Page 1: Digital Photo Frame
- User Guide Digital Photo Frame - Guide de l’utilisateur VFD725w-50P - Bedienungsanleitung VFM735w-51P - Guía del usuario - Guida dell’utente Model No.: VS12403... -
Page 2: Important Safety Instructions
Important Safety Instructions Do not use the equipment near water. Wipe the machine with a soft and dry cloth. Do not block any vent holes. Please install the product in accordance with the manufacturer’s instructions. Do not use the product on your legs for a long time because it gets hot and you may be burned. P lease avoid installing the product in a place where the temperature is above 40°C or lower than -10°C, or in a place that is moist or wet. P rotect the power cord plug, outlet, and connections to other equipment from damage by trapping and squeezing. Please only use devices and accessories specified by the manufacturer. T he unit is hot pluggable. However it is recommended that the power be turned off before the memory card is inserted or removed. Do not remove the memory card during data access. The data may be lost and the product could be damaged. 10. Disconnect the power cord if the product will not be used for an extended period. 11. D o not repair, disassemble, or modify the product. Only qualified ViewSonic personnel can check and repair any damage to the machine. 12. T he unauthorized playing of certain audio or image files may infringe the related copyright laws under certain circumstances. 13. W hen you use the internal speakers, do not adjust the volume to a high level, or the sounds may distort and become unpleasant. 14. When you view pictures for an extended period of time your eyes may become strained. 15. Do not touch the screen because it is difficult to remove finger marks. 16. Avoid exposing the digital photo frame to direct sunlight. Adjust the angle to reduce glare. 17. Careful attention should always be paid when moving the digital photo frame. 18. Make sure the place where the digital photo frame is placed is clean and dry. -
Page 3: Compliance Information
Compliance Information Following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE). The mark indicates the requirement NOT to dispose the equipment as unsorted municipal waste, but use the return and collection systems according to local law. ViewSonic VFD725w-50P/VFM735w-51P... -
Page 4: Declaration Of Rohs Compliance
Cadmium (Cd) Hexavalent Chromium (Cr 6+ ) Polybrominated biphenyls (PBB) Polybrominated diphenyl ethers (PBDE) Certain components of products as stated above are exempted under the Annex of the RoHS Directives as noted below: Examples of exempted components are: 1. M ercury in compact fluorescent lamps not exceeding 5 mg per lamp and in other lamps not specifically mentioned in the Annex of RoHS Directive. 2. L ead in glass of cathode ray tubes, electronic components, fluorescent tubes, and electronic ceramic parts (e.g. piezoelectronic devices). 3. L ead in high temperature type solders (i.e. lead-based alloys containing 85% by weight or more lead). 4. L ead as an allotting element in steel containing up to 0.35% lead by weight, aluminium containing up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight. ViewSonic Proposed Maximum Concentration 0.1% 0.1% 0.01% 0.1% 0.1% 0.1% Actual Concentration < 0.1% < 0.1% < 0.01% < 0.1% < 0.1% < 0.1%... -
Page 5: Copyright Information
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to change product specifications without notice. Information in this document may change without notice. No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without prior written permission from ViewSonic Corporation. Product Name: Model Number: Document Number: Serial Number: Purchase Date: Product disposal at end of product life ViewSonic is concerned about the preservation of our environment. Please dispose of this product properly at the end of its useful life. Your local waste disposal company may provide information about proper disposal. ViewSonic For Your Records VFD725w-50P/VFM735w-51P ViewSonic Digital Photo Frame VS12403 VFD725w-50P_VFM735w-51P_UG_ENG Rev. 1C 04-16-09 ________________________________________________ ________________________________________________ VFD725w-50P/VFM735w-51P... -
Page 6: Table Of Contents
Main screen ...8 Viewing thumbnails ...9 Browsing a single picture ...10 Playing a slideshow...10 Using OSD menu ... 11 Listening to Music (For VFM735w-51P only) ...12 Watching Videos (For VFM735w-51P only) ...13 Managing Files...14 Coping files...15 ViewSonic TABLE OF CONTENTS VFD725w-50P/VFM735w-51P... - Page 7 Deleting files ...15 Changing Frame Settings ...16 Settings menus...16 Setting auto power on/off ...18 Setting time ...19 Setting alarm clock (For VFM735w-51P only)...19 Displaying Calendar (For VFM735w-51P only) ...20 Frequently Asked Questions...21 Specification ...23 ViewSonic VFD725w-50P/VFM735w-51P...
