Ballard Designs JU031 Assembly Instructions

Auto tilt umbrella 9’ or 11’
Hide thumbs
1
2
3
4

Advertisement

Table of Contents

PRODUCT NAME: Auto Tilt Umbrella 9' or 11'
ITEM NUMBER: JU031
ASSEMBLED DIMENSIONS: 8' 2"H x 9' Diameter or 8' 6"H x 11' Diameter
- Close Umbrella and secure ties during windy conditions or when Umbrella is not in use.
- Umbrella must be anchored and secured in a 50lb minimum Umbrella Base.
WIND DAMAGE IS NOT COVERED UNDER ANY UMBRELLA WARRANTY
PRODUCTS NOT INTENDED
FOR COMMERCIAL USE
UPDATED: 6-22-2020
REPLACEMENT CANOPIES SOLD SEPARATELY
WARNING
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
Page 1 of 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JU031 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ballard Designs JU031

Summary of Contents for Ballard Designs JU031

  • Page 1 Customer Service: 800-367-2810 Online: www.ballarddesigns.com PRODUCT NAME: Auto Tilt Umbrella 9’ or 11’ ITEM NUMBER: JU031 ASSEMBLED DIMENSIONS: 8’ 2”H x 9’ Diameter or 8’ 6”H x 11’ Diameter REPLACEMENT CANOPIES SOLD SEPARATELY WARNING - Close Umbrella and secure ties during windy conditions or when Umbrella is not in use.
  • Page 2 Attaching Canopy STEP 1: With frame closed, unscrew finial counterclockwise from top Finial STEP 2: Slide canopy over top of frame. Line up metal ring in canopy top to extrusion in top of frame. Then pull canopy over frame. Frame Metal Ring in Canopy Canopy...
  • Page 3 Removing Canopy STEP 1: Unscrew finial counterclockwise from top of umbrella frame. Finial Metal Ring in Canopy STEP 2: Gently pull downward on arm pockets, removing canopy from frame (total of 8 arms). Arm of Frame Arm of Frame Arm Pocket Arm Pocket of Canopy of Canopy...
  • Page 4 Operating Umbrella To Open: From closed position, crank handle clockwise until Canopy is extended to desired height. clockwise counter clockwise To engage Tilt: Once Canopy is open, keep cranking clockwise until Canopy begins to tilt. Stop cranking handle once desired tilt has been reached. NOTE: Maximum Tilt 35 degrees. To return to upright position: Crank handle counter clockwise to return Canopy upright..
