TP3206-70 V100R002C10
Connection Diagrams
Document Version: 02
Issue Date: 2019-06-04
HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP3206-70 and is the answer not in the manual?

Questions and answers

Summary of Contents for Huawei TP3206-70

  • Page 1 TP3206-70 V100R002C10 Connection Diagrams Document Version: 02 Issue Date: 2019-06-04 HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 Modified Section Description Author 2018-07-30 This issue is the first official release. Wang Rui Changed the tablet model and tabletop Device List; Power Management Wang Rui 2019-06-04 display part number. Copyright © Huawei Technologies Co., Ltd. 2019. All rights reserved.
  • Page 3: Table Of Contents

    Contents Cable Identification Methods Device List Cable List Video Management 1. Telepresence Host and Codec 2. Presentation Input 3. Presentation Output Network Management 1. Network Diagram 2. Cable Connections Control Cable Connections Audio Management 1. Microphones 2. MIC Microphone Input 3.
  • Page 4 Cable Types and Quantity Power Management 1. Cable Connection Diagram (TP3206-70) 2. Cable List Ground Bar Connections...
  • Page 5: Cable Identification Methods

    Cable Identification Methods In connection diagrams, different cables are represented by different colors and names. Cables of the same type are numbered according to their installation sequence. For example, video cables are numbered V1, V2, ..., and Vn. The following table lists the cable identification methods. Initial Letter Cable Type Symbol Line...
  • Page 6: Device List

    40 W 120 W 02312JKK Microphone 22050078 8-outlet power IRS-S800CC10 02160212 supply controller 6-outlet PDU Clever 14190662 1-outlet PDU Clever 14190403 Desktop socket Wireless router HG659 100–240 V AC 10 W 10 W 53035736 2190W Power consumption of the TP3206-70...
  • Page 7: Cable List

    Cable List Type Description Part Number Quantity Remarks Type CAM-CAM 04051016 1 PCS 3.5 m 3-in-1 cable for connecting the camera to the codec DVI-HDMI 04050498 3 PCS Cable for connecting a display to the codec VGA-DVI 04051014 1 PCS Cable for connecting an external VGA presentation source to the codec Video cable HDMI-HDMI...
  • Page 8: Video Management

    Video Management Telepresence Host and Codec [V01] HD-VI 1 TP3206: uses 65-inch narrow-gap LCD displays. [V02] HD-VI 2 [V03] HD-VI 3 Left Middle Right Front view (facing the displays) [V04] [V05] [V06] HD camera Ports on the rear panel of the telepresence codec TE80 HDMI1 port on the 70-inch...
  • Page 9 Video Management Telepresence Host and Codec Type Part Number Length Connected Parties Remarks Codec: VIDEO INPUT [V01] CAM-CAM Camera: CAM 1 port Label 1-Label 1 1 HDVI port 04051016 (3-in-1 cable with Codec: VIDEO INPUT [V02] CAM-CAM 3.5 m Camera: CAM 2 port Label 2-Label 2 each connector 2 HDVI port...
  • Page 10: Presentation Input

    Video Management Presentation Input Left presentation source Right presentation source [V07] [V08] Ports on the rear panel of the telepresence codec TE80 Type Part Number Length Connected Parties Remarks Left video presentation Codec: VIDEO INPUT 4 [V07] VGA-DVI 04051014 source: VGA port Right video presentation Codec: VIDEO INPUT [V08]...
  • Page 11: Presentation Output

    Video Management Presentation Output Ports on the rear panel of the telepresence codec TE80 [V09] Middle tabletop display Right tabletop display Left tabletop display [V10] [V11] Tabletop display Type Part Number Length Connected Parties Remarks Codec: VIDEO OUTPUT 5 Left tabletop display: [V09] DVI-DVI 04051012...
  • Page 12: Network Management

    Network Management Network Diagram NOTE A. The network switch ports are divided into Telepresence codec TE80 two groups: VLAN 1 and VLAN 2. LAN2 LAN1 B. Ports connected to external networks LAN1 Telepresence (service networks) are grouped in VLAN 1. host LAN2 These ports are numbered from 1 to 12.
  • Page 13: Cable Connections

