OPERATION
MANUAL
SCR Control CO
Shielding Arc
2
Welding Machine
FKR/350/500
ATTENTION:
For safety guarantee, only the person with operating
certificate or expert skills can collocate, check,
maintain, fix and repair the welder.
For safety guarantee, please completely read and
understand the details in this manual before using.
Keep the manual in convenient place for easy reading.
Advertisement
Table of Contents
Related Manuals for Hanshen FKR350
Summary of Contents for Hanshen FKR350
- Page 1 OPERATION MANUAL SCR Control CO Shielding Arc Welding Machine FKR/350/500 ATTENTION: For safety guarantee, only the person with operating certificate or expert skills can collocate, check, maintain, fix and repair the welder. For safety guarantee, please completely read and understand the details in this manual before using. Keep the manual in convenient place for easy reading.
- Page 2 Comparing with other welding machines, CO2/MAG arc welding machine has the following features： ◆ Higher working efficiency : CO arc has strong penetration ability, deeper welding pool, higher melt efficiency. So, welding speed is faster and productivity is 1-3 times higher than stick welding ◆...
-
Page 3: Table Of Contents
CATALOGUE NOTICE 1,Characteristic..................4 2,Safety attention ..................4 3,Installation place and power facility ............6 4,Machine structure and accessories ...........6 machine st ructure and assembly drawing.........6 ◆ 5,Components name and function............7 ◆ Welding power (operation panel) ..........8 ◆ Remote controller...............9 CONNECT Connection and Grounding …………………………………………… 10 Power source and distribution box ……………………………..11 ◆... - Page 4 TECH DATA 1、Rated Specification/Standard accessories/ Outline dimension ……...26 2、Instance for welding conditions ……………………………………..28 3、About duty cycle …………………………………………………….29 4、Words and expressions ………………………………………………30 Meani ngs of crater （Yes ）crater （No ）……………………..30 ◆ What's slow feeder speed with lift arc …………………… ………31 ◆ What's flashback time ……………………………………………31 ◆...
-
Page 5: Notice
NOTICE 1、CHAEACTERS Performance exceeding common SCR welding machine -remote control cable，enhance maneuverability，decrease cable broken ◆ problem. New design and tri -protection treatments， dust、 water、 smog protections， improve ◆ performance and suitable to any worksite and environment. Separately adjust for current and voltage /simple centralize conversion f unction，... - Page 6 3、INSTALL ENVIRONMENT AND POWER FACILITY Power 3 PHASE AC(380V) 50Hz Model FKR350 FKR500 Adopted power 20KVA 40KVA Capacity 18.1 KVA 31.9KVA Engine generator 2 times up 2 times up Fuse size Input Circuit breaker protection (leakage protection) Power inlet 8 mm...
-
Page 7: 3,Installation Place And Power Facility
● please use different circuit breaker（or leakage protecting device）for welding machine、generator and transformer. ●please use appointed wire-feeder with our welding machine 4、MACHINE STRUCTURE AND ACCESSORIES ●machine structure and assembly drawing... -
Page 8: 5,Components Name And Function
5、PARTS NAME AND FUNCTION ●welding power (operation front panel) -
Page 9: Welding Power (Operation Panel)
Welding power... -
Page 10: Remote Controller
remote controller ●... -
Page 11: Connect
CONNECT Connection and Grounding Safety warning Avoiding accidents happen such as electric shock,burning etc, follow rule should be abided by: ●Connecting power cable should be under”power off”, and absolutely safety condition. ●Don’t touch any parts with damp hands. Attention Avoiding fire, burn machine or unstable arc occurred by cable over-heated: ●cable should be more than demaned specification ●don’t hang any things on cable or touch welding parts... -
Page 12: Power Source And Distribution Box
●please tightly connect cables’ joints. Connection and Grounding Welding power connected with base metal and inlet cable... -
Page 13: Power Source And Workpiece End 、Output Cable
Welding power connection with wire-feeder and welding torch Attention Wire-feeder machine should match with welding machine and power source If not match , the machine can not work and possibly be damaged . Note: Information about welding torch 、 wire-feeder and gas flow-meter, please refer to page 29,page30. -
