Please read instructions carefully before installation.
•
Check the contents of kit. Contact your YAKIMA dealer if any parts appear missing or damaged.
•
Place these instructions in the vehicle's glove box after installation is complete.
TOOLS REQUIRED:
•
4 mm Ball End Allen Key
ITEM COMPONENT
LightMate L&R
1.
with Plug
2.
Steel Bracket
3.
M6 8 mm Screw
4.
M6 8 mm Washer
5.
M6 8 mm Nuts
6.
Velcro Straps
7.
M6 14 mm Screw
8.
M6 14 mm Washer
M6 14 mm
9.
Dome Nut
10.
Plastic Stopper
11.
Cable Tie
9802701-Rev1.0
®
FIRST TIME INSTALLATION
L I G H T B O A R D N U M B E R P L A T E
KIT CONTENTS
1
QTY
x1
x1
x5
x5
2
x5
x2
x4
x4
x4
10
x2
x4
LightMate
3
7
4
8
5
9
11
™
6
1/4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Yakima LightMate
Summary of Contents for Yakima LightMate
- Page 1 • Please read instructions carefully before installation. • Check the contents of kit. Contact your YAKIMA dealer if any parts appear missing or damaged. • Place these instructions in the vehicle’s glove box after installation is complete. L I G H T B O A R D N U M B E R P L A T E...
- Page 2 Screws to 2 Nm using a 4 mm Ball End Allen Key. SECURE CABLE Hook cable to clips on rear of LightMate as pictured and using a sharp tool, break the perforation to allow the cable to come through the bottom of the light board as shown.
- Page 3 Tighten all Screws to 2 Nm using a 4 mm Ball End Allen Key. ATTACH LIGHTMATE Secure LightMate to your bike carrier or bike frames using the Velcro Straps as pictured. Ensure the lights and number plate are not obstructed from view.
- Page 4 L I G H T B O A R D N U M B E R P L A T E MAINTENANCE AND SAFETY • Remove LightMate prior to entering a car wash. • Replace Velcro straps if they become worn or damaged.
