5.4
Bias-T
Table 5
provides typical specifications for the Bias-T.
CATEGORY
RF Path
DC Path
Physical
Environmental
Quality
Lightning
Protection
Table 5. Bias-T Specification
PARAMETER
Frequency Rangy (MHz)
Insertion Loss (max)
Return Loss (min)
Power Handling (max)
Isolation (RF to DC port)
Inter modulation (3rd order) 2x20W tones
DC Input Voltage
Input Current
DC Path Resistance
Dimension (HxWxD) mm
Weight
Color
Housing
Operating Temperature
Storage Temperature
Outdoor Protection
MTBF
Current Peak
Raising Time (10–90)
Peak Half Voltage Time 50–50)
ADCP-75-214 • Issue 2 • September 2006
SPECIFICATION
800–2200
0.2 dB
19 dB
500W RMS
> 30 dB
<–108 dBm
5–24 V
0–2 A
< 1 Ohm
55.5 x 95.0 x 40.0mm
(2.2 x 3.7 x 1.6 inches)
0.3 Kg (0.7 lbs.)
Gray Metallic
Aluminum
–40 to +65º C (–40°F to +149°F)
–40 to +70º C (–40°F to +158°F)
IP65
500,000 hours
10 KA
8 ns
20 ns
© 2006, ADC Telecommunications, Inc.
Page 21
