GUARDIAN GEAR ZW1081 Quick Start Manual

TO USE AS A BIKE ATTACHMENT

A
B
D
1. Remove all components from the box.
PARTS
(A) Stroller Body (1) (E) Flag (1)
(B) Back Wheel (2) (F) Extension Sta (2)
(C) Front Wheel (1)
(D) Handle (1)
4. Attach the larger back wheels into
the frame of the stroller by pushing the
wheel in until it clicks. To remove the
wheels, lift the back of the trailer up
and push the buttons located on the
axle. Pull out the wheels
Attaching Cross-Trainer Pet Stroller to Bicycle.
7. Fasten hitch arm onto rear axle of your bike. Wrap the safety strap around the
chainstay of the bike. Snap the hook into the D-ring attaching the trailer arm.
Cross-Trainer Pet Stroller
C
E F
2. Lift both side bars to an upright position.
Please note:
5. Lift front of stroller up and remove the hitch arm-locking pin from
the back hole in the hitch arm bracket. Fold hitch arm out until it
is parallel with the base frame. Lock the hitch arm into place by
reinserting the safety pin through the front hole of the hitch arm
bracket and secure with the wrap spring clip.
The above steps must be completed
within the canvas covering.
Flag Attachment
1. Insert the Flagpole into the
Extension Sta .
3. Insert the safety pin into the hole
on the crossbar to secure the
side bars. Ensure that the safety
pin is secured with the wrap
spring clip.
6. Fully assembled Stroller
2. Insert the Extension Sta
into the sheathe on the
side of the stroller.
