- Page 1 Installation and Assembly Instruction Guide TABLES Cirrus • Eclipse • GTX • Jill • Matrix • Milestone • OTZ • Quest Radius • Rockford • SST • Technix • Titan • Trix • Vector • Vortex WCT • Z Tables...
-
Page 3: Table Of Contents
Table of Contents Radius ................... 4 Cirrus ..................6 Quest ..................8 Trix ..................10 Vortex ................. 12 SST ..................14 Vector ................. 16 Technix................18 Eclipse ................. 20 GTX ..................22 OTZ ..................24 Milestone ................26 WCT ..................28 Z Table ................ -
Page 4: Radius
Radius Hardware Included: #12 x 1" screws Steel Modesty Panel: Steel Modesty Panel Machine Screw #8 x 1" screws 10-32 x 5/8" Veneer Modesty Panel: Cam Studs Cam Studs 15 Cam Veneer Modesty Panel Tools Required: #2 Phillips Head Screwdriver #3 Phillips Head Screwdriver... - Page 5 Radius Steel Modesty Panel Veneer Modesty Panel Steel Modesty Panel Veneer Modesty Panel Leg Frame and Table Top SteP 1: attaCH ModeSty to leGS For Steel ModeSty Panel: Install (2) cams into pre-drilled holes on each end SteP 1: attaCH ModeSty to leGS of the modesty panel.
-
Page 6: Cirrus
Cirrus Hardware Included: #12 x 1" screws Steel Modesty Panel: Steel Modesty Panel machine screws #8 x 1" screws 10-32 x 5/8" Veneer Modesty Panel: 15mm cam cam studs Tools Required: #2 Phillips Head Screwdriver #3 Phillips Head Screwdriver Veneer Modesty Panel... - Page 7 Cirrus Steel Modesty Panel Veneer Modesty Panel Steel Modesty Panel Leg Frame and Table Top Veneer Modesty Panel For Veneer ModeSty Panel: For Steel ModeSty Panel: SteP 1: attaCH ModeSty to leGS SteP 1: attaCH ModeSty to leGS Install (2) cams into pre-drilled holes on each end Position the modesty panel between the leg of the modesty panel.
-
Page 8: Quest
Quest Hardware Included: #12 x 1" screws Steel Modesty Panel: Steel Modesty Panel machine screws #8 x 1" screws 10-32 x 5/8" Veneer Modesty Panel: 15mm cam 15mm cam studs inserts Tools Required: #2 Phillips Head Screwdriver #3 Phillips Head Screwdriver Veneer Modesty Panel... - Page 9 Quest Steel Modesty Panel Veneer Modesty Panel Steel Modesty Panel Veneer Modesty Panel Leg Frame and Table Top For Veeneer ModeSty Panel: For Steel ModeSty Panel: SteP 1: attaCH ModeSty to leGS SteP 1: attaCH ModeSty to leGS Install (2) cams into pre-drilled holes on each end Position the modesty panel between the leg of the modesty panel.
-
Page 10: Trix
Trix Hardware Included: #12 x 1" screws Steel Modesty Panel: 10mm M6 bolts Tools Required: #3 Phillips Head Screwdriver 10 mm Wrench... - Page 11 Trix Trix table with keel Trix table with keel and veneer modesty panel SteP 1: attaCH leG aSSeMBly to UnderSIde oF toP Line up leg plate with locating holes on underside of top. Attach leg assembly to underside of top using #12 x 1"...
-
Page 12: Vortex
Vortex Hardware Included: #12 x 1" screws 1/4-20 x 1-1/4" bolts Tools Required: #3 Phillips Head Screwdriver 5/32" Allen wrench... - Page 13 Vortex #12 x 1" screws 1/4-20 x 1-1/4" bolts Welded mounting tabs Apron frame Corner mounting bracket SteP 1: attaCHInG tHe leGS to tHe aPron FraMe Attach each leg by bolting through a corner mounting bracket into welded threaded insert in leg using (2) 1/4-20 x 1-1/4 bolts per leg.
-
Page 14: Sst
Hardware Included: #12 x 1" screws 1/4-20 x 1-1/4" bolts Tools Required: #3 Phillips Head Screwdriver 5/32" Allen wrench... - Page 15 SteP 1: attaCHInG tHe leGS to tHe aPron Attach each leg by bolting through a corner mounting bracket into welded threaded insert in leg using (2) 1/4-20 x 1-1/4 bolts per leg. note: For epoxy tops, skip to Step 4. SteP 2: attaCHInG tHe FraMe aSSeMBly to tHe taBle toP Place the table top upside down on a clean, padded surface.
