- Page 1 Installation and Assembly Instruction Guide enchmark Library Furniture www.mediatechnologies.com...
-
Page 2: Table Of Contents
Magazine shelving ..........15 Mobile shelving .............16 Wood Tables .............18 Steel Frame Tables SST .................20 Vector, Floating Vector ..........21 WCT, Steel Frame...........22 WCT, Panel End Frame ...........23 WCT, Leg Base Frame Assembly ......24 www.mediatechnologies.com • email: sales@mediatechnologies.com Phone: 231-861-2194 • Fax: 231-861-6678... -
Page 3: Wood Frame Shelving Single Faced
Wood Frame Shelving Single Faced Bookcases - shelving per unit Dimension # of shelves 30" H 1 adjustable 36" H 2 adjustable 42" H 2 adjustable 48" H 2 adjustable 60" H 3 adjustable 72" H 4 adjustable 84" H 5 adjustable 90"... - Page 4 Wood Frame Shelving - Single Faced General Assembly Tools Required: Two 5/16 Wrenches, Phillips Screwdriver Parts Included: Back ⁄ -18 x ¾” ⁄ -18 x 1 ¾” bolts bolts Side/End Panels Shelves #8 x ⁄ ” screw ⁄ nuts Bottom Shelf Cam bolt Toe Bracket...
- Page 5 Wood Frame Shelving - Single Faced STEP 2 - Attaching the backs Slip the back into the grooves in the side panels and bottom frame. The side panels will push outward because the bolts on the bottom frame are not tightened. •...
-
Page 6: Single Faced
Wood Frame Shelving - Single Faced Wood Steel Fixed shelf pin STEP 7 - Installing shelves For wood shelves : Slip round pin of shelf clips into appropriate line holes in side panels and lower shelf into place so pointed portion of shelf clip is inserted into pre-drilled holes on underside of shelf. -
Page 7: Double Faced
Wood Frame Shelving Double Faced Assemble units only as described in this guide. All screws, nuts & bolts and other fasteners must be tightened securely and checked regularly. Failure to do so could cause instability and injury. CAUTION... - Page 8 Wood Frame Shelving - Double Faced General Assembly Parts Included: ⁄ -18 x ¾” ⁄ -18 x 1 ¾” Back bolts bolts Side/End Panels #8 x ⁄ ” screw ⁄ nuts Shelves Cam bolt Toe Bracket Bottom Shelf Middle Front Toes ATTENTION: UNITS ARE ASSEMBLED STANDING UP STEP 1 - Attaching the toes to the sides...
- Page 9 Wood Frame Shelving - Double Faced STEP 2 - Attaching the backs Slip the back into the grooves in the side panels and lower into the groove of the middle toe. • The side panels will push outward because the bolts on the bottom frame are not tightened.
- Page 10 Wood Frame Shelving - Double Faced STEP 6 - Attaching the bottom shelf Slip pin into the holes located near the bottom back side of each side panel (see illustration left). Lower shelf into place so pin fits into groove on underside of shelf. Front of shelf rests on toe. Step 7 –...
- Page 11 Steel Frame Shelving K31 Series Assemble units only as described in this guide. All screws, nuts & bolts and other fasteners must be tightened securely and checked regularly. Failure to do so could cause instability and injury. CAUTION...
- Page 12 Steel Frame Shelving General Assembly: STEP 1 - Attaching side panels to steel frames For Starter Units: Attach the tubular steel frames to an end panel using the shorter (1 ¾") connector bolt and nut • Make sure shelf pin hole lines face in towards shelves •...
- Page 13 Steel Frame Shelving STEP 2 - Attaching the Toes Attach the angle mounting brackets to either end of the rear face of the toes by screwing the #8 x " screws into to the pre-bored holes. Then screw the toe/bracket assembly to the side panels using more of the #8 x "...
