Mweld POWER TIG DPIII Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
POWER TIG DP
III
WARNING:
Read carefully and understand all ASSEMBLY
CATALOGUE
AND OPERATION INSTRUCTIONS before
operating. Failure to follow the safety rules and
1
other basic safety precautions may result in
serious personal injury.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWER TIG DPIII and is the answer not in the manual?

Questions and answers

Related Manuals for Mweld POWER TIG DPIII

Summary of Contents for Mweld POWER TIG DPIII

  • Page 1 OWNER’S MANUAL POWER TIG DP WARNING: Read carefully and understand all ASSEMBLY CATALOGUE AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury.
  • Page 2 CATALOGUE General Safety Rules Welder Instruction Safety Usage Technical Specifications Functions Current Adjustment Instruction Welder Installation List of Spare Parts Operations Methods Common faults and solving methods Explosive View and Spare Parts List Main Circuit Principle Diagram Complete Set List Delivery &...

  • Page 3: General Safety Rules

    WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in serious injury. CAUTION: Do not allow persons to operate or assemble this POWER TIG DPIII until they have read this manual and have developed a thorough understanding of how the POWER TIG DPIII works.
  • Page 4 immerse them in water. These components and the welder must be completely dry before attempting to use them. -Follow the instructions in this manual. -Keep welder in the off position when not in use. -Connect ground lead as close to the area being welded as possible to ensure a good ground. -Do not allow any body part to come in contact with the welding wire if you are in contact with the material being welded, ground or electrode from another welder.
  • Page 5 UV and IR Arc Rays The welding arc produces ultraviolet (UV) and infrared (IR) rays that can cause injury to your eyes and skin. Do not look at the welding arc without proper eye protection. -Always use a helmet that covers your full face from the neck to top of head and to the back of each ear. -Use a lens that meets ANSI standards and safety glasses.
  • Page 6 There are specific applications for which the POWER TIG DPIII was designed. Always check of damaged or worn out parts before using the POWER TIG DPIII . Broken parts will affect the POWER TIG DPIII operation. Replace or repair damaged or worn parts immediately.

  • Page 7: Safety Operation

    Welders Instructions POWERTIG pulse inverter welder uses inert gases (Argon) as the protection medium for the arc, using high frequency or high pulse to do the gas ionization and melt metals by the arc, made between the tungsten electrode and work piece, to reach the welding purpose. It can give fast good compensation for power grids fluctuation, and can control accurately for various welding process.
  • Page 8 * Welders have strong electromagnetism and electric frequency disturbs. Do not let near the persons with heart pacemaker or easily affected by electromagnetism and electric frequency. * Do not press, pile or stress the welding wires by any apparatus. Do not bend the welding wires into very small angle, otherwise it would hurt the inside wires to cause the hidden troubles.

  • Page 9: Technical Specifications

    Technical Specifications Environment Conditions * Ambient air temperature range: 5~+40℃ in welding,water cooling -10~+40℃ in welding, air cooling -25~+55℃ in delivery, storage * Air relevant humidity: in 40℃ , ≤50%; in 20℃ , ≤ 90% * Dusts, Acid, Causticity airs or materials contents in the welding area air lower than the relevant standards (except for these caused by the welding), No strong shake allowed in the welding area.
  • Page 10 Main technical specifications of the welder No special advice on above parameter. The nameplate parameter on the welder is prior. ITEM UNIT POWER TIG 200DPIII POWER TIG 180DP 220(220~240) 230(220~240) 220(220~240) 230(220~240) ted Input Voltage 50/60 50/60 50/60 50/60 Power Frequency Rated Input 8.58...
  • Page 11 Remark of Illustration Welder earth ing sign TIG Weldin g Drug skin electrode stick arc welding ，Single AC power supply Single stilln ess freq uency inverter --- tran sformer --- rectifier DC cu rrent ＋ ：+ Electrode － ：- Electrode X：Duty Cycle ...A：Rated max input current 1max...
  • Page 12 Functions Manual metal-arc welding This mode is equivalent to the function of the dc arc welding machine, the manual welding electrode welding function。 Argon arc welding Widely used in a variety of carbon steel, alloy steel, stainless steel, copper and copper alloys, nickel and nickel alloy welding, especially suitable for thin plate welding (3 mm or less) and plate (>...