-
Page 16: Vector
Vector Standard, Vector Wave & Floating Top Hardware Included: 1/4 -20 x 1 Button Head Standard Tops: 1/4-20 x 2-1/2" bolts Floating Tops: 1/4 - 20 x 90 mm bolts 3/4" spacer Tools Required: 5/32 Allen Wrench... - Page 17 Vector Step 1 - aSSeMBle leG FraMe to SPanner Align holes in plate on end of the spanner with the holes in leg frame as shown. Secure with ¼-20 x 1” BH Bolt. Step 2- AttACHING BASe FRAMe ASSeMBLY tO tHe tOp Place the table top upside down on a clean, padded surface.
-
Page 18: Technix
Technix Full Frame & Section Frame Hardware Included: #12 x 1 #6 x 1/2" Pan Head Screw Flat Head Screw 1/4-20 x 1/2" Machine Screw Tools Required: #2 Phillips Head Screwdriver #3 Phillips Head Screwdriver... - Page 19 Technix SteP 1: Place the top upside down on a clean, padded surface. Align holes on mounting plates with pre-drilled holes on bottom side of worksurface. Fasten each mounting plate using the (4) corner holes with #12 x 1" Phillips Pan Head Screws.
-
Page 20: Eclipse
Eclipse Hardware Included: #12 x 1" screws Tools Required: #3 Phillips Screwdriver... - Page 21 Eclipse SteP 1: Place the table top upside down on a clean, padded surface SteP 2: Center leg assembly on underside of top and attach using #12 x 1" PH Screws (do not over tighten). Assemble tables only as described in this guide.
-
Page 22: Gtx
Hardware Included: 1/4-20 x 3/4" 3/4" spacers Button Head Bolt 1/4-20 x 80 mm Bolt Tools Required: 5/32" Allen Wrench... - Page 23 Spanner Spacers SteP 1: aSSeMBle leG FraMe to SPanner Align hole in tab plate on end of the spanner with the threaded holes in leg frame as shown. Secure with ¼-20 x ¾" BH Bolt. SteP 2: attaCHInG BaSe FraMe aSSeMBly to tHe toP Place the table top upside down on a clean, padded surface.
-
Page 24: Otz
Standard & Cylinder Base Hardware Included: 1/4 - 20 x 1" 1/4 - 20 x 1" Flat Head Pan Head Machine Screw Machine Screw Tools Required: 5/32" Allen Wrench... - Page 25 Standard BaSe CylInder BaSe SteP 1: Attach the steel plate to the top of each table leg using (2) ¼-20 x 1" Flat Head Machine Screw. SteP 2: Assemble table base together with the steel ring using ¼-20 x 1" Button Head machine screw thru ring into each leg.
-
Page 26: Milestone
Milestone T, TT, X & 4X Bases, Standard, Folding, Flip Top Hardware Included: #12 x 1 Pan Head Screw Tools Required: #3 Phillips Head Screwdriver... - Page 27 Milestone SteP 1: Place the table top upside down on a clean, padded surface SteP 2: Center leg assembly on underside of top and attach using #12 x 1" PH Screws (do not over tighten). Assemble tables only as described in this guide.
-
Page 28: Wct
Steel Leg & Panel End Frame Steel Frame Tables: #8 x 1" screw 1/4-20 x 1-3/4" bolts 1/4 - 20 x 1 3/16" & 1/4 - 20 Nut Panel End Tables: #8 x 1" screw 1/4-20 x 3/4" bolts Corner Tables: 10-32 x 5/8"... - Page 29 WCT Steel Leg SteP 1: attaCHInG FraMeS to taBle toP Assemble end or intermediate steel frames to underside of top using ¼-20 x 1 ¾" bolts. tighten finger tight only at this point. note: InterMedIate FraMeS May MoUnt eItHer at endS or MIdSPan, dePendInG on Con- FIGUratIon.
- Page 30 WCT, Panel End Levelers Modesty Panel Angle Bracket Table Top SteP 1: attaCHInG Panel endS to toP Screw panel ends to table top using (4) ¼-20 x ¾" bolt through each of 2 angle mounting brackets. Finger tight for now. Screw in levelers. SteP 2: attaCHInG ModeSty Panel Screw modesty panel to panel ends using (4) ¼-20 x ¾"...
