Section 4 - Technical Data - Inta HIPER-V3 DIRECT Installation Instructions Manual

Page 5

Section 4 - Technical Data

Maximum operating pressure
Maximum Hot Water Flow Rate
Maximum District Flow Rate
Maximum Pressure differential
Weight (empty/ installed)
Temperature of Heating – Low Mode ºC
Temperature of Heating – High Mode °C
Temperature of Hot Water
10°C to 50°C at 14 l/m
Primary Flow 0.266 ltrs /sec
Max DHWS Flow
Min DHWS Pressure
Max Hot water temperature
At 18l/m and ΔT of 15°C
Maximum Inlet Temperature
Minimum required 'District 'flow
rate @ 80°C to provide Hot Water
10 to 50°C at max flow rate
Minimum required 'District' flow
rate @ 70°C to provide Hot Water
10 to 50°C at max flow rate
Maximum Pressure
Electrical Supply
Power consumption full load
'District' Inlet and Outlet
Heating System Inlet and Outlet
Cold Water Inlet / Hot Water Outlet
HIUV3-40
bar
l/min
l/min
bar
kg
Available Settings
ºC
Hot Water Performance
Kw
Ltrs/min
bar
Heating Performance
kW
'District' Heat Provision
ºC
l/min
l/min
Electrical Data
watts
Connection Data
-V3 DIRECT
Data
10
14 to 18
18
3
21
30 – 45
30 – 80
40 – 60
40 Plate
50kW
18
1.5
10 bar
15
85
9.36
11.98
10 bar
230V AC 50Hz 1Ph
105
3/4" Male BSP
3/4" Male BSP
1/2" Male BSP
05/20 E&OE
