Specification - Cellinx CamPilot MR902 User Manual

Specification

Items
Video Compression
Audio Streaming
External I/O
Network
Sof tware
Operating
Power
Phy sical
Case
Dimension
▶ Top
▶ Section
Compression Ty pe
Video Input
Resolutions
Bitrate
Frame Rate
Streaming
Bi-Directional Audio
Audio Input Compression
Audio Line Input
Audio Output Compression
Audio Line Output
RS232
Digital Input
Digital Output
RS422
SD Card
Factory Def ault Button
SD Card LED
LAN LED
Power LED
Ethernet
Protocol
Web Browser
SDK
Security
Temperature
Power Requirement
Power Consumption
Dimensions
Weight
Material
H.264(MPEG4 AVC) Baseline@L3.0 / MJPEG
D1 / 4CIF / VGA / CIF / QVGA / QCIF
30/25 (NTSC/PAL) f ps @ all resolutions f or each channel
H.264 Dual Stream or Simultaneous H.264 and MJPEG
Two way , f ull duplex (Stereo)
2ch, Line lev el input. Nominal 0-dB input lev el is 1.0 VRMS. Gain of –34.5 dB to 12 dB.
1ch, Line lev el output. Nominal output lev el 1.0 VRMS.
2ch. (Dry Contact N.O. / N.C.)
2ch. (Relay Switching - Nominal Voltage 5VDC, 1A)
1ch. f or external dev ices control (PTZ driv er etc.)
SD/SDHC card interf ace support
Restore to def ault setting (Network, Password and etc)
Ethernet(10/100 Based-T), RJ-45 Connector
TCP, IP, HTTP, DHCP, FTP, DNS, DDNS, NTP, ICMP,
SNMP, SMTPE, UPnP, RTP, RTSP, Onv if
MD5 Password / iptables (f irewall)
0°C ~ 40°C / 32°F ~ 104°F
169(W) x 117(D) x 31(H) mm
4
Specifications
2ch
32Kbps ~ 6Mbps
G.711 / G.726
G.711 / G.726
RS232C Lev el
SD card status Indicator
LAN status Indicator
Power status Indicator
IE 8.0 or abov e
Cellinx SDK 4.0
DC 12V / 1.0A
300mA (Nominal)
345g
Aluminum
▶ Side
