Use the Wireless TROLL Com to connect an In-Situ instrument to a Bluetooth-enabled mobile
device and the VuSitu mobile app. The Wireless TROLL Com doesn't have internal data storage.
It allows data transfer between an instrument and VuSitu (or Win-Situ 5 via a USB cable).
1
USB connection
Plug your Wireless TROLL Com
into a PC for charging or setup.
6
Connection status indicator
Flashing red = The Wireless
TROLL Com, instrument, and
Bluetooth-enabled device are
not connected.
Continuous red = The Wireless
TROLL Com is connected to an
instrument, but not connected
to a Bluetooth-enabled mobile
device.
Flashing green = The Wireless
TROLL Com is connected to the
Bluetooth-enabled device, but is
not connected to an instrument.
Continuous green = The
Wireless TROLL Com, instrument,
and Bluetooth-enabled device
are connected.
5
Cable connector
Attach an instrument to the Wireless TROLL Com with a Rugged Cable
before connecting to VuSitu. When switching instruments, you may need to
turn the Wireless TROLL Com off and on again.
Information subject to change without notice. In-Situ, In-Situ logo, Baro Merge, BaroTROLL, HERMIT, HydroVu™, iSitu,
Pocket-Situ, RDO, RuggedCable, RuggedReader, SmarTROLL™, TROLL, VuSitu, and Win-Situ are trademarks or registered
trademarks of In-Situ Inc.
2016. All rights reserved. This product may be covered by patents identified at www.in-situ.com/
©
patents
Wireless TROLL Com/Wireless Rugged TROLL Com
2
Wireless Rugged
TROLL Com
Dust cover for USB connection
3
On/Off button
Press the button once to turn
the device on or off.
4
Battery charge status
indicator
2020-06-29 | 0031242
100% - 90%
90% - 75%
75% - 50%
50% - 25%
Less than 25%
Advertisement
Related Manuals for In-situ Wireless TROLL Com
Summary of Contents for In-situ Wireless TROLL Com
- Page 1 Use the Wireless TROLL Com to connect an In-Situ instrument to a Bluetooth-enabled mobile device and the VuSitu mobile app. The Wireless TROLL Com doesn’t have internal data storage. It allows data transfer between an instrument and VuSitu (or Win-Situ 5 via a USB cable).
- Page 2 A fully-charged communication device will run for up to 40-50 continuous hours. Avoid full discharges and charge the battery each use. Do not store the Wireless TROLL Com in temperatures above 86 F/30 C. Connecting to VuSitu with a Wireless TROLL Com You must have the VuSitu mobile app to use the instrument with a mobile device.
- Page 3 Communications radio firmware. button and then choose the correct Com Port. Click check mark button. Default communication settings The following default communication settings are most common for In-Situ instruments: • Baud: 19200 • Data bits: 8 • Parity bits: Even •...
- Page 4 300 to 1100 mbar Resolution 0.1° C 0.01 mbar Sensor type Fixed Fixed Response time < 30 seconds Instantaneous in thermal equilibrium Units of measure Celsius or Fahrenheit psi, kPa, bar, mbar, mmHg, inHg, Torr, atm Method EPA 170.1 Piezoresistive 1-970-498-1500 www.in-situ.com...