- Page 14 Steel Frame Shelving STEP 4 - Installing Fixed Shelves in units 60" and taller - For Units shorter than 60" skip to STEP 5 VARIANTA SCREWS MUST BE Varianta Screw INSTALLED ON TALLER UNITS Shouldered pins must be replaced with varianta screws on mid- height shelves of the bookcases at both ends of a run Note: Units not using the optional tops must also substitute euro screws for the top shelf at the beginning and end of a run.
- Page 15 K31 Series Magazine Shelf Installing magazine display shelf Install standard adjustable shelf as usual and then rest magazine shelf on top of it. Lift rear of shelf to desired tilt angle and slip smooth 5mm shelf pins through the pivot slots in the rear of each side flange.
-
Page 16: Mobile Shelving
K31 Series Mobile Shelving • Mobile K31 Series shelving is assembled in the same manner as standard, non-mobile K31 Series shelving with the exception of the toes. • Individual toes and brackets are replaced by a toe frame, shipped assembled with casters and metal caster support frames. -
Page 17: Wood Tables
Wood Tables Benchmark Library Half Hex Computer Table Personal & 2 - Person Computer Table Occasional Table Assemble units only as described in this guide. All screws, nuts & bolts and other fasteners must be tightened securely and checked regularly. Failure to do so could cause instability and injury. - Page 18 Wood Table Leg, Apron & Support Keel Attaching steel mounting plate and leg to table top Tools Required: 5/16 Wrench Attach leg plates (with attached legs) to table using the 5/16-18 x Phillips screwdriver 1" Phillips pane head cap screws captive lock washers Attaching optional aprons Align apron between the legs on the table.
-
Page 19: Steel Frame Tables
Steel Frame Tables SST Tables Vector Tables WCT Tables Assemble units only as described in this guide. All screws, nuts & bolts and other fasteners must be tightened securely and checked regularly. Failure to do so could cause instability and injury. CAUTION... -
Page 20: Sst
SST Table Tools Required: #12 x 1" screws Phillips screwdriver Tools Required: Allen wrench Welded mounting tabs Apron frame Corner mounting bracket 1/4-20 x 1-1/4” bolts STEP 1 - Attaching legs to apron Attach each leg by bolting through a corner mounting bracket into welded threaded insert in leg with (2) 1/4-20 x 1-1/4"... - Page 21 Vector Table Tools Required: Allen Wrench Table Top ¼-20 x 1” bolts Table Keel (2 on 36” wide tables) ¼-20 x 2½” bolts 90mm bolts Welded Double Leg Frames STEP 1 - Attaching table tops to legs and keel Lay table top upside down on a level clean padded surface. Align leg frames and keel to predrilled holes in underside of worksurface and attach using ¼-20 x 2-½"...
-
Page 22: Wct, Steel Frame
WCT, Steel Frame Parts Included: Tools Required: Allen wrench Phillips head screwdriver 10-32 x 5/8” Modesty Panel screw #8 x 1” screw Intermediate Frame Connector Bolt and Nut Table Top ¼ - 20 x 1 ¾” End Frames bolt STEP 1 - Attaching frames to table top Assemble end or intermediate steel frames to underside of top using 1/4-20 x 1 3/4"... -
Page 23: Wct, Panel End Frame
WCT, Panel End Tools Required: Phillips head screwdriver Allen wrench Levelers Grommets ¼ - 20 x ¾” Modesty Panel bolt #8 x 1” screw Angle Bracket Table Top STEP 1 - Attaching panel ends to top Screw panel ends to table top using (4) ¼-20 x ¾" bolt through each of 2 angle mounting brackets. -
Page 24: Wct, Leg Base Frame Assembly
Step 4: Completing assembly • Finally, tighten BH Bolts attaching end/ corner frames to top. www.mediatechnologies.com • email: sales@mediatechnologies.com Assemble units only as described in this guide. All screws, nuts & bolts and other fasteners must Phone: 231-861-2194 • Fax: 231-861-6678 Revised 040617 be tightened securely and checked regularly.
