2-2 Basic operations

Just after power-on:
The display below appears just after power-on.
C1 C2 AL1 AL2
PV
SV
SEL
PXR
How to switch parameters:
The figure below shows the basic operations for the PXR.
Just after power-on
PV
Changes SV.
SV
PXR
SEL
(approx. (approx.
1 second) 3 seconds)
Parameters of the
first block
12
°C
AL3
Status at delivery
<In Auto mode>
(PV/SV displayed)
°C
C1 C2 AL1 AL2 AL3
SEL
SEL
SEL
(approx.
5 seconds)
Parameters of the
Parameters of the
second block
third block
Basic operations for the PXR (In Auto mode)
°C
C1 C2 AL1 AL2 AL3
PV
SV
SEL
<In Manual mode>
PXR
Setting parameters
Not operated
for 30 seconds.
PV
SV
Pressing and holding the
keys makes the value increase or
decrease fast.
PV
SV
SEL
PV
SV
SEL
PV
SV