- Page 31 Corner WCT, Leg Base Frame Assembly SteP 1: attaCH tHe Corner leG/ end leG to taBle toP Fasten WCT Corner Leg to underside of top using ¼-20 x ¾” BH Bolt into threaded insert. Fasten WCT end frame Leg to underside of top using ¼-20 x 1-3/4” BH Bolt into threaded insert. Tighten finger tight only at this point SteP 2: attaCH ModeSty to leG FraMeS Secure Modesty to end frame and corner leg using connector bolt and nut.
-
Page 32: Z Table
Z Table Single and Dual Surface Hardware Included: 10-32 x 5/8" #8 x 2" screws Machine Screws #8 x 1" screws 1/4-20 x 45mm connector bolts Tools Required: #2 Phillips Head Screwdriver 5mm Allen Wrench... - Page 33 Z Table RH and LH Steel Frames attentIon UnItS are aSSeMBled UPSIde down Modesty Panel Top Work Surface Modesty Panel For UnItS 60" and lonGer See SteP 3, Lower Work Surface For SHorter UnItS ProCeed to SteP 4 SteP 1: attaCHInG ModeSty Panel Align modesty panel to pilot holes in underside of longer and narrower top work surface and attach using #8 X 1"...
-
Page 34: Rockford
Rockford Hardware Included: #12 x 1" screw 10-32 x 1/2" Tap TITE BH Screw Tools Required: #2 Phillips Head Screwdriver #3 Phillips Head Screwdriver... - Page 35 Rockford SteP 1: Place the table top upside down on a clean, padded surface. SteP 2: attaCH leG aSSeMBly Align leg plate with locating holes on underside of top. Attach leg assembly to top using #12 x 1" screws. (do not over tighten) SteP 3: adJUSt leG HeIGHt Loosen #10-32 x 1/2"...
-
Page 36: Titan
Titan Hardware Included: #8 x 1" screw Connector Bolt & Nut Connector Nut Tools Required: Allen Wrench Phillips Head Screwdriver... - Page 37 Titan SteP 1: attaCHInG ModeSty Panel to leG FraMeS Loosely attach modesty/wire management panel to end or intermediate steel frames using connector bolt and nut. Flange faces out, wire management trough opening faces in. SteP 2: FRAMe ASSeMBLe tO uSeSR-SIde OF tOp. Assemble to underside of top using 2 1/2"...
-
Page 38: Jack
Jack Hardware Included: 1" Pan Head 1.75" Button Screw Head Screw 2" Pan Head 30 mm bolts Screw 60 mm bolts 70 mm bolts Set Screw Tools Required: (2) 5/16 Wrenches Phillips Head Screwdriver... - Page 39 Jack SteP 1: aSSeMBle BaSe FraMe Assemble end & intermediate steel leg frames together with modesty and spanner pieces. Attach leg frame to modesty using ¼-20 x 30mm Connector Bolt & Nut (finger tight). Modesty flanges overlap on the intermediate leg then bolt together through back side.
-
Page 40: Jill
Jill Hardware Included: #12 x 1" Pan Head Screw Tools Required: #3 Phillips Head Screwdriver... - Page 41 Jill SteP 1: Place the table top upside down on a clean, padded surface SteP 2: Center leg assembly on underside of top and attach using #12 x 1” PH Screws (do not over tighten). Assemble tables only as described in this guide.
-
Page 42: Matrix Modular Workstations
Matrix Modular Workstations Mod-eez studs Mod-eez clips Lip engages groove in Attach kneespace support to back panel before installing underside of worksurface worksurface using Mod-eez fasteners. Fasten support to panel to worksurface with 1" x 1" x 2" "L" bracket using 4 - #8 x 5/8" long Zip-R screw * Worksurfaces 48"... - Page 43 Matrix Modular Workstations SteP 1: attaCHInG end and InterMedIate PanelS to BaCk PanelS Screw Mod-eez stud screws into holes in vertical cen- ter line of double end/intermediate panels or back edge of single end/intermediate panels. NOte: MOde-eez CLIpS ON BACk pANeLS ARe InStalled at tHe FaCtory Slide Mod-eez studs into factory installed Mod-eez clips on either end of back panels.
- Page 44 Assemble tables only as described in this guide. All fasteners must be tightened securely and checked regularly. Failure to CAUTION do so could cause instability and injury. 012513...
