Carrier WeatherExpert 48JC04 Installation Instructions Manual
Carrier WeatherExpert 48JC04 Installation Instructions Manual

Carrier WeatherExpert 48JC04 Installation Instructions Manual

Ultra high efficiency single package rooftop gas heating/electric cooling unit with puron (r-410a) refrigerant

Advertisement

CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . 1
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Rated Indoor Airflow . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Jobsite Survey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Step 1 - Plan for Unit Location . . . . . . . . . . . . . . . . . 7
Step 3 - Inspect Unit . . . . . . . . . . . . . . . . . . . . . . . . . 7
Step 4 - Provide Unit Support . . . . . . . . . . . . . . . . . . 7
• ALTERNATE UNIT SUPPORT (IN LIEU OF CURB OR
Step 5 - Field Fabricate Ductwork . . . . . . . . . . . . . . 9
Step 6 - Rig and Place Unit . . . . . . . . . . . . . . . . . . . . 9
Ductwork (When Required). . . . . . . . . . . . . . . . . . 10
Step 8 - Install Outside Air Hood . . . . . . . . . . . . . . 11
• ECONOMIZER HOOD PACKAGE REMOVAL AND
Step 10 - Install Flue Hood . . . . . . . . . . . . . . . . . . . 12
Step 11 - Install Gas Piping. . . . . . . . . . . . . . . . . . . 12
(GAS CONNECTIONS)
Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
• ALL UNITS
• HACR AMP RATING
• UNITS WITHOUT THRU-BASE CONNECTIONS
(ELECTRICAL CONNECTIONS)
• FIELD CONTROL WIRING
• SPACE TEMPERATURE SENSOR (SPT)
• THERMOSTAT
• HEAT ANTICIPATOR SETTINGS
• HUMIDI-MIZER® CONTROL CONNECTIONS
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53480282-01
Single Package Rooftop Gas Heating/Electric Cooling Unit
Installation Instructions
Printed in U.S.A.
Form 48JC-4-6-01SI
48JC04-06 Ultra High Efficiency
with Puron
®
Integrated Gas Controller. . . . . . . . . . . . . . . . . . . . . .27
Controller Options . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Smoke Detectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Step 15 - Install Accessories . . . . . . . . . . . . . . . . . .30
Step 16 - Fan Speed Set Up . . . . . . . . . . . . . . . . . . .30
START-UP CHECKLIST . . . . . . . . . . . . . . . . . . . . .CL-1

SAFETY CONSIDERATIONS

Improper
installation,
maintenance, or use can cause explosion, fire, electrical shock or
other conditions which may cause personal injury or property
damage. Consult a qualified installer, service agency, or your
distributor or branch for information or assistance. The qualified
installer or agency must use factory-authorized kits or accessories
when modifying this product. Refer to the individual instructions
packaged with the kits or accessories when installing.
Follow all safety codes. Wear safety glasses and work gloves. Use
quenching cloths for brazing operations and have a fire
extinguisher available. Read these instructions thoroughly and
follow all warnings or cautions attached to the unit. Consult local
building codes and appropriate national electrical codes (in USA,
ANSI/NFPA70, National Electrical Code (NEC); in Canada, CSA
C22.1) for special requirements.
It is important to recognize safety information. This is the safety-
alert symbol
. When you see this symbol on the unit and in
instructions or manuals, be alert to the potential for personal
injury.
Understand the signal words DANGER, WARNING, CAUTION,
and NOTE. These words are used with the safety-alert symbol.
DANGER identifies the most serious hazards which will result in
severe personal injury or death. WARNING signifies hazards
which could result in personal injury or death. CAUTION is used
to identify unsafe practices, which may result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability,
or operation.
WARNING
Electrical shock can cause personal injury and death. Shut
off all power to this equipment during installation. There
may be more than one disconnect switch. Tag all disconnect
locations to alert others not to restore power until work is
completed.
Pg 1
WeatherExpert
(R-410A) Refrigerant
adjustment,
alteration,
5-2020
Replaces: New
®
service,
