolex strongly recommends that users DO NOT alter the configured frequency. 4.5.5.5 Voltages From the CommTrac Setup Menu press L, navigate to Voltages and press R to enter the Voltages Menu.
  • Page 41 Timed Out will display once the Test is completed. 4.5.5.7 Location Msg Interval From the CommTrac Setup Menu press L, navigate to Location Msg Interval and press R to enter the Location Msg Interval Menu. www.trolex.com P5596.1600 rev B...
  • Page 42 Press R to increment the digits as required. Press L to move to the next digit. Repeat for all digits, press L and select Save or Cancel as required. Press R to confirm the selection and return to the CommTrac Setup Menu. www.trolex.com P5596.1600 rev B...
  • Page 43 Press R to change the configuration between Alarm Muted and Alarm Not Muted as required. Press L and navigate to Save or Cancel as required. Press R to confirm the selection and return to the CommTrac Setup Menu. www.trolex.com P5596.1600 rev B...

  • Page 44: Exit

    Main Display. 4.6 Support If you need technical support to operate this product, or would like details of our after sales technical support packages, please contact your local Trolex service agent or service@trolex.com. www.trolex.com P5596.1600 rev B...

  • Page 45: Diagnostics And Maintenance

    • Check that the gas concentration has receded, then reset the eModule by removing it for 2 seconds Electrochemical, Infrared or LED Infrared Gas Sensor • The screen will display the error message www.trolex.com P5596.1600 rev B...

  • Page 46: Sensor Negative Drift

    10% of the measuring range. 5.1.3 Recovery from Display Freeze If the display freezes, it may be unfrozen by pressing and holding the L and R buttons simultaneously for about 10 seconds. www.trolex.com P5596.1600 rev B...

  • Page 47: Introduction

    5.2.1 Introduction To keep your Sentro Wireless in the best possible condition and minimise downtime, Trolex strongly recommends that you carry out regular planned preventative maintenance and keep records of the maintenance carried out. The planned preventative maintenance for Sentro Wireless consists of a number of tasks...

  • Page 48: Sentro Wireless Gas Inlet Port - Check And Clean

    Note: When a Carbon Monoxide eModule is fitted, in order to comply with performance standard ANSI/ISA 92.00.01, ensure that any bump test verifies that the accuracy is within +/- 6 ppm or +/- 10% of the reading, whichever is the largest. www.trolex.com P5596.1600 rev B...

  • Page 49: Sentro Wireless Batteries - Replace

    4.5.1. 2. Replace any eModule that fails the calibration. 3. eModules may be pre-calibrated at any location convenient to the user, and installed in another location at some later date. www.trolex.com P5596.1600 rev B...

  • Page 50: Sentro Wireless - Safety Check

    5.2.6 Sentro Wireless - Safety Check The Sentro Wireless will not normally require maintenance or calibration, but it is advisable to return it to the Trolex Product Support Department for an annual safety check. 2. After the completion of all maintenance, update the maintenance records.

  • Page 51: Recommended Test Gas Concentrations

    Product Support department and can be supplied in a range of capacities from 34 litres up to 110 litres. Please contact your local Trolex service agent or service@trolex.com for advice regarding recommended test gas procedures and product support plans.

  • Page 52: Disposal

    Disposal Part of the ethos of Trolex is sustainable design. Sentro Wireless contains materials that can be recovered, recycled and reused. At the end of its useful life ensure that the Sentro Wireless is recycled in accordance with local laws and bylaws for the geographic area where it is located.

  • Page 53: Maintenance And Calibration Log

    TX6355 User Manual 5.6 Maintenance and Calibration Log Order Reference: TX Serial Number: Date Purchased: Gas Type: Location: Scheduled Change Return Date Fault Recalibrate Comments Check eModules to Trolex www.trolex.com P5596.1600 rev B...

  • Page 54: Disclaimers

    When devices are used for applications with technical safety requirements, the relevant instructions must be followed. Trademarks © 2018 Trolex® Limited. Trolex is a registered trademark of Trolex Limited. The use of all trademarks in this document is acknowledged. www.trolex.com P5596.1600 rev B...

  • Page 55: Document History

    TX6355 User Manual Document History Version Date 26/02/18 4545 14/07/20 5009 Contact Details Trolex Ltd, Newby Road, Hazel Grove, Stockport, Cheshire, SK7 5DY, UK +44 (0) 161 483 1435 sales@trolex.com www.trolex.com P5596.1600 rev B...
  • Page 56 P5596.1600 rev B...
