AIRREX INFRARED HEATER
USER MANUAL
Models AH-200i / 300i / 800i
AH-200i
• Thank you for purchasing an Airrex infrared heater!
• Please read the user manual carefully before operating the heater.
• Once you have read the user manual, ensure that it is stored in such a way that it is available to
everyone using the heater.
• Study the safety instructions with particular care before using the heater.
• These heaters have been adjusted to function in Northern European conditions. If you take the
heater to other areas, check the mains voltage in your country of destination.
• This user manual also includes instructions for activating the three-year warranty.
• Due to active product development, the manufacturer reserves the right to make changes to the
technical specifications and functional descriptions in this manual without separate notice.
• Please check and use always the latest user manual from our website rexnordic.com
AH-300i
AH-800i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AH-200i and is the answer not in the manual?

Questions and answers

Related Manuals for Airrex AH-200i

Summary of Contents for Airrex AH-200i

  • Page 1 AH-300i AH-800i • Thank you for purchasing an Airrex infrared heater! • Please read the user manual carefully before operating the heater. • Once you have read the user manual, ensure that it is stored in such a way that it is available to everyone using the heater.

  • Page 2: Table Of Contents

    • CLEANING SURFACES ·················································································47 • MAINTENANCE LOGBOOK ········································································48 ■ DIAGNOSING AND REPAIRING MALFUNCTIONS ····································49-51 • ERROR MESSAGES ·······················································································49 • WIFI PROBLEMS ····························································································51 ■ TECHNICAL SPECIFICATIONS AND CONNECTION DIAGRAM ·············52-53 • ENSURE SUFFICIENT VENTILATION ························································53 ■ AIRREX WARRANTY ························································································54-55 ■ TECHNICAL SUPPORT ····················································································56...

  • Page 3: Turvallisuusohjeet

    SAFETY INSTRUCTIONS The purpose of these safety instructions is to ensure the safe use of the Airrex heaters. Adherence to these instructions prevent the risk of injury or death and damage to the heating device as well as other items or premises.
  • Page 4 SAFETY INSTRUCTIONS Do not place your hands or any items Do not place any electrical devices or heavy inside the safety mesh. Touching the internal items on the heater. Items on the device components of the heater may cause burns or may cause malfunctions, electric shocks or an electric shock.
  • Page 5 SAFETY INSTRUCTIONS IMPORTANT THINGS TO NOTE BEFORE OPERATION ENSURE THE SAFETY USE ONLY HIGH-GRADE BIODIESEL OF THE HEATER’S LOCATION OR LIGHT FUEL OIL IN THE HEATER. • The vicinity of the heater must be free of flammable • The use of fuels other than light fuel oil or diesel materials.

  • Page 6: Heater Structure

    Control panel Heating element Intake air Burner Heat opening Heat reflector, Ignition unit reflector, rear side Fuel Flame sensor pump Heat reflector, Fuel Tilt sensor bottom gauge Fuel Power cord Fuel (220/230 V tank Fuel filter Fuel tank AH-200i AH-300i AH-800i...

  • Page 7: Remote Control

    HEATER STRUCTURE REMOTE CONTROL Selecting thermostat/ timer operation • Aim the end of the remote control towards the heater. Temperature or Shutdown timer on/ • Strong sunlight or bright neon or fluorescent lights may operating time disrupt the operation of the remote control. If you adjustment suspect that the lighting conditions may be causing problems, use the remote control right in front of the...

  • Page 8: Burner Structure

    HEATER STRUCTURE BURNER STRUCTURE BURNER MOTOR IGNITION UNIT AIR INTAKE WINDOW FOR VIEWING THE COMBUSTION CHAMBER FLAME DETECTOR FUEL PUMP FUEL HOSE BLEED SCREW SOLENOID FUEL FILTER...

  • Page 9: Operating Switches And Display

    HEATER STRUCTURE OPERATING SWITCHES AND DISPLAY 10. SHUTDOWN TIMER INDICATOR LIGHT 1. LED-DISPLAY The light indicates whether or not the shutdown timer is The display can be used to check the temperature, active. timer, error codes, etc. 11. FUEL GAUGE 2.

  • Page 10: Operating Instructions

    HOW T O U SE OPERATION & STOP OPERATING INSTRUCTIONS OPERATION & STOP ACTIVATION AND DEACTIVATION HOW T O U SE 2. SELECT THE DESIRED OPERATION TYPE USING "MODE" BUTTON. Heater will turn ON with "beep" sound, and automatically operate. 1.

  • Page 11: Thermostat Operation

    At t OPERATING INSTRUCTIONS HOW TO U S E HOW TO U S E HOW TO U S E THERMOSTAT OPERATION TEMPERATURE CONTROL TEMPERATURE CONTROL In this mode, you can set the desired temperature, after which the heater operates automatically and switches itself on This mode enables the user set the desired temperature, and once it is set, this heater works automatically with running and stop repeatedly This mode enables the user set the desired temperature, and once it is set, this heater works automatically with running and stop repeatedly as needed to maintain the set temperature.

  • Page 12: Timer Operation

    means, every 20min. means, every 20min. Operation and 5min. Operation and 5min. Pause Pause OPERATING INSTRUCTIONS 5. The repitition time can be set from 10min. to 55min. The operation is as much as setting time, and 5. The repitition time can be set from 10min. to 55min. The operation is as much as setting time, and 'Constant opeartion'.

