Perfect Choice Swivel Rocking Dining Chair Assembly Instructions

Tools Not Included but Required:
Tools Included:
Assembled Back
Assembled Seat
1. Place the assembled base onto a flat surface. Then place the seat onto
the base lining up the bolts coming out of the horizontal seat support with the
holes in the fiberglass springs. Make sure the seat is facing the correct direction.
The horizontal seat support should almost entirely be resting on the fiberglass springs. Then, one
bolt at a time, line up the 2 holed washer with those same bolts and place a lock nut onto each
bolt. Place all 4 nuts onto all 4 bolts first and then tighten.
2. Determine your left and right assembled arm supports. The screws
holding the assembled arm supports together should face in towards
each other. Place a 3-1/2" bolt through all 8 holes of the assembled arm
supports and into the seat. Place a flat washer, lock washer and nut
onto each bolt and hand tighten only.
ASSEMBLY INSTRUCTIONS
Swivel Rocking Dining Chair
#2 Square Drive Bit, 4mm Allen Wrench
Arm Supports
Hardware
Assembled Base
7/ 1 6" wrench, socket & ratchet and a power drill
Backboard
Arms
Parts Included:
1 - Assembled Back
1 - Assembled Seat
1 - Set of Arms
1 - Assembled Base
1 - Backboard
2 - Arm Supports (left & right)
Stainless Steel Hardware
Included:
8 - 3-1/2" Bolts
4 - 3" Bolts
2 - 2-1/2" Bolts
4 - 1-5/8" Deck Screws
14 - Nuts
14 - Flat Washers
14 - Lock Washers
4 - Lock Nuts
2 - Rectangular
2 Holed Washers
Step 1
Step 2