-
Page 8: Introduction
We also have no responsibility for damages or loss of data caused by improper operation. The instruction manual is subject to change for improvement without notice. Trademarks and trade names used in this user’s manual are owned by their respective companies or organizations. ViewSonic VFD725w-50P/VFM735w-51P... -
Page 9: Main Features
Calendar display (For VFM735w-51P only) Alarm setting (For VFM735w-51P only) Auto power On/Off Support earphone connection (For VFM735w-51P only) Compatible with SD/MMC/MS, and CF memory cards USB Host for connecting to the USB mass storage USB2.0 high speed transmission ViewSonic VFD725w-50P/VFM735w-51P... -
Page 10: Overview
[M] Menu touch key; touch and hold to open OSD menu [ ] Exit touch key [ ] Left/Rotate/Adjust Volume touch key (For VFM735w-51P only) ViewSonic Back and Side View [ ]Right/Rotate/Adjust volume touch key (For VFM735w-51P only) [ ] Up/Previous touch key... -
Page 11: Getting Started
Getting Started Attaching the mount ViewSonic Place the frame on a flat surface with its back facing you. Place the mount carefully in the slot on the back of the frame. Turn the mount counter-clockwise by 45°until it locks. It will now be possible to set the device in the landscape orientation. -
Page 12: Connecting To The Power
• Secure Digital Card (SD) • Multimedia Card (MMC) • Memory Stick (MS) • Compact Flash card (CF) You have three possibilities of inserting a memory card or attaching a memory stick: ViewSonic Plug one end of the power adaptor into the DC socket in the Digital Photo Frame, and the other into the wall outlet. - Page 13 The 3-in-1 card slot only reads one memory card at a time. Do not insert more than one card into one memory card slot. To remove the cards or the USB memory stick, pull it out gently. ViewSonic Push a USB memory stick into the USB HOST slot. VFD725w-50P/VFM735w-51P...
-
Page 14: Copy Files From Computer
When connecting with a computer, the USB HOST driver is not available. Do not disconnect the USB cable or remove the card during files coping and transferring. ® System support: Windows 2000/ XP/ Vista Copy function does not work for all video files. ViewSonic VFD725w-50P/VFM735w-51P... -
Page 15: Viewing Photos
If several memory devices connect to the frame simultaneously, the Digital Photo Frame will read the memory source by the priority order as follows: USB, CF, SD/MMC/MS, NAND flash (only for model with internal memory). ViewSonic USB driver Appears when you inserted a USB flash driver. -
Page 16: Viewing Thumbnails
Viewing thumbnails Note: Touch the [ ] button from a slideshow or a single view to return to the thumbnails view. ViewSonic Touch the [ ] or [ ] button to select a memory source, and then touch the [ ] button. The mode menu appears. Use the [ ] or [ ] button to select Photo, Music, Movie or File. -
Page 17: Browsing A Single Picture
To pause the slideshow and view a single picture, touch the [ ] button. To resume the slideshow, touch the [ ] button again. Touch the [ ] button to exit the slideshow and view the pictures in thumbnail. Touch the [M] button to exit the slideshow and return to the main screen. ViewSonic VFD725w-50P/VFM735w-51P... -
Page 18: Using Osd Menu
X2, X4, X8, X16. When a picture is magnified, touch the [ ], [ ], [ ] or [ ] button to view the other part of the picture. ViewSonic and touch the [ ] button. The and touch the [ ] button. -
Page 19: Listening To Music (For Vfm735W-51P Only)
Listening to Music (For VFM735w-51P only) If there are MP3/WMA files on the memory device, you can play them on the Digital Photo Frame. ViewSonic Select a memory source (e.g. USB, SD/MMC) in the main screen and touch the [ ] button. The mode menu appears. -
Page 20: Watching Videos (For Vfm735W-51P Only)
To fast search forward or backward within a track, touch and hold [ ] or [ ] button. Each time the button is pressed, the speed of search changes accordingly. Touch the [ ] button to resume the playback from the searched point. To stop playback and return to the video list menu, touch the [ ] button. ViewSonic VFD725w-50P/VFM735w-51P... -
Page 21: Managing Files
In the File mode, you can view all playable files and folders on the memory source. You also can copy files from a memory device to another memory device or delete the files. ViewSonic Select a memory source (e.g. USB, SD/MMC) in the main screen and touch the [ ] button. -
Page 22: Coping Files
Use the [ ] or [ ] button to select Delete in Copy and Delete menu, and then touch the [ ] button. Use the [ ] or [ ] button to select “ ViewSonic Highlight a file using the [ ] or [ ] button and touch the [ ] button. A check mark is displayed next to the file. -
Page 23: Changing Frame Settings
The available options include: Random, Fading, Off, Bottom_To_Top, Top_To_Bottom, Left_To_Right, Right_To_Left, Door_Close, Door_Open, Hori_Cross, Verti_Cross. ViewSonic Select the SETUP icon in the main screen and touch the [ ] button. The Setup Menu and software version appear on the screen. - Page 24 The available options include: -3, -2, -1, 0, 1, 2, 3. Adjust the contrast of TFT screen. TFT Contrast The available options include: -3, -2, -1, 0, 1, 2, 3. Adjust the saturation of TFT screen. TFT Saturation ViewSonic VFD725w-50P/VFM735w-51P...
