Full HD IP Box Camera
CamPilot STH120
User Manual
Overview
CamPilot STH120
(Lens are sold separately)
Accessories
Before installing and using the product,
please read this manual carefully.
Be sure to keep it handy for later reference.
•
1/3" Panasonic CMOS
•
True Day & Night / 3D DNR / WDR / BLC / DEFOG
•
C/CS Mount, DC Iris Lens Support
•
1920x1080 resolution at 30FPS
•
Multi-codec support : H.264 / MJPEG / MPEG-4
•
Multi-stream with variable resolution & frame
-
1st stream : H.264 or MJPEG @ 1080p~VGA
-
2nd stream : H.264, MPEG4 or MJPEG @ D1~CIF
-
3rd stream : H.264, MPEG4 or MJPEG @
CIF~QCIF
•
Stream based motion detection
•
Multi-codec audio support : G.711 / G.726
•
Two-way audio supported (Full Duplex)
•
Alarm Input (1ch) / Output (1ch)
•
SD / SDHC card support
•
Power : DC 12V, 1A (PoE)
An adaptor and a LAN cable are not included in the product
1
Advertisement
Table of Contents
Related Manuals for Cellinx CamPilot STH120
Summary of Contents for Cellinx CamPilot STH120
- Page 1 Full HD IP Box Camera CamPilot STH120 Before installing and using the product, please read this manual carefully. User Manual Be sure to keep it handy for later reference. Overview • 1/3" Panasonic CMOS • True Day & Night / 3D DNR / WDR / BLC / DEFOG •...
- Page 2 ■ Mounting Surface The mounting surface material must be strong enough to support the camera. ■ CamPilot STH120 can be used for surveillance purpose. Be thoroughly informed of related regulations prior to installation to ensure compliance with such regulations...
- Page 3 Overview Features and Appearance CamPilot STH120 is an IP Camera that transmits real-time high-resolution digital video and audio data with H.264 high compression rate over Internet or Intranet. ▶ Front ▶ Side DC Iris connector C/CS mount ring ▶ Top...
-
Page 4: Specification
SNMP, SMTPE, UPnP, RTP, RTSP, Onvif Softw are Embedded OS (Linux) Web Brow ser IE 8.0 or above Cellinx SDK 4.0 Security MD5 Passw ord / iptables (firew all) / SSL Operating Temperature -10°C ~ 55°C / 14°F ~ 131°F... - Page 5 Specification Dimension ▶ Top ▶ Side ▶ Rear ▶ Front Monitoring PC Requirements Item Specification Processor Pentium Core2 Duo or more 2GB or more Graphic Card 512MB or more Monitoring Windows 2003 / XP / Vista / 7 Monitor Resolution 1024 X 768 pixels or more Network 10/100 Base-T LAN...
-
Page 6: Basic Connection
Connection Basic connection (1) DC 12V – power, DC 12V 1A adaptor ( , auto switching) No polarity (When the PoE is used, the power connection is not necessary.) (2) LAN / POE – ETHERNET, LAN cable (RJ45 jack, Auto detection of cross/direct cable) (Please, refer to the standard of “IEEE 802.3af”) Expert connection (1) AUDIO IN / OUT... -
Page 7: Setting An Ip Address
Network Setting an IP address Change the network setting value with the program “NVTManagement” 1. NVTManagement execution • Execute the file “NVTManagement.exe” 2. IP address set-up • Click the button “NVT Scan”, select the model. • Input the IP address, Subnet Mask, Gateway and DNS Server IP address, click the button “Apply”... - Page 8 Network 3. Accessing to CamPilot STH120 with a web browser Open a web browser on a monitoring PC and enter the IP address assigned to a CamPilot STH120 as following Example> http://192.168.1.2 • The page as below shows up after the connection is completed.
