C a m P i l o t M R 3 1 0
Va n d a l P r o o f I P D O M E C A M E R A
M R 3 1 0 - C P 9 3 H / C P 9 3 H - 1 8 I R
M R 3 1 0 - C P 9 5 H / C P 9 5 H - 1 8 I R
Instruction Manual
Before installing and using the camera, please read
this manual carefully.
Be sure to keep it handy for later reference.
CamPilot MR310
INSTRUCTION MANUAL
N
V
S
(Network Video Streamer)
User's Guide
CamPilot MR310
Instruction Manual
20100802
1 / 56
Advertisement
Table of Contents
Related Manuals for Cellinx CamPilot MR310-CP93H
Summary of Contents for Cellinx CamPilot MR310-CP93H
- Page 1 INSTRUCTION MANUAL (Network Video Streamer) User’s Guide C a m P i l o t M R 3 1 0 Va n d a l P r o o f I P D O M E C A M E R A M R 3 1 0 - C P 9 3 H / C P 9 3 H - 1 8 I R M R 3 1 0 - C P 9 5 H / C P 9 5 H - 1 8 I R Instruction Manual...
- Page 2 • Simple environment setting - Internet Explorer or Firefox can be used to modify user environment set in the CamPilot MR310. • Embedded Linux O/S - CamPilot MR310 uses cutting-edge networking technology. Cellinx Systems optimized Linux for this CamPilot MR310 operation and runs it with 32bit RISC CPU. CamPilot MR310...
- Page 3 INSTRUCTION MANUAL PRECAUTIONS ■ Do not open or modify Do not open the case except during maintenance and installation, as it may be dangerous and cause damages. ■ Do not put objects inside the unit Make sure that no metal objects or flammable substances get inside the camera. It could cause fire, short-circuits or damages.
-
Page 4: Troubleshooting
INSTRUCTION MANUAL TROUBLESHOOTING Before sending the camera out for repair, check the items below. If the problem persists after checking these items, contact your service center. ▲ If no image appears - Is the LAN cable attached securely? - Are the power and voltage normal? - Has the iris of the lens inside the camera been adjusted correctly? (with the level volume) - Is there adequate illumination? -
Page 5: Dimension (Mm)
INSTRUCTION MANUAL DIMENSION (mm) CamPilot MR310 5 / 56... -
Page 6: Installation
INSTRUCTION MANUAL INSTALLATION 1. Use the supplied L-wrench to remove the four fixing screws (B) of dome cover (A). 2. Align the camera unit with the surface of the ceiling, make marks on the ceiling in the places where the screw holes are to be drilled, and then drill the four holes. - Page 7 INSTRUCTION MANUAL CONNECTION ▲ CONNECTION (Ⅰ) DC12V / AC24V LAN(RJ45) 2nd VIDEO CAUTION : Check for polarity when using a DC 12V/ AC24V power supply. ▲ CONNECTION (Ⅱ) LAN(PoE) 2nd VIDEO CAUION : Check for polarity when using a POE(Power of Ethernet) power supply. - Support: IEEE 802.3af CamPilot MR310 7 / 56...
-
Page 8: Ethernet Connection
INSTRUCTION MANUAL ▲ ETHERNET CONNECTION Connect Ethernet cable to the network CamPilot MR310 8 / 56... -
Page 9: Camera Setting
INSTRUCTION MANUAL CAMERA SETTING ▲ LENS ADJUSTMENT & GIMBAL ADJUSTMENT <DV LENS TYPE> <DV LENS & IR LED TYPE> 1. Adjust the panning(360˚) and tilt(90˚) position. (DV LENS TYPE) Adjust the panning(360˚) and tilt(70˚) position. (DV LENS & IR LED TYPE) 2. -
Page 10: Gimbal Adjustment
INSTRUCTION MANUAL ▲ GIMBAL ADJUSTMENT <Omni focus LENS & IR LED TYPE> <Omni focus LENS TYPE> 1. Adjust the panning(360˚) and tilt(90˚) position. (Omni focus LENS TYPE) Adjust the panning(360˚) and tilt(70˚) position. (Omni focus LENS & IR LED TYPE) CamPilot MR310 10 / 56... - Page 11 INSTRUCTION MANUAL ▲ CAMERA SETTING FOR SIDE OSD CONTROL BOARD CON1 FUNCTIONAL OF CONTROL BOARD [1] Functional control of O.S.D(On Screen Display)(SW2) [2] Functional of VIDEO OUT(2ND) (CON1) [3] Functional when using PAN FOCUS LENS [OPTION] (1) You push SW1 for 2 seconds. And then the function of SW2 changes from OSD control key to zooming control key.
