Overview

•

Overview

The Cisco Nexus 9236C switch (N9K-C9236C) is a 1 rack unit (RU) switch that has the following ports:

• 36 100-Gigabit QSFP28 interface ports that support 100-, 50-, 40-, 25-, 10- and 1-Gigabit speeds. You

• 1 100/1000 management port

• 1 console port

• 2 software-defined ports

• 1 USB port for saving or loading switch configurations

The chassis for this switch includes the following user-replaceable components:

• Fan modules (four) with the following airflow choices:

Overview, on page 1

can use the following adapters with these ports:

• CVR-2QSFP28-8SFP which provides eight SFP/SFP+/SFP28 ports for each vertical pair of ports

on the switch. The top four SFP/SFP+/SFP28 ports connect to the upper QSFP28 port of the switch

pair, and the bottom SFP/SFP+/SFP28 ports connect to the lower QSFP28 port.

• CVR-QSFP-SFP10G which provides an SFP/SFP+ port for one QSFP/QSFP28 port on the switch.

Note

These ports also support breakout cables with four 10-Gigabit SFP+ transceivers

(such as the QSFP-4X10G-AOCxM and QSFP-4SFP10G-CUxM cables).

• Port-side intake fan module with burgundy coloring (NXA-FAN-30CFM-B)

• Port-side exhaust fan module with blue coloring (NXA-FAN-30CFM-F)

Overview

Need help?

Do you have a question about the Nexus 9236C and is the answer not in the manual?

Page 1 Overview, on page 1 Overview The Cisco Nexus 9236C switch (N9K-C9236C) is a 1 rack unit (RU) switch that has the following ports: • 36 100-Gigabit QSFP28 interface ports that support 100-, 50-, 40-, 25-, 10- and 1-Gigabit speeds. You can use the following adapters with these ports: •...
Page 2 Overview Overview Note Table 1: Fan Speeds for this Switch Port-Side Intake Port-Side Exhaust Fan Speed % Fan Speed % Typical/Minimum 100% Maximum 100% 100% • Power supply modules (two—one for operations and one for redundancy [n+1]) with the following choices: •...
Page 3 Lane shift button Grounding pad To determine which transceivers, adapters, and cables are supported by this switch, see the Cisco Transceiver Modules Compatibility Information document. The following figure shows the switch features on the power supply side of the chassis.
Page 4 Overview Overview AC power supply modules have burgundy coloring (DC power supply modules have green coloring). For port-side exhaust airflow, the fan and AC power supplies have blue coloring (DC power supply modules have gray coloring). You can also order the 1200-W HVAC/HVDC power supply which has dual-direction airflow with white coloring.
