SSV Works WC3-SP82K Instructions Manual

Textron wildcat xx side 8” subwoofer pods

Advertisement

Quick Links

SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in material or workmanship.
All SSV Works Electronics are covered by a limited 1 year warranty against defects in material or workmanship.
All Kicker Speakers are covered by a limited 1 year warranty against defects in material or workmanship. All
Kicker Amplifiers are covered by a limited 2 year warranty against defects in material or workmanship. Labor for
replacement of defective components is not covered. Contact SSV Works for further warranty information.
TOOLS FOR INSTALLATION
PARTS LIST IMAGES
1. Driver & Passenger Subs - Pair
5. Bracket "B" x2
9. Amp power wire x1, Fuse
Holder with 40A Fuse and
Battery Terminal Cable x1
For ease of installation, we recommend removing the Stage 1 kick panel 6.5" speaker pods from the vehicle prior to installing the
WC3-SP82K. If you do not have the 6.5" speaker pods installed in your vehicle, skip to Step D.
- T25 & T30 Torx - 8mm socket
2. M6 x 1.0 Screws and
Washers x12
D
R
I
V
E
R
6. Driver/Passenger Brackets
10. B-H1912 24" audio extension
harness x1 and B-H1389 69"
audio extension harness x1
- 8mm & 10mm wrench
3. M6 Hex Head Bolts &
Washers x4
P
A
S
S
E
N
G
E
R
7. Large Washer x4
11. M6x1.0 screw & nut x1
WC3-SP82K
Textron Wildcat XX
Side 8" Subwoofer Pods
Please read and understand these
!
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
- #2 Phillips screwdriver
4. Backet "A" x2
8. Loaded amp tray with Kicker
500.1 amp
12. M5 screw x4
- Wire cutters

Advertisement

loading
Need help?

Need help?

Do you have a question about the WC3-SP82K and is the answer not in the manual?

Questions and answers

Summary of Contents for SSV Works WC3-SP82K

  • Page 1 For ease of installation, we recommend removing the Stage 1 kick panel 6.5” speaker pods from the vehicle prior to installing the WC3-SP82K. If you do not have the 6.5” speaker pods installed in your vehicle, skip to Step D.
  • Page 2 Stage 1 Kick Panel 6.5” speaker pod A. From underneath passenger side fender remove (8) T-30 screws as shown on the pictures. (Repeat on opposite side) C. Pull inner fender forward to expose F65 harness and (2) remaining B. From beneath the passenger side fender, remove (4) T30 screws and T30 torx screws that mount the pod (circled in pink).
  • Page 3 G. Remove the (1) T30 screw from the driver and passenger side on the rear of the center console. F. Remove the (6) T25 screws securing the grab handle to the vehicle. Separate the two halves of the grab handle and remove handle. Remove the (4) T30 screws from the driver and passenger front of the center console.
  • Page 4 J. Highlighted in pink are the bracket mounting points for the pod. Bracket for mounting point 3 is for the directional driver/passenger bracket. The bracket used is designated with a D driver or P passenger . K. Using the provided T30 torx screws and washers, mount the I.
  • Page 5 L. To hold the enclosure in place, screw in a factory T30 screw. Do not M. Use an 8mm socket with extension or nut driver to fasten provided tighten screw. 8mm screw and large washer through the factory mounting tab and into Bracket A.
  • Page 6 R. Locate the (4) mounting bosses on the backside of the SSV Works S. Align the MRB3 brain on the mounting bosses. Fasten the MRB3 amp tray. brain to the tray with the provided M5 Phillips screws. Then connect MRB3 Brain “LINE OUT Ext. amp trigger” to Kicker Amp 500.1 input.
  • Page 7 W. Using a scribe, mark the hole of the lower mounting tab into the X. Re-install the loaded amp tray, fasten the lower mounting tab with plastic. Once marked, remove the loaded amp tray and drill a ¼” provided (1) T30 screw, (2) large washers and (1) 10mm lock-nut. hole through the mark.
  • Page 8 Output. F1.Re-connect the MRB3 controller F2. Re-connect the power/ground F3. Re-connect the antenna. Route G1. Connect the Aux-in plug. to the brain. wire. the antenna wire under dash. © 2019 SSV Works, Oxnard, CA 93030 WC3-1K Rev. A 3-21-19...