-
Page 12: Remote Control Instructions
INSTRUCTION MANUAL ▲ REMOTE CONTROL Instructions: 1) Set the camera ID in OSD menu. (The default setting is “001”) NOTE : If the camera ID is modified, the new camera ID must be set and power on / off. Then the camera is able to recognize the new ID. 2) Press the “KEY”... -
Page 13: Osd Menu Settings
INSTRUCTION MANUAL ▲ OSD MENU SETTINGS 1 . E X P O S U R E 6 . P R I V A C Y LENS MASK 1 E. SHUTTER MASK 2 MASK 3 MAX_DR MASK 4 MASK 5 STARLIGHT MASK 6 2 . -
Page 14: Installation Process
INSTRUCTION MANUAL NETWORK CONFIGURATION ▲ INSTALLATION PROCESS 1) Connecting power supply, LAN and audio cables to a CamPilot MR310. • DC 12V - Power (Adapter , DC 12V/1000mA) • ETHERNET - LAN cable (RJ45 Jack) - A client PC or a network devices is connected to the CamPilot MR310. •... - Page 15 INSTRUCTION MANUAL 2) Executing NVR program Installation on PC (Ex: NVS 4.1 Installation) - On each installing process, click ‘Yes’ or ‘Next’ to install by default. - The programs like ENCP, NDC Manager, NDC Viewer and etc. are installed after the whole process. ▶...
- Page 16 INSTRUCTION MANUAL 4) Scan CamPilot MR310 and network configuration - Click “Scan Cameras” button to search CamPilot MR310, Network video streamer, on the local network where ENCP runs. - The Camera List displays the basic information of the searched CamPilot MR310 on the local network.
-
Page 17: Using Web Browser
INSTRUCTION MANUAL Using Web Browser ▲ OVERVIEW • User can monitor the video and audio data and manage CamPilot MR310 through a web browser over internet. • User can select a type among encoder mode and decoder mode through a web browser. - Page 18 INSTRUCTION MANUAL ▲ CONNECTION • To connect to a CamPilot MR310, type the IP address that is given to the CamPilot MR310 on the address window of a web browser as below. (Refer to “ENCP 2.0” program manual to set IP address of the CamPilot MR310) http:// (CamPilot MR310) IP Address) ►...
- Page 19 INSTRUCTION MANUAL Setting page login : Type the ID and Password of the administrator and click “Setting” button. Monitoring page login : Type the ID and Password of the administrator and click “Monitoring” button Guest login : Click “Guest Login” to enter the monitoring page of guest account Client’s IP : Displays the IP address of the connected PC.
- Page 20 INSTRUCTION MANUAL • Note for Monitoring Page - When first connecting to monitoring page, click “Yes” to download ActiveX if “security warning” window appears. (CASE ①) ① ① ② - Click the yellow information bar to download ActiveX control. CamPilot MR310 20 / 56...
- Page 21 INSTRUCTION MANUAL - User can download and install ActiveX Setup manually if the information bar does not appear. (CASE ②) - Click “Run” button to install ActiveX file manually (NVSOCX.exe) ► ActiveX Setup window CamPilot MR310 21 / 56...
