Soltech SOLPORT 15W Installation Manual

INSTALLATION
1. REMOVE THE MOUNTING PLATE FROM THE LAMP
1a.
Remove screws
on the side of the
mounting plate.
2. FIX THE MOUNTING PLATE ON THE WALL
2a. 2b.
Place mounting Drill holes from
plate on the wall and .3 in and up to 2.5 in
mark 5 hole positions. in depth.
3. FIX LAMP ONTO THE MOUNTING PLATE
3a.
Put the lamp to
the right position
and slide to fasten.
4. FIX SOLAR PANEL ANGLE AND ADJUST DEMANDED WORKING MODE
4a.
Remove screws
on the side of the
mounting plate.
NOTICE & WARNING
1. The SOLPORT will provide optimal usage where there is enough sunshine.
2. Please note the lighting time depends on sunshine duration and weather.
3. The lamp will light up automatically at dusk.
4. Built-in intelligent IC is with over-charge, over-discharge and over-voltage protection.
5. The lamp is equipped with an internal battery pack, which is replaceable. If needed, please
contact for correct new battery pack.
6. If the battery is taken out and put back in or replaced with new batteries, please allow the
solar panel to receive maximum sunshine to activate the lamp.
7. Non-professionsals please do not disassemble the lamp.
8. Please do not dispose the battery with household garbage to avoid explosion.
1b.
Slide the mounting plate down
to the evacuated position and
remove it easily
2c. 2d.
Fix expansion Use screwdriver
plugs into holes. to fix the mounting
plate on the wall.
3b.
Fix the screw on the
side of the mounting plate.
4b.
Adjust the solar panel to
the appropriate angle, press
any button to activate lamp and
control. Then screw in lamp.
SOLPORT
INSTALLATION MANUAL
15W/1500LM
PLEASE READ AND FOLLOW INSTRUCTIONS FOR PROPER OPERATION
SAVE THIS MANUAL FOR FUTURE REFERENCE
