Matrix Modular Workstations
Mod-eez studs
2
4
Underside
of worksurface
Z Bracket
#12 x 1" Screws
Assemble tables only as described in this
!
guide. All fasteners must be tightened
securely and checked regularly. Failure to
CAUTION
do so could cause instability and injury.
1
Lip engages groove in
underside of worksurface
Wire Manager
Mod-eez clips
(come installed)
3
4
Angle Brackets
5
Tables