- Page 22 INSTRUCTION MANUAL ▲ MONITORING Monitoring Page • 1st / 2nd / 3rd Stream - Select a Stream to monitor - If the stream button is inactivated, check the video setting of “server setting page”. • Snapshot - Capture a JPEG Image of current video stream (JPG file creation route : C:/root) CamPilot MR310 22 / 56...
- Page 23 INSTRUCTION MANUAL • REC - Record the video of current video stream (AVI file creation route : C:/root) • Full - Extend the image of current video stream to fit monitor size. • Resolution - Display a current resolution. - User can select other resolution. (If CamPilot MR310 is rebooted, the resolution on the monitoring page is initialized to the designated value of “server setting page”.) - Changing the resolution is not available on a guest account.
- Page 24 INSTRUCTION MANUAL • D/O - Digital Out - This controls the device that is connected to CamPilot MR310. • Bitrate - Display the bitrate of current video stream. - User can select other bitrate. (If CamPilot MR310 is rebooted, the bitrate on the monitoring page is initialized to the designated value of “server setting page”.) - Changing the bitrate is not available on a guest account.
-
Page 25: Server Setting
INSTRUCTION MANUAL ▲ SERVER SETTING - To apply the changed setting, reboot CamPilot MR310. (Click Reboot on the menu) • Status - This is the initial page of Server Setting. - This shows network status, model information, network traffic status, connection list and system log. - Page 26 INSTRUCTION MANUAL • Network Status - MAC Address: Media Access Control Address of CamPilot MR310 (Unchangeable) - IP Address: the assigned IP Address of CamPilot MR310 - Subnet Mask: Subnetwork of the IP address belongs to. (Use the value to fit the network environment) - Gateway: Gateway Address (Use the value to fit the network environment) - Default DNS: IP Address of Default DNS server •...
- Page 27 INSTRUCTION MANUAL • Basic > Network (Wired) - User can set Network Information of CamPilot MR310: IP Address, Subnet Mask, Gateway, Default DNS ① Static IP - IP Address: Ask network administrator for an appropriate address - Subnet Mask / Gateway / Default DNS : Ask network administrator - After setting, click “OK”...
- Page 28 INSTRUCTION MANUAL ② Dynamic IP - If DHCP server is on the local network and you intend to allocate IP address dynamically, use this method - Select Dynamic IP tab and click “OK” button, and reboot CamPilot MR310. - If you want to select Dynamic IP, set Dynamic DNS to access CamPilot MR310. CamPilot MR310 28 / 56...
- Page 29 INSTRUCTION MANUAL ③ PPPoE - Use in case that the network supports PPPoE like xDSL - Ask ISP(Internet Service Provider) for details - User ID : xDSL user ID - User Password : xDSL user password - Service Name : Service name of ISP - MTU : Maximum transmission unit of data - IP address of DNS sever can be set to create automatically - If your xDSL does not use static IP type, you should use Dynamic DNS setting...
- Page 30 INSTRUCTION MANUAL • Basic > Video - User can select video streaming type (Encoder or Decoder mode) - CamPilot MR310 support only an Encoder mode ① Encoder Mode CamPilot MR310 30 / 56...
-
Page 31: Video Setting
INSTRUCTION MANUAL Video Setting - Preview : User can check the current video setting through the preview images. (1st / 2nd / 3rd stream selectable) - Video Compressed Type: H.264 / MJPEG (Compression type of 3rd stream : MPEG4) - Resolution : QQVGA / QCIF / QVGA / CIF / VGA / 4CIF / D1 (Resolution of 3rd stream : QCIF fixed) - Bitrate Type : CBR / VBR •... - Page 32 INSTRUCTION MANUAL • Basic > Audio Server to PC Audio Option - Audio Type : Mono (Fixed) - Audio Codec : G.711 / G.726 - Sampling Rate : 8kHz / 32kHz - Volume : -34.5~12dB CamPilot MR310 32 / 56...
