Foldable Diaper Changing Station
Save This Manual for Future Reference
Combi Horizontal Diaper Changing Station
Instruction Manual
and Inspection Manual
Combi Horizontal Diaper Changing Station
Combi Horizontal Diaper Changing Station
OK21F
OK21W
<Floor Mount Type>
<Wall Mount Type>
This manual contains information required for safe and comfortable use of
Combi Horizontal Diaper Changing Station OK21. Read this manual careful-
ly before use to ensure correct use and inspection. Keep this manual carefully.
Advertisement
Related Manuals for Combi OK21F
Summary of Contents for Combi OK21F
- Page 1 <Floor Mount Type> <Wall Mount Type> This manual contains information required for safe and comfortable use of Combi Horizontal Diaper Changing Station OK21. Read this manual careful- ly before use to ensure correct use and inspection. Keep this manual carefully.
-
Page 2: Table Of Contents
Combi Horizontal Diaper Changing Station OK21 Instruction Manual & Inspection Manual Table of C on te n ts Instruction Manual Page Inspection Manual 7-14 Page Daily Inspection Page 7-10 Periodic Inspection Page 11-14 Part Replacement Procedure 15-19 Page Replacement Procedure for Retractor... -
Page 3: Instruction Manual
Combi Horizontal Diaper Changing Station OK21 Instruction Manual Usage of Product This is a foldable diaper changing station installed in the facility. This is a horizontal type in which the user stands on the side of the wall and changes diaper. - Page 4 Combi Horizontal Diaper Changing Station OK21 Instruction Manual & Inspection Manual This product dedicates to changing a diaper for children. Please clean regularly to keep immaculate after installation. After inspection or replacing parts, make sure to clean the product. Cleaning Method l To clean the Product, wipe it with a dampened cloth with diluted neutral detergent, then wipe with a dampened cloth with water, and finally wipe with a dry cloth to completely remove remaining detergent and moisture.
- Page 5 (Hereinafter, Leg Cover) View from the Top When Opened Center Cover Baggage Space Inner Back Cover OK2 (Hereinafter, Inner Back Cover) Combi Horizontal Diaper Changing Station OK21F/OK21W Retractor Belt Receiver (Buckle Holder) Assembled Holding Cushion OK2 Table (Hereinafter, Holding Cushion)
- Page 6 Combi Horizontal Diaper Changing Station OK21 Instruction Manual & Inspection Manual How to Use Use the product correctly by following the warning instructions. Warning Keep Eyes on Child May Fall! Do Not Leave Child all the Time Do not allow child stands up.
- Page 7 How to Use Belt Retractor Belt ■ To Fasten the Buckle ■ To Release the Buckle Pull out the belt. I n s e r t t h e b u c k l e u n t i l i t Press the button on the side clicks.
-
Page 8: Inspection Manual
Combi Horizontal Diaper Changing Station OK21 Instruction Manual & Inspection Manual Combi Horizontal Diaper Changing Station OK21 Inspection Manual This manual describes the details of daily and periodic Warning inspections required for comfortable and safe use of C a r r y o u t d a i l y i n s p e c t i o n , a n d p e r i o d i c Combi Horizontal Diaper Changing Station OK21. - Page 9 Visual Replacement found and the contents are readable. No peel off or no breakage of sticker are ⑫ Visibility of Combi Logo Stickers Visual Replacement found and the contents are readable. * The kind of sticker is explained on page 9.
- Page 10 Combi Horizontal Diaper Changing Station OK21 Instruction Manual & Inspection Manual The sticker should be properly affixed and the contents are readable. (It should not be invisible or unreadable due to the peel off, dirt, graffiti, etc.) * The stickers contain warnings and precautions for safe use.
- Page 11 Checking Belt and Buckle Handling of Inspection Points Inspection Method Judgment Criteria Defects ⑬ Scratches, Cracks, and Rattling Visual Touch No scratches, cracks or rattling Repair of Buckles ⑭ Scratches, Cracks, and Rattling of the Visual Touch No scratches, cracks or rattling Repair Receiver (Buckle Holder) ⑮...
-
Page 12: Periodic Inspection
Combi Horizontal Diaper Changing Station OK21 Instruction Manual & Inspection Manual Periodic Inspection If any issues detected during the inspection, immediately Periodic inspections are conducted discontinue use and contact the sales agent and request periodically about once a year. repair. - Page 13 (2 locations on the left and right) Fixed with 2 screws. Removing the Leg Cover. <For OK21F> Remove the 4 screws (white screws) from the side and remove the leg cover from the leg frame. (Make sure there are 4 screws)
- Page 14 Combi Horizontal Diaper Changing Station OK21 Instruction Manual & Inspection Manual Checking of Looseness of Screws and Rust on Body Frame Handling of Inspection Points Inspection Method Judgment Criteria Defects Discontinuation of No severe rust ❶ Rust on Body Frame and Leg Frame...
- Page 15 ❺ Checking fixing screws for the lower cover/leg cover (Cover W). Check the lower cover fixing screws (4 locations) and leg cover fixing screws (4 locations) are missing or loose. ❻ Checking the fixing screws for the inner back cover and inner front cover Check ❺...
-
Page 16: Part Replacement Procedure
Combi Horizontal Diaper Changing Station OK21 Instruction Manual & Inspection Manual Combi Horizontal Diaper Changing Station OK21 Parts Replacement Procedure If any malfunctions are found in the daily inspection or periodic inspection, etc., and the parts are replaced with new ones, read this replacement procedure carefully and replace them correctly. - Page 17 Remove the Buckle and Pull out the Belt from the Inner Front Cover. Pull out the belt from the inner front cover. Remove the Remove the buckle metal rod inside fixing screws Inner Front Cover the buckle and (2 locations). remove the buckle from the belt.
- Page 18 Combi Horizontal Diaper Changing Station OK21 Instruction Manual & Inspection Manual I n s ta lla tion Pr oc edu r e Set the Retractor to the Inner Cover. Inner Back Cover Installation is done by following the reverse procedure of removal.
- Page 19 Insert the Inner Front Cover into the Holding Cushion, and Then Insert it into the Outer Cover. ① Align the tab of holding cushion to the ② Align both ends of the holding cushion ③ Insert the inner front cover back of upper portion of the inner front and insert into the recesses of both ends into the outer cover.
-
Page 20: Replacement Procedure For Receiver (Buckle Holder)
Combi Horizontal Diaper Changing Station OK21 Instruction Manual & Inspection Manual Affix New Baggage Mark Sticker (2 locations) to the Inner Front Cover. Affix it matching to the Baggage Mark Sticker space. Inner Front Cover Replacing Receiver (Buckle Holder) If you discover that "Receiver" has cracks, scratches, or rattling, Warning it is recommended that you purchase "Receiver"... - Page 21 Head Offices: 2-6-7 Motoasakusa, Taito-ku, Tokyo 111-0041 Japan Te l : 0 3 - 5 8 2 8 - 7 6 3 1 F a x : 0 3 - 5 8 2 8 - 7 6 3 0...
