Combi Vertical Diaper Changing Station "Smart Hold OKF11"
Save This Manual for Future Reference
Combi Vertical Diaper Changing Station
"Smart Hold OKF11"
Daily Inspection and
Periodical Inspection Manual
[To the person in charge of installation]
The inspection after the installation is the same as the daily
inspection. After installation is complete, inspect the product by
referring to 2 Daily Inspection on pages 3 to 4.
Advertisement
Related Manuals for Combi Smart Hold OKF11
Summary of Contents for Combi Smart Hold OKF11
- Page 1 Combi Vertical Diaper Changing Station “Smart Hold OKF11” Save This Manual for Future Reference Combi Vertical Diaper Changing Station “Smart Hold OKF11” Daily Inspection and Periodical Inspection Manual [To the person in charge of installation] The inspection after the installation is the same as the daily inspection.
-
Page 2: Table Of Contents
This manual describes the details of "Daily Inspections" and "Periodic Inspections" required for the comfortable and safe use of Combi Vertical Diaper Changing Station " Smart Hold OKF11". Be sure to perform daily or weekly inspection and annual periodic inspections in accordance with the contents of this manual. -
Page 3: Daily Inspection
Daily Inspection Daily inspections are carried out daily or weekly basis by visual and touch. No tools are used. If any malfunctions are found during the inspection, immediately discontinue the usage and contact sales agent to request service. Checking external appearance Checking the open/close operation of the table panel ①... - Page 4 Combi Vertical Diaper Changing Station "Smart Hold OKF11" Daily Inspection and Periodical Inspection Manual Checking stickers The sticker should be properly affixed and contents are readable. (No scratches, tears, missing, or discoloration) The contents should be readable. (dirt mark, graffiti, etc.) * The sticker contains warnings and cautions for safety use.
-
Page 5: Periodic Inspection
Periodic Inspection ● Periodic inspections are conducted periodically about If any issues are found during inspection, once a year. immediately discontinue the usage and contact ● In the periodic inspection, check the daily inspection sales agent to request service. points and remove each part according to the following and check the condition of each part. - Page 6 Combi Vertical Diaper Changing Station "Smart Hold OKF11" Daily Inspection and Periodical Inspection Manual ④ Checking the fixing anchor bolts for the leg frame ❶ ❷ Remove the bottom cover and hinge Check the 3 anchor bolts for fixing the leg covers from the frame in this order.
- Page 7 ⑤ Check for rust on wall fixing screws and main body frame ❸ ❷ ❶ For partitions, gypsum boards It is fixed in the small holes. Check the screws (7 locations) are not missing or loose. Check the main frame for rust. ❺...
-
Page 8: Part Replacement
Combi Vertical Diaper Changing Station "Smart Hold OKF11" Daily Inspection and Periodical Inspection Manual Part Replacement Belt Replacement * Replace the belt with a retractor. If broken, frayed, or severely soiled belt is found during daily inspections. It is recommended to purchase "Belt Retractor Replacement Set"... - Page 9 Remove the 4 fixing screws and replace the Extract the belt from the retractor and pass through belt including the retractor. the belt hole in the table panel (upper side). Table Panel (Upper) Metal Rod B e lt R e tr a c t o r If a metal bar is passed through the belt, it will not fall...
-
Page 10: Others
Combi Vertical Diaper Changing Station "Smart Hold OKF11" Daily Inspection and Periodical Inspection Manual Procedure of replacing buckle holder Refer to Belt Replacement for the disassemble of the table panel. Turn the table panel over and remove the screws. Replace the buckle holder and fix it with screws. - Page 11 Head Offices: 2-6-7 Motoasakusa, Taito-ku, Tokyo 111-0041 Japan Te l : 0 3 - 5 8 2 8 - 7 6 3 1 F a x : 0 3 - 5 8 2 8 - 7 6 3 0...