-
Page 33: Digital Input
INSTRUCTION MANUAL • Basic > Event ① Digital Input CamPilot MR310 33 / 56... -
Page 34: Digital Output
INSTRUCTION MANUAL Common - Sensor Type: Select a type out of two types. Preset - Preset Enable: enables the CamPilot MR310to send the preset signal to the connected camera which supports preset function - Preset Number: preset number that assigned to the camera which supports preset function Digital Output - Digital Output Enable: enables the CamPilot MR310to send the digital signal to... -
Page 35: Motion Detection
INSTRUCTION MANUAL Motion Detection ② Preset : Same as “Digital Input” setting Digital Output : Same as “Digital Input” setting FTP : Same as “Digital Input” setting SMTP (e-mail) : Same as “Digital Input” setting CamPilot MR310 35 / 56... - Page 36 INSTRUCTION MANUAL ③ Periodic Timer Common - Periodic Timer Enable : enables the CamPilot MR310 to send the signal to the client PC periodically - Time Interval : means the period (sec.) Preset : Same as “Digital Input” setting form Digital Output : Same as “Digital Input”...
- Page 37 INSTRUCTION MANUAL • Basic > Date / Time ① Current Time Set Date / Time - Server Time : the time that the CamPilot MR310 keeps internally - New Date / Time: user can assign the specific time voluntarily. CamPilot MR310 37 / 56...
-
Page 38: Time Server
INSTRUCTION MANUAL ② Time Server Time Server - Enable : enables the time of CamPilot MR310 synchronize with time server periodically. - Interval : means the period (sec.) - Time zone: user can select a time zone - Daylight Saving Time : Check this box in using daylight saving time - Time Server: user can assign a Time Server to apply the current time to CamPilot MR310 - After setting, click the “OK”... - Page 39 INSTRUCTION MANUAL • Basic > OSD (On Screen Display) Text Color - Background Color : Select a color of background - Foreground Color : Select a color of text - Transparency : 0~10 CamPilot MR310 39 / 56...
- Page 40 INSTRUCTION MANUAL - Font Size : Normal / Big - Date Enable : display date - Time Enable : display time - Channel Enable : display channel name - X Axis: Input a point on the coordinate - Y Axis: Input a point on the coordinate Logo - This means the image that is displayed on OSD of the transferred image.
- Page 41 INSTRUCTION MANUAL • Expert > Camera Setting Menu - Access to the OSD menu of CamPiot MR310. Direction Keys - Operate the OSD setting menu of CamPiot MR310. - Select a value on the OSD setting menu of CamPiot MR310. ※...
- Page 42 INSTRUCTION MANUAL • Expert > PTZ / RS232 - CamPilot MR310 does not support PTZ and RS232 function. Channel 1 - Channel Name : the channel name of OSD - Channel Model (PTZ model) : Select a model of the connected PTZ camera or receiver - Channel ID (Rx Address) : the Rx address of the connected PTZ camera or receiver - Baud rate / Data bits / Parity / Stop bits...
-
Page 43: Record Setting
INSTRUCTION MANUAL • Expert > Local Storage (Optional) - Local Storage function is automatically mounted when inserted into the Micro-SD card slot. Status - Display the total space, used space and free space of Micro-SD Card. Record Setting - Mode : Select a record type (OFF / Full Recording / Event Recording) - Select a video stream of CamPilot MR310 (1st / 2nd / 3rd Stream) - Select a overwrite setting of the local storage (ON/OFF) File list... - Page 44 INSTRUCTION MANUAL • Expert > Port - Web Port: Default is 80 - FTP Port: Default is 21 CamPilot MR310 44 / 56...