Page 14: Gas Cylinder And Adjustor
Connection and Grounding Gas cylinder and regulator Note Gas quality will effect to welding result, follows are some key points: ●CO2 welding must use CO2 gas. ●MAG welding must use MAG mixed gas(argon gas mixed with 5-20% CO2). CO2 and argon mixed, gas mix facility must be used(avoiding mixed mot well) ●... -
Page 15: Operation
OPERATION 1、Confirmation and preparation before operation ●Confirming to safety fitting and preparing ●Safety fittings ●For your naked eye and skill leather glove and safety boots should be dressed well. ●must wear protection mask with shading and filting len. Avoiding toxin gas(CO, ozone, oxidize nitrogen), ventilation system must be employed. -
Page 16: Preparation Before Welding
Confirmation and preparation before cooperation Preparation before welding operation ■Switching and gas flow adjusting... -
Page 17: Wire I Nstallation
Preparation before welding operation ■Install wire... -
Page 18: Finger Push For Wire Control
Preparation before welding ■Slightly move for wire-feed press spot -switch and wire-feeder ① starts, until 15-20mm length of wire out from nozzle, then loose switch Note: Thin wire is easily broken（like Φ0.8 wire）, please slow wire-feed speed. Note Select wire roller，just according to wire dia. , not wire type. When using cored wire，should adjust pressure of wire-feed arm，pressure should be less than that of solid wire . -
Page 19: 2、Manual Operation For Welding （Base Function
2、MMA operation（basic function and method） ●Welding with crater arc(self-location, crater arc action) It is used to fill pit after welding, suitable for medium thickness sheet. Welding with crater arc, funcation for filling welding pool at end and suitable for medium thickness plate Operatiing sequence ●Turn diversion switch to “crater arc on”... -
Page 20: No Crater Welding (Acting Simultaneously With Torch )
Welding without crater arc This kind of welding is used for tack welding, instantaneous welding and thin sheet welding. Operation ●turn diversion switch to “without crater arc” position, “turn on”, “turn off” gun, arc start or arc stop will be happened. Work time diagram... -
Page 21: Function
The cable longer, section smaller , the more disbenefit for welding result. ●Relationship between extension cable length and cable section, as below: Extended cable length(single, in line) 20m in 20m up FKR350 38mm 60 mm Cable section FKR500 70 mm 100 mm ●For extended cable ,the shorter ,the better, no need for extra length cable... -
Page 22: Connection Of Lengthening Cable
●by socket connection for wire-fed facility there is a socket for wire-fed at left lower part of front panel ， once open cover up ,a socket for wire-fed can be seen connecting to wire-fed as follows ： connecting from socket to outside facility can be considered a）... -
Page 23: Welding Functions Extension
■ socket for gas adjustor connection Notice When use Co2 welding，avoid gas froze，heater socket should be applied this socket only for Co2 adjustor ,cannot be used for others on up part of rear ,there is a gas adjustor socket ●socket as gas heater power （AC36V） ●Once use electric power from others ，... -
Page 24: 2、Peripheral Equipment
2、peripheral equipment As fully exerting welding machine performance，widely extending welding range improve process adaptability ,flexibility，and promoting welding effectivity ,quality ,please use concernced facility recommended by us , indication of following facility ： ■ torch... -
Page 25: T ◆ Wire -Feeder Machine
■ wire-fed machine ■ gas flow meter... - Page 26 TECHNICAL DATA 1、 Rated Specification、Dimesion FKR350 FKR500 Rated input current 3-Phase, AC 380V Rated input capacity 18KVA 32KVA Max.emputy voltage Inlet current DC60~350A DC60~500A Outlet voltage DC16~32V DC16~39V Rated load durative rate(cycle 10 minutes) Solid wire Solid wire Wire dia corresonding...
-
Page 27: 1、Rated Specification/Standard Accessories/ Outline Dimension
Dimension diagram FKR350 (unit : mm) FKR500 (unit:mm) - Page 28 2、Follow table is standard reference value when welding ,please modify according to workpiece and welding position,so as to seek best welding result.