  • Page 13: Welder Installation

    Current Adjustment Instruction Welding current Arc welding current refers to the "hand/argon arc" function mode Settings of the welding current size, at the same time refers to the pulse argon arc welding of pulse peak electric current. At this time of the arc heat is big, the workpiece heated, it is used to welding.
  • Page 14 explosive gas or goods around. * Avoiding direct sunshine or rainfall, ambient temperature in the range of -10~40 ℃ (water cooling model, 5~40℃ ) * Apparatus to exclude wind and smoke should be equipped if the inside aeration is not sound. Connected with power source (see the input wiring drawing) Connect the 【...
  • Page 15 Input wiring drawing * Power supply configuration of one welder: Item POWERTIG200KD PULSE ii ACB （ A） ≥4 0 FU SE （ A） KN IFE SWITCH （ A） ≥ 6 0 PO WE R LINE（ mm ） ≥ 4 Note: the breaking current of fuse is twice of its rated working current. Connected with Argon (see the input wiring drawing) Install the decompression valve (Argon meter) onto the Argon bottle, connect the gas hole on the Argon bottle with the Argon input hole on the behind panel of the welder with the gas pipe, supplied together with the...

  • Page 16: Operation

    Operation ATTENTION ：The protection grade of POWERTIG DC pulse Welder is IP21S. It is forbidden to put in a finger or insert a round bar less than 12.5mm (metal bar in particular) into the welder. No heavy force can be employed on the welder. Front panel real panel 1．welding mode...
  • Page 17 * Light separating screen should be put in the job site to prevent arc hurting other people； * Inflammable or explosive materials are prohibited to access the job site； * Every connector of welder should be connected correctly and grounded reliably * Manual Arc Welding When put ‘welding mode selection switch’...
  • Page 18 Welding regulations parameter table (only for reference) WORK Wire Tungste Welding Top Dia Designe Thickne Argon Flow n Stick Current Angle Φ d Joint Φ /min) Dia Φ (mm) (mm) (mm) (mm) Vertical 1.6~3.0 50~90 12~20° 0.12~0.25 Joint 1.6~2.5 8~12 ＞...
  • Page 19 Relevant potentiometer Replace the potentiometer broken Panel knob not Main PC board broken Replace the PC board adjustable Find the disconnected wire and Cable broken/fallen off Connect reliably Digital meter Change the meter broken No display on Find the disconnected wire and the AMP meter Cable broken/fallen off Connect reliably...
  • Page 20 Explosive view and spare Parts List Note: above table spare parts list is just for reference. Code English name 20020170017 handle 11010011797 top cover 11020013625 mounting plate 20070800288 rocker switch 20030060074 YZ power cable 20040300007 cable protection cover 11010032555 back panel up fixed plate 20050050694 fan window 20050050691...
  • Page 21 20070550048 gas solenoid 20070890181 11020015340 Cover Of Axial Fan 11010021208 right panel 20070430125 IGBT heaet sink 20050050108 Radiator connector 11020011589 heat sink fixed holder 20050050180 SUPPORT PILLAR 20050120052 The little clamp 20070430124 FRD heat sink 11010041341 bottom panel 11050010099 power PCB board 11040050052 coupling transformer 20070570184...
  • Page 22 Main circuit principle diagram 1 2 3 4 1 2 3 Note: reference drawing, not extra notice for the extra change...

  • Page 23: Delivery And Storage

    Complete Set list POWERTIG***KD PULSE ii pulsed inverter TIG welder 1Piece Product Qualification Certificate 1 Piece Warranty Card 1 Piece Operator ’s Manual 1 Piece Accessories – easy-broken parts TIG welding torch 1Piece Pottery muzzle（ 1piece in the welding torch） 3 Pcs Tungsten electrode holder（...