-
Page 45: Security Level
INSTRUCTION MANUAL • Expert > Security Security Level - HIGH : Only connections from the local area are permitted - MEDIUM : Video and Audio connections from any place and setting from the local area permitted. - LOW : All connections from any place permitted CamPilot MR310 45 / 56... -
Page 46: Guest Permission
INSTRUCTION MANUAL • Expert > Account Account - The password amendment of administrator account is available. - The administrator can add up to 5 users and modify the properties. Guest Permission - This is to determine the guest permission for access to the CamPilot MR310 - At guest account, video and audio monitoring is permitted. - Page 47 INSTRUCTION MANUAL • Expert > DDNS - DDNS is the function that matches an IP address and a host name. - If a CamPilot MR310 has the dynamic IP address, the host name by DDNS (Dynamic Domain Name Service) must be used instead of the IP address for the credibility of the network connection.
- Page 48 INSTRUCTION MANUAL DynDNS - For use of “ddns.nu” register at www.dyndns.com/ - Type the registered DDNS ID, DDNS Password, Host name and Interval for updating and click “OK” button and reboot the CamPilot MR310. ▶ Main page of “DynDNS” CamPilot MR310 48 / 56...
- Page 49 INSTRUCTION MANUAL ddns.nu - For use of “ddns.nu” register at www.ddns.nu - Type the registered DDNS ID, DDNS Password and DDNS handle and click “OK” button and reboot the CamPilot MR310 ▶ Main page of “ddns.nu” ProutDNS - ProutDNS is a set of PHP scripts to create your own Dynamic DNS service. - Type the DDNS server, the registered DDNS ID, DDNS Password, Host name and Interval for updating and click “OK”...
- Page 50 INSTRUCTION MANUAL • Expert > UPnP UPnP - Enable : Check the box to use UPnP(Universal Plug and Play) of CamPilot MR310 - Friendly name : User can change the friendly name of CamPilot MR310 CamPilot MR310 50 / 56...
-
Page 51: Input Setting
INSTRUCTION MANUAL • Expert > Motion Detect Input Setting - Check “Enable” box for use of motion detection - Detect Area: if the detection area is selected, it changes to green (User can check preview image assuming JPEG Capture enable on the video setting page.) - Sensitivity : 1~30 (Maximum sensitivity in case of the value “1”) CamPilot MR310 51 / 56... -
Page 52: Firmware Update
INSTRUCTION MANUAL • Expert > Firmware Update Language - Language Select : Select a language file (After that, it is required to refresh the web browser. Please push F5 button.) - Language File : Add a language file Firmware Update - Uploads the newly firmware after clicking the browsing button and finding a new firmware. - Page 53 INSTRUCTION MANUAL Logo Upload - Changes the logo image file. - The process is same as “Firmware Update” - Use GIF file (Maximum size : 567x175) OSD Logo Upload - Changes the logo image on OSD. - The process is same as “Firmware Update” - User have to use file name by “osd_logo.bmp”...
- Page 54 INSTRUCTION MANUAL • Expert > Report Report - User can check all of setting of CamPilot MR310. - User or installer can memo on the report page. - User or installer can print out this pages and use in various usages •...
-
Page 55: Common Specifications
INSTRUCTION MANUAL SPECFICATION ▲ Common Specifications MODEL CamPilot MR310 GENERAL SPEC NTSC ARM9E 240MHz Flash Memory System 64MB Embedded Linux Compression Type H.264 / MJPEG / MPEG-4 Resolutions D1 ~ QQVGA Bitrate 32Kbps ~ 8Mbps Video Frame Rate 30/25 (NTSC/PAL) fps in all resolutions Streaming 1st stream : H.264 or MJPEG @ all resolutions 2nd stream : H.264 or MJPEG @ all resolutions... -
Page 56: Camera Specifications
INSTRUCTION MANUAL ▲ Camera Specifications MODEL CamPilot MR310 GENERAL SPEC NTSC 1/3" Sony Super HAD Ⅱ CCD Type Pixels 410K 470K 520 TV Line [Color] Resolution 560 TV Line [TDN (BW)] Color : 0.14Lux [F1.2, 30IRE] Min. Illumination B/W(TDN) : 0.01Lux [F1.2, 30IRE] CP93H IR LED ON : Zero Lux (Optional) 50dB or more(AGC off)