-
Page 25: Setting Auto Power On/Off
Every: The Digital Photo Frame will turn on or off at the preset time everyday. Once: The Digital Photo Frame only turns on or off at the preset time once. Touch the [ ] button to confirm. Note: The current time must be set correctly before setting up this feature. ViewSonic VFD725w-50P/VFM735w-51P... -
Page 26: Setting Time
Off: Disables the alarm clock function. Every: The alarm clock will start to ring at the preset time everyday. Once: The alarm clock will start to ring at the preset time once. Touch the [ ] button to confirm. ViewSonic VFD725w-50P/VFM735w-51P... -
Page 27: Displaying Calendar (For Vfm735W-51P Only)
You can switch your Digital Photo Frame to Calendar mode that the current date and time is displayed on the screen with a slide show in thumbnail. ViewSonic Select the Calendar icon in the main screen and touch the [ ] button. -
Page 28: Frequently Asked Questions
The file formats on your card might not be supported (only JPEG pictures are accessible). Provide files with the supported JPEG. Note: Some digital cameras save images into non-standard formats. Please refer to the operating manual of your camera for specifics. ViewSonic VFD725w-50P/VFM735w-51P... - Page 29 Auto-on or Auto-off time. If the time has already passed for the day, it will start entering Auto-on or Auto-off status at the specified time from the next day. What is the best picture resolution displayed on the screen? • The best resolution is 800*480 and the max picture resolution of this Digital Photo Frame is 8000*8000 pixels. ViewSonic VFD725w-50P/VFM735w-51P...
-
Page 30: Specification
JPEG, Maximum resolution: 8000*8000 pixels Supported audio format MP3: Bit rate 32~320Kbps (CBR, VBR) (For VFM735w-51P only) MPEG-1(MP@ML), MPEG-4(ASP, Xvid Compliant), M-JPEG(up to VGA, 30fps) (For Supported video format VFM735w-51P only) -10℃ ~ 40℃ Operating temperature Dimension 210*160*28.6mm Weight 453.2g ViewSonic VFD725w-50P/VFM735w-51P... -
Page 31: Customer Support
Customer Support For technical support or product service, see the table below or contact your reseller. Note: You will need the product serial number. Country/Region Austria Belgium Bulgaria Czech Republic Denmark Estonia Finland France Germany Greece Hungary Republic of Ireland Italy Latvia ViewSonic Web Site www.viewsoniceurope.com/aus/ www.viewsoniceurope.com/befl/ www.viewsoniceurope.com/befr/ www.viewsoniceurope.com/ www.viewsoniceurope.com/ www.viewsoniceurope.com/dk/ www.viewsoniceurope.com/ www.viewsoniceurope.com/fi/ www.viewsoniceurope.com/fr/ www.viewsoniceurope.com/de/ www.viewsoniceurope.com/ www.viewsoniceurope.com/ www.viewsoniceurope.com/uk/ www.viewsoniceurope.com/it/ www.viewsoniceurope.com/lv/ Telephone 0150 159 6005... - Page 32 Portugal www.viewsoniceurope.com/ Slovak Republic www.viewsoniceurope.com/ Slovenia www.viewsoniceurope.com/ Russia www.viewsoniceurope.com/ru/ Spain www.viewsoniceurope.com/es/ Sweden www.viewsoniceurope.com/se/ Switzerland www.viewsoniceurope.com/ch/ Ukraine www.viewsoniceurope.com/ United Kingdom www.viewsoniceurope.com/uk/ Taiwan http://www.viewsonic.com.tw/ Singapore http://www.viewsonic.com.sg/support/ ViewSonic +37 037 466191 40 6661 5618 053 484 9308 00 389 246 1889 +22 57 77 38 +48 61 879 8993 21359 1423 421 244 648 151 + 386 839 4617 095 7258 106 913 496 534 08 5792 9045 +41 52 624 0128 +380 44 239 99 99 0207 949 0307 0800-061-198...
-
Page 33: Limited Warranty
R epair or attempted repair by anyone not authorized by ViewSonic. c. C auses external to the product, such as electric power fluctuations or failure. U se of supplies or parts not meeting ViewSonic’s specifications. Normal wear and tear. A ny other cause which does not relate to a product defect. 3. A ny product exhibiting a condition commonly known as “image burn-in” which results when a static image is displayed on the product for an extended period of time. How to get service: 1. F or information about receiving service under warranty, contact ViewSonic Customer Support (please refer to Customer Support page). You will need to provide your product’s serial number. 2. T o obtain warranted service, you will be required to provide (a) the original dated sales slip, (b) your name, (c) your address, (d) a description of the problem, and (e) the serial number of the product. 3. T ake or ship the product freight prepaid in the original container to an authorized ViewSonic service center or ViewSonic. 4. F or additional information or the name of the nearest ViewSonic service center, contact ViewSonic. ViewSonic Limited Warranty VIEWSONIC Digital Photo Frame VFD725w-50P/VFM735w-51P... - Page 34 Limitation of implied warranties: There are no warranties, express or implied, which extend beyond the description contained herein including the implied warranty of merchantability and fitness for a particular purpose. Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. D amage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of profits, loss of business opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages. 2. Any other damages, whether incidental, consequential or otherwise. 3. Any claim against the customer by any other party. 4.3: ViewSonic DPF Warranty DPF_LW01 Rev. 1A 06-20-08 ViewSonic VFD725w-50P/VFM735w-51P...