  • Page 13: Using Mobile Application

    USING MOBILE APPLICATION INSTALLING APPLICATION 1. Start Google Play or App Store 2. Find Airrex application (available in countries: Finland, Sweden, Norway. Denmark, Iceland, Estonia, Latvia, Lithuania, United Kingdom) 3. Install the application REGISTER AS A USER TO APPLICATION 1. On the login screen, 3.

  • Page 14: Connecting Heater To Application

    USING MOBILE APPLICATION CONNECTING HEATER TO APPLICATION 3. Please read all terms of 4. Find the serial number on 2. Choose diesel heater 1. Press CONNECT service and accept them by the right side of the heater. from the product options. PRODUCT button to start clicking ACCEPT button.

  • Page 15: Tips For Using Mobile Application

    USING MOBILE APPLICATION CONNECTING HEATER TO APPLICATION 4. At the operation mode, the operation symbol and repetition time both are displayed, and when you make off by pushing power button, STOP symbol the time is blinking, and if you don't push button for 3sec., this displayed blinking time is ‘Interval pause time’, STOP symbol (--) and set as 'repetition time'.

  • Page 16: Using Mobile Application

    USING MOBILE APPLICATION USING THE MOBILE APPLICATION APPLICATION DASHBOARD The mobile application works the same way with the normal control panel. Please refer to the operating instructions in this user manual to understand what each button does. 1. Push notifications 2.

  • Page 17: Notice When Using Mobile Application

    INTERNAL LTE ROUTER (OPTIONAL) If you don't have access to a wi-fi network, Airrex heater can be equipped with an internal LTE Router. You can buy a router from your Airrex dealer. HOW TO INSTALL LTE ROUTER TO HEATER 1.

  • Page 18: Maintenance And Cleaning

    MAINTENANCE AND CLEANING REPLACING THE FUEL FILTER The fuel filter is located in the heater tank. REPLACING THE FUEL FILTER 1. Disconnect the fuel hoses from the fuel pump. 2. Lift off the rubber seal on the fuel tank with a screwdriver. 3.

  • Page 19: Yearly Maintenance

    Needed spare parts for yearly maintenance service are all included in separately sold Airrex heater service kit. Ensure to use right service kit for your heater. Yearly maintenance service is also available as an all included paid service.

  • Page 20: Maintenance Logbook

    MAINTENANCE AND CLEANING MAINTENANCE LOGBOOK Heater model: Serial number: Date: Maintenance done by: Maintenance done: Date: Maintenance done by: Maintenance done: Date: Maintenance done by: Maintenance done: Date: Maintenance done by: Maintenance done:...

  • Page 21: Diagnosing And Repairing Malfunctions

    Temperature sensor is probably damaged. Heater can still be · If the temp sensor which detects room temp has used in timer operation mode. Please contact official Airrex problem, displays error and operation is only made by time service to fix temperature sensor.
  • Page 22 The heater can still be used in timer operation ER 2 error message Temperature sensor error mode. Please contact the official Airrex service to fix temperature sensor. The warning light is lit if the device is tilted by more than 30°C or subjected to a strong shock or...

  • Page 23: Wifi Problems

    6) Delete the product from the mobile app and register the product again from the beginning. (Note: For iPhone, turn Bluetooth off and on in the phone settings and forget the device named "AIRREX" on the device list.)

  • Page 24: Technical Specifications And Connection Diagram

    TECHNICAL SPECIFICATIONS AND CONNECTION DIAGRAM AH-200i AH-300i AH-800i Heating capacity 13kW/h 15kW/h 22kW/h (11,180kcal/h) (12,900 kcal/h) (18,920 kcal/h) Fuel Biodiesel, diesel Fuel comsumption 0.95 - 1.14 L / h 1.14 - 1.33 L / h 1.71 - 1.9 L / h...

  • Page 25: Ensure Sufficient Ventilation

    ENSURE SUFFICIENT VENTILATION! More than 85% of all operating malfunctions are due to insufficient ventilation. It is advisable to place the heater in a central and open location so that it can radiate heat in front of it without obstruction. The heater needs oxygen to run, which is why sufficient ventilation in the room must be ensured.

  • Page 26: Airrex Warranty

    AIRREX WARRANTY Warranty terms and conditions Warranty provided by Rex Nordic Oy (2646942–1) Mustanlähteentie 24A, 07230 Askola, FINLAND 1. General description Rex Nordic provides a warranty to consumers who have purchased a product imported by an importer either directly or from a reseller. The consumer’s rights during the warranty period are determined based on the regulations valid in the country where the warranty or warranty service claim has been presented.
  • Page 27 6. Warranty limitations The warranty shall not cover: a. repair of a defect caused by natural wear and tear or inappropriate use; deficient or faulty service performed by a party other than the importer or conditions of use deviating from the dimensioning basis; or selection by the purchaser of a device unfit or wrongly dimensioned for use or for a certain application.

  • Page 28: Technical Support

    TECHNICAL SUPPORT WHY OUR SERVICE? WE ARE HERE TO HELP YOU 1. We are the official service shop for Airrex products. FINLAND +358 400 470 915 2. We only use original spare parts. SWEDEN +46 72 555 29 09 3. All spare parts for devices are available in our warehouse.

This manual is also suitable for:

Ah-300iAh-800i