    Network Management Cable Connections Type Part Number Length Connected Parties Remarks [N01] RJ45-RJ45 04070009 Switch port 1 Network wall port [N02] RJ45-RJ45 04070003 Switch port 2 Codec: LAN 1 port Left desktop socket: [N03] RJ45-RJ45 04070009 Switch port 3 RJ45 port (female) Right desktop socket: [N04] RJ45-RJ45...
  • Page 14: Control Cable Connections

    Control Cable Connections [C02] Power supply controller B Telepresence host [C01] Power supply controller A Type Part Number Length Connected Parties Remarks Power supply controller A: Telepresence host: [C01] RJ45-RJ45 04070003 RS485 port COM4 port Power supply controller B: Telepresence host: [C02] RJ45-RJ45 04070003...
  • Page 15: Audio Management

    Audio Management Microphones MIC 6 MIC 5 MIC 1 MIC 2 MIC 4 MIC 3...
  • Page 16: Mic Microphone Input

    Audio Management Microphone Input MIC 1 MIC 2 MIC 3 MIC 4 [A01] [A03] [A02] [A04] Telepresence codec TE80 [A05] [A06] MIC 5 MIC 6 Type Part Number Length Connected Parties Remarks [A01] MIC 1 Codec MIC IN 1 Label 1-Label 1 [A02] MIC 2 Codec MIC IN 2...
  • Page 17: Presentation Audio

    Audio Management Presentation Audio [A07] Telepresence codec TE80 Part Type Length Connected Parties Remarks Number [A07] 3.5 mm-3.5 mm 04050404 Presentation audio source Codec LINE IN 8...
  • Page 18: Speaker Output (Network Diagram)

    Audio Management Speaker Output (Network Diagram) [A09] [A08] [A08] [A09] [A11] [A10] [A12] [A13] Middle speaker (right) Left speaker Middle speaker (left) Right speaker Type Part Number Length Connected Parties Remarks [A08] Codec: AUDIO OUTPUT 1 L port Left speaker host: IN L port 04051015 3.5 m [A08]...
  • Page 19 Power Management Cable Connections (TP3206-70 Sharp Display) Network switch: 20 W PDU 2 (1-outlet) [P10] Tri-lens camera: 50 W [P06] Left speaker [P04] [P09] system: 90 W [P01] [P02] PORT2 PORT3 PORT4 PORT5 PORT6 PORT7 PORT8 Wall outlet 1: PORT1...
  • Page 20 Power Management Cable Connections (TP3206-70 Sharp Display) TP3206: uses 70-inch narrow-gap LCD displays. Right display: Left display: Middle display: 380W 380 W 380 W Front view (facing the displays) [P15] [P16] [P17] [P13] [P14] Wall outlet 2: PORT2 PORT3 PORT4 PORT5 PORT6 PORT7 PORT8...
  • Page 21 Power Management Cable Connections (TP3206-65 Samsung Display) [P19] [P20] PDU 4 (6-outlet) Wall outlet 3 [P22] [P21] [P24] [P23] PDU 5 (1-outlet) Touch panel: 10 W Left desktop socket Right desktop socket [P25] [P26] PDU 4 (6-outlet) Wall outlet 4 120W [P28] [P29]...
  • Page 22 Power Management Cable List Note: C13 indicates the female connector of a power cable, while C14 indicates the male connector. Type Part Number Length Connected Parties Remarks Determined by the wall [P01] Wall socket 1 power cable socket specifications in each Wall socket 1 Power extension cable 1 (C14) country.
  • Page 23 Power Management Cable List Type Part Number Length Connected Parties Remarks Determined by the wall socket Power extension cable 12 [P19] Wall socket 3 power cable Wall outlet 3 specifications in (C14) each country. Wall socket 3 power cable [P20] Power extension cable 12 04050847 6-outlet PDU 4 (C14)
  • Page 24 Ground Bar Connections [G01] [G03] [G02] [G04] [G05]...
  • Page 25 Ground bar (M6) [G04] M6-M6 04091337 2.5 m Telepresence host (M6) Ground bar (M6) Ground stud of the M8-M8 Ground terminal (M8) [G05] 04091337 conference room HUAWEI TECHNOLOGIES CO., LTD. Huawei Industrial Base Bantian Longgang Shenzhen 518129 People’s Republic of China www.huawei.com...
