Summary of Contents for MasterForce 260-9516
- Page 1 1000 Peak Amp Lithium Ion Jump Starter and USB Power Source 260-9516 To Reduce The Risk Of Injury, User Must Read And Understand Operator’s Manual. Save These Instructions For Future Reference. 0099002184-02...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Symbols ................Page 3 Safety Information ................Page 4 Important Safety Instructions ............Page 5 Personal Safety Precautions............Page 5 Features ..................Page 6 Specifications .................Page 7 Replacement Parts .................Page 7 Charging the Internal Battery of the Jump Starter .......Page 7 Operating Instructions ..............Page 8 Maintenance and Storage ..............Page 9 Troubleshooting ................Page 9... -
Page 3: Safety Symbols
SAFETY SYMBOLS Some of the following symbols may be used on your jump starter. Please study them and learn their meaning. Proper interpretation of these symbols will allow better and safer operation of the jump starter. Symbol Name Designation/Explanation Volts Voltage Amperes Current... -
Page 4: Safety Information
SAFETY INFORMATION The purpose of safety symbols is to attract our attention to possible dangers. The safety symbols, and the explanations with them, deserve your careful attention and understanding. The symbol warnings do not by themselves eliminate any danger. The instructions and warnings they give are no substitutes for proper accident pre- vention measures. -
Page 5: Important Safety Instructions
1. IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS. 1.7 Place the jump starter as far away from the battery being jumped as the cables will permit. RISK OF EXPLOSIVE GASES. 1.8 Do not expose the jump starter to rain or snow. WORKING IN THE VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS. -
Page 6: Features
A battery can produce a short circuit generates, uses, and can radiate current high enough to weld a ring to radio frequency energy and, if not metal, causing a severe burn. installed and used in accordance with the instructions, may cause 2.6 Never smoke or allow a spark or flame harmful interference to radio com- in the vicinity of the battery or engine. -
Page 7: Specifications
4. SPECIFICATIONS Internal battery type ..............Lithium Ion Polymer Capacity ......................29.6Wh Nominal voltage ..................... 12V DC Micro USB input ..................5V DC, 2A USB output ....................5V DC, 2.4A Jump start ..............1000A peak/500A cranking Charging Temperature ............32°F - 122°F (0 ˚C - 50 ˚C) 5. -
Page 8: Operating Instructions
7. OPERATING INSTRUCTIONS JUMP STARTING A VEHICLE 3. Plug your device into the USB port. IMPORTANT: Using the jump starter with- 4. Turn on the USB device. out a battery installed in the vehicle will 5. When finished using the USB port, damage the vehicle’s electrical system. -
Page 9: Maintenance And Storage
8. MAINTENANCE AND STORAGE • Clean the clips and the case each time • Charge at least once every month, if you are finished using it. not in frequent use, to prevent over-dis- charge. • Charge battery to full capacity before storage. - Page 10 READY/FAIL LED BEHAVIOR Green LED lit solid Ready to jump start Red LED lit solid and buzzer sounds Short circuit protection continuously No LED lit and no buzzer beep Battery low voltage protection Flashing LED alternates between Green Reverse charging protection and Red Red LED flashing and buzzer sounds Reverse polarity protection...
-
Page 11: Warranty
® discretion, MASTERFORCE™ agrees to have the item or any defective part(s) repaired or replaced with the same or similar MASTERFORCE™ product or part free of charge, within the stated warranty period, when returned by the original purchaser with original sales receipt. Not withstanding the foregoing, this limited warranty does not cover any damage that has resulted from abuse or misuse of the Merchandise. - Page 12 © 2020 Menard, Inc., Eau Claire, WI 54703 05/2020...