-
Page 30: 3、About Duty Cycle
,thus effect welding machine's ability or even damage. ●above said diagram are ideal value for FKR350、FKR500 current and duty cycle. ●Please use in this ranges when use with torch or other facility， please use according to based duty cycle specification... -
Page 31: 4、Words And Expressions
esides very small current welding ,usually there is a small pit when finish welding (welding end ），this pit calls "crater" the reason of formed pit arising by arc pressure and metal cold shrink after burning general speaking ，the large welding current,the big welding pit forming .In welding process ,pit is easy to be a welding problem.So, the smaller pit ,the best welding result .We call the... -
Page 32: What's Slow Feeder Speed With Lift Arc
What is slow fed speed with lift arc So as to obtain stable lift arc at beginning, wire-fed speed will be slower.This calls slow wire-fed control, the slow speed calls slow wire-fed speed. What is delay buring When finish welding , even if switch off torch , as inertia from wire-fed machine, the action of wire-fed can not stop at once, so wire will come out of torch continuely.This will be caused stick to work-piece and make problem at next lift arc. -
Page 33: Overhaul
OVERHAUL 1、Daily overhaul safety advise Except for special requiring， any repair for welding machine must be carried out after cut off power in distribution case and ensure strictly safety.There is any other against abovesaid, electric shock or burning can be occured at any moment .It's very important to daily check as fully give out welding machine ability and safety work per day. - Page 34 Daily overhaul (continual)
-
Page 35: Weld Ing Torch
Daily overhaul (continua ) -
Page 37: 2、Regular Check
2、Regular check Separate two side covers and one top cover，clean splashand dust inside welding machine by pressure air (dry air ). How to separate top cover and side covers, see pre- page. It's importance to check smell ,color change、 heat or inner connection， and other check. -
Page 38: Clean Dust In Power Source
DEAL WITH PROBLEM 1、 primary diagnose In case problem happen such as can not welding ,current unstable、welding result not good ,etc. Don't think it must be problem of welding machine. Welding machine is correct but as some other cases, not problem really, such as：fuse broken, parts loosen, forget switch ,wrongly enactment, cable broken, gas tube chap, etc. -
Page 39: Eck Power Source And Concerned Facility
Problem item Check part Repair item ● Roller not accord to SUS Wire-fed tube ○ ○ ○ ○ ○ ● Roller brock or sth wrong machine ● Press handle too high or loosen ● SUS inlet block with power ● Torch cable hend too much Torch ●... -
Page 40: Check And Repair Wearing Parts
2、 Abnormity indicator and depose The welding machine with self-diagnose function： once problem occur, indicator will be On, please check reason and depose.Welding machine temperature is strangely higer. [reason] when use,duty cycle output is exceed,abnormity indicator will be On. [depose] please turn off torch swich but power switch is still On,(cooling fan keep running),wheninner temperature is down to requiring，it can start automatically，... -
Page 41: Trouble Shoot 1、Primary Check For Abnormity
3、 other problem ,abnormity and depose From other problems and abnormity, out of description “abnormity primary diagnose ”and “abnormity indicator and depose ”, please check reason as following sequence and find depose way .Problem and abnoity reason investigation. First ,classify problem and abnormity，look out concerning item as following 1-4.Second，confirm which one from right symbol A to D. -
Page 45: Other Reasons
Deal with after know reason Safety warn before deal with problem, power must be cut off，otherwise power shock, burn , etc will be happened . locate reason according to check flow chart，deal with following: when fuse broken locate reason （overload 、short circuit ），replace fuse , after switch on，if fuse broken again，please switch off power，and contact with us. -
Page 46: S ：Outline For Torch And Wire-Feeder Usage And Maintenance
. 5、FKR350 welding machine use Ф 0.8、Ф 1.0、Ф 1.2 wire ; KR500 welding machine use Ф1.2、Ф1.4、Ф1.6 wire . If use wire Diameter can meet requirement, it can result bad welding result even damage torch . -
Page 47: 1、Circuit Diagram
5、 Circuit diagram...
