ViewSonic E90f+ User Manual page 8

Do the following to adjust the screen image:
To display the Main Menu, press button [1].
1
MAIN MENU 1
CONTRAST/BRIGHTNESS
H. SIZE/POSITION
V. SIZE/POSITION
ZOOM
PINCUSHION/PIN BALANCE
TRAPEZOID/PARALLEL
TILT
1
:EXIT
To select a control you want to adjust, press the arrow buttons on the front
2
control panel of your monitor and scroll through the choices. When the
control you want is highlighted, press button [2].
NOTE: Some controls on the Main Menu are listed in pairs, such as
Contrast/Brightness. Display control screen (sample shown in step 3 below).
Press button [2] to toggle to the next control in the pair.
To adjust the selected control, such as
3
press the arrow buttons.
To save the control setting and Exit the menu press button [1] twice.
4
SELECT:
2
CONTRAST
MAIN MENU 2
DEGAUSS
VIEWMATCH COLOR
OSD POSITION
MOIRE REDUCTION
LANGUAGE
MEMORY RECALL
AUTO SIZING
VIEWMETER
1
:EXIT
in the sample below,
ViewSonic
SELECT: 2
E90f+ 7
