Summary of Contents for ViewSonic VS12242
-
Page 2: Compliance Information
Compliance Information FCC Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 3: Important Safety Instructions
DPG801BK CE Conformity for European Countries The device complies with the requirements of the EEC directive 2004/108/EC as amended by 92/31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic compatibility”, and 2006/95/EC as amended by 93/68/ EEC Art.13 with regard to “Safety”. Following information is only for EU- member states: The mark shown to the right is in compliance with the... - Page 4 prong. The wide blade and the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs.
-
Page 5: Declaration Of Rohs Compliance
DPG801BK Declaration of RoHS Compliance This product has been designed and manufactured in compliance with Directive 2002/95/EC of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Substance... -
Page 6: Table Of Contents
Table of Contents Follow the instructions below to install and operate the unit..1 Step 1: Check the components......1 System Requirements: . - Page 7 DPG801BK <Memo> Quick Start Guide...
-
Page 8: Follow The Instructions Below To Install And Operate The Unit
Follow the instructions below to install and operate the unit. Step 1: Check the components. Carefully open the packing box and ensure that you have the following items. 1. Digital photo frame (DPG801BK) 2. Adjustable foot stand 3. USB cable 4. -
Page 9: Controls On The Front
DPG801BK Controls on the front Controls on the back Power switch Power jack USB jack (for connecting to a computer so the computer can edit files in the unit) Control panel Hanging slot 5-in-1 card slot: SD/xD/MMC/MS/MS Pro Speaker Lock slot Quick Start Guide... -
Page 10: Step 2: Install The Adjustable Foot Stand
DPG801BK Step 2: Install the adjustable foot stand. 1. On the back of the unit, attach the foot stand to the lock slot. Lock slot Adjustable foot stand 2. To place the photo frame vertically, rotate the foot stand counter- clockwise until it is secured to the photo frame. -
Page 11: Step 3: Connect The Ac Power
DPG801BK 3. To place the photo frame horizontally, rotate the foot stand clockwise until it is secured to the photo frame. Step 3: Connect the AC power. 1. Plug one end of the AC power adapter into the power jack on the back of this unit. -
Page 12: Step 4: (Optional) Insert A Memory Card
3. Place this unit horizontally (recommended direction) or vertically on a stable surface. Step 4: (Optional) Insert a memory card. On the back of the unit, you can insert a memory card containing the content you want to show on the unit. Note: Secure Digital™... -
Page 13: Step 5: Turn On The Unit
DPG801BK Step 5: Turn on the unit. Slide the power switch to the ON position to power on the unit. Power switch Step 6: Operate the unit. After the unit is turned on, available functions (represented by name or icon) show on the screen. Their corresponding buttons also light up on the control panel for a period of time. - Page 14 Simply press the corresponding button below (if the unit is placed horizontally) or beside (if the unit is placed vertically) the name or icon indicating the function you want to use. To toggle among Photo, Calendar, Music, and Video modes, press under Mode.
-
Page 15: Using The Photo Mode
DPG801BK Using the Photo mode Current mode Mode selection Note: Standard JPEG and BMP image file formats are supported. Using the Calendar mode Current mode Mode selection Menu Slideshow Zoom-out Next file Zoom-in Previous file Menu Next month Previous month Current file number/Total number of files... -
Page 16: Using The Music Mode
Using the Music mode Current mode Track name, elapsed time, and volume level Mode selection Note: MP3 and WMA audio file formats are supported. Quick Start Guide Volume down Next track Volume up Previous track DPG801BK List of all music tracks and access to menu Play or Pause... -
Page 17: Using The Video Mode
DPG801BK Using the Video mode Current mode Video file name, elapsed time, and volume level Mode selection Note: The Motion JPEG (M-JPEG) compressed video files (*.avi and *.mov) are supported. However, not all files with these extensions can be played properly. Refer to the table below for limitations.
