Perfect Choice Swivel Dining Chair Assembly Instructions

Swivel Dining, Counter Height or Bar Height Chair
Tools Not Included but Required:
Tools Included:
Assembled Back
Assembled Seat
1. Assembling the base. 1a:Take the set of interlocking cross supports and lock them together using a 2"
deck screw making sure the provided screw hole is facing up. 1b: Next take one of the four lower legs for
the base and attach one circular lower leg support using a 3" lag screw making sure to place the pocket of
the circular lower leg support towards the ground. Repeat for other 3 legs. 1c: Next, attach one lower leg
to the cross section you assembled in step 1a using a 4" deck screw. Then repeat with the 3 remaining legs.
Make sure to insert the circular support into each leg as you go. 1d: Next, flip the base over and finish
screwing the circular supports to each leg using the four 2" deck screws.
Step 1
1a
2. Attach the swivel to the seat using two 2-1/4" hex head bolts &
washers and two 1-1/2 lag screws & washers. The lag screws should
go into the wider swivel support. The bolts should go through the
swivel mechanism first and then through the supports under the seat.
Place a flat washer and lock nut onto each bolt and tighten.
ASSEMBLY INSTRUCTIONS
#2 Square Drive Bit, 4mm Allen Wrench
Arm Supports
Swivel
Hardware
Cross
Supports
Lower Legs
Arms
Circular Lower
Leg Supports
1b
7/ 1 6" wrench, or socket & ratchet and a power drill
Parts Included:
Backboard
1 - Assembled Back
1 - Assembled Seat
1 - Set of Arms
1 - Set of Interlocking Cross Supports
1 - Swivel
2 - Arm Supports (left & right)
4 - Circular Lower Leg Supports/Footrests
4 - Lower Legs for Base
1 - Backboard
Stainless Steel Hardware Included:
8 - 3-1/2" Bolts
8 - 3" Bolts
2 - 2-1/2" Bolts
2 - 2-1/4" Hex Head Bolts
4 - 3" Lag Screws
4 - 4" Deck Screws
2 - 1-1/2" Lag Screws
1c
1d
NOTE: Swivel will loosen after some use.
5 - 2" Deck Screws
4 - 1-5/8" Deck Screws
22 - Flat Washers
14 - Lock Washers
14 - Nuts
6 - Lock Nuts
Step 2
