Limited One Year Warranty
T&S warrants to the original purchaser (other than
for purposes of resale) that such product is free from
defects in material and workmanship for a period of
one (1) year from the date of purchase. During this
one-year warranty period, if the product is found to
be defective, T&S shall, at its options, repair and/
or replace it. To obtain warranty service, products
must be returned to...
T&S Brass and Bronze Works, Inc.
Attn: Warranty Repair Department
2 Saddleback Cove
Travelers Rest, SC 29690
Shipping, freight, insurance, and other transpor-
tation charges of the product to T&S and the return
of repaired or replaced product to the purchaser are
the responsibility of the purchaser. Repair and/or
replacement shall be made within a reasonable time
after receipt by T&S of the returned product. This
warranty does not cover Items which have received
secondary finishing or have been altered or modi-
fied after purchase, or for defects caused by physi-
cal abuse to or misuse of the product, or shipment
of the products.
Any express warranty not provided herein, and
any remedy for Breach of Contract which might arise,
is hereby excluded and disclaimed. Any implied
warranties of merchantability or fitness for a particu-
lar purpose are limited to one year in duration. Under
no circumstances shall T&S be liable for loss of
use or any special consequential costs, expenses
or damages.
Some states do not allow limitations on how long
and implied warranty lasts or the exclusion or limi-
tation of incidental or consequential damages, so
the above limitations or exclusions may not apply
to you. Specific rights under this warranty and other
rights vary from state to state.
P/N: 098-003122-45 Rev.2
Date: 980416
Drawn: CW
Checked:
MW 6-10-98
Approved:
MAB 6-10-98
Installation and
Maintenance
Instructions
WORKBOARD FAUCET
B-1100 Series
Deutsch:
Installations- und
Wartungsanleitungen
Español:
la Instalación y las
Instrucciones de
Mantenimiento
Français:
les Instructions
d'Installation et
d'Entretien

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B-1100 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for T&S B-1100 Series

  • Page 1 B-1100 Series Any express warranty not provided herein, and any remedy for Breach of Contract which might arise, is hereby excluded and disclaimed.
  • Page 2: Exploded View

    Exploded View Some items are listed for instructional purposes and may not be sold as separate parts.
  • Page 3: Part Number Guide

    Part Number Guide Base Faucet Assemblies Asm, Base Faucet (B-1100 - B-1103) Base, Faucet Washer, Shank 000999-45 Locknut 002954-45 Seat 000763-20 Escutcheon, Body 001258-40 (3-1/2" - 4" Centers) Escutcheon, Body 001259-40 (8" Centers) Locknut, Cover Pl 000712-25 Asm, Spindle - LH 002709-40 Asm, Spindle - RH 002710-40...
  • Page 4: General Instructions

    General Instructions Nozzle Installation: Faucet Installation: Note: Nozzle should be installed first. 3. Drill (2) two holes into sink or See diagram below: countertop where you are installing no.1. Inlet spacing: 3-1/2”, 4” or 8” 1. Shut off water supply and drain center to center.
  • Page 5: Instrucciones Generales

    Instrucciones Generales Instalación De La Boquilla: Instalación De La Canilla: Nota: Las boquillas deben de ser 3. Perfore (2) dos huecos en el instaladas primero. Mire el dibujo lavatorio o el mostrador donde la de abajo: parte No.1 será instalada. Aberturas para las lineas de surtido: 9cm, 1.
  • Page 6: Instructions Générales

    Instructions Générales L’Installation Du Robinet: L’Installation De L’Ajutage: 3. Percer (2) deux trous dans le Noter: Les ajutages devoir être comptoir ou l’évier ou vous aller installer au début. Voir le diagramme installer Nº.1. L’espacement de ci-dessous: l’arrivée: 9cm, 10cm ou 20cm centre 1.
  • Page 7: Allgemeine Anleitungen

    Allgemeine Anleitungen Schwenkhahninstallation: Armatureninstallation: Anmerkung: Der Schwenkhahn ist 3. Zwei (2) Löcher in das Becken oder als erstes zu installieren. Siehe die Abdeckplatte bohren, in die Nr.1 Zeichnung unten: installiert wird. Entfernung der Wasserzufuhren: 9cm, 10cm oder 1. Wasserzufuhr abstellen und 20cm von Mitte zu Mitte.
  • Page 8 RELATED T&S BRASS PRODUCT LINE B-2347 Lavatory Faucet with Hose Spray T&S BRASS AND BRONZE WORKS, INC. A firm commitment to application-engineered plumbing products 2 Saddleback Cove, P.O. Box 1088, T & S Brass-Europe Travelers Rest, SC 29690 ‘De Veenhoeve’ Phone: (864) 834-4102 Oude Nieuwveenseweg 84...
