Lifetime 538116 Assembly Instructions Manual

Outdoor glider bench
Hide thumbs Also See for 538116:

Advertisement

Quick Links

Download this manual
Para el español, ver la página 2.
Pour le français, voir la page 3.
OUTDOOR GLIDER
BENCH
ITm./ART. 538116
Lifetime benches are designed to be strong and
durable. We strive to make assembly as easy as
possible without compromising quality. If you
get stuck, we have tools to help:
• Level Ground
Assemble the bench on level ground
• Recruit Friends and Family
Assembly should take 2 people about 1
hour to complete.
FOR DOmESTIC USE ONly!
ImPORTANT: RETAIN FOR FUTURE REFERENCE. READ CAREFUlly.
TOOlS REQUIRED
BTN
4 mm
(Included)
NEED HElP? TAlK TO US!
Call: 1-800-225-3865
7:00 am - 5:00 pm (Monday - Friday) MST
and 9:00 am - 1:00 pm Saturday MST
(U.S.A. and Canada)
Importado por:
Importadora Primex S.A. de C.V.
Blvd. Magnocentro No. 4
San Fernando La Herradura
Huixquilucan, Estado de México
C.P. 52765
RFC: IPR-930907-S70
Tel: 5-5246-5500
Ninguna garantía ofrecida por el fabricante es válida en méxico.
CSH
8 mm x 10 mm
(Included)
lifetime's Shed Assembly Experts offer quick responses and great customer service.
Web: www.lifetime.com/instructions
Live Chat: www.lifetime.com/instructions
TABlE OF CONTENTS
Icon Legend...............................4
Warnings & Notices.....................5
Parts Identifi er............................6
Base Assembly............................7
Seat Assembly..........................10
Cleaning & Care........................15
Registration............................16
Warranty.............................17
mODEl# AND PRODUCT ID
(you will need both when contacting us)
Model Number:
Product ID:
60055
