  • Page 1 Wireless Dimming | Wireless DMX | Wireless Motion Since 1991 W i r e l e s s LumenDimM4 Quick Start Guide Rev. 1.0...
  • Page 2 RC4 LumenDimM4 1. DMX Data Indicator 2. Function and COP* Indicator 3. Function Button 4. SetA - SetD Buttons 5. DimA - DimD Indicators 6. RF Connect Indicator for Transmitter Linking 7. RF Connect (Link) Button 8. Screwdriver Access for Connection Terminals 9.

  • Page 3: Registering Your Product

    LumenDimM4 users will find all the information they need right here. • A DMX lighting console. Your LumenDimM4 also has a wide variety of expanded features for advanced • A LumenRadio CRMX-compatible wireless transmitter like the users. You can find out more about all of them in the RC4 Knowledge Base at RC4 LumenDimIO or the LumenRadio TX1.

  • Page 4: Performing A Factory Reset

    Press and hold Func, briefly tap (press and release) the SetA button, then release Func. The first four When the RF Connect LED is off, the LumenDimM4 is ready to be linked to your indicators will blink to confirm that factory settings transmitter.

  • Page 5: Setting The Dmx Address

    Assigning DMX channels and dimmer curves is easy using RC4 OneTouch™: On your DMX lighting console, bring up one dimmer (DMX output channel) that will be your LumenDimM4 starting address. For example, if you want your first LumenDimM4 dimmer on DMX channel 60 with a curve that is optimized for LEDs, bring up 60 @ 30% at the console.
  • Page 6 61, DimC is on 62, and so on. Connect * The LumenDimM4 can control a variety of devices including solenoids, relays, servo motors, and much more. Non-Sequential Channel Assignment Dimmers don’t have to be sequential.
  • Page 7 Choosing Other Dimmer Curves or Profiles Dimming and Controlling Multicolor LEDs The LumenDimM4 default is the ISL dimmer curve, which is best for LEDs. This The illustration on the previous page shows an RGB color mixing LED device. There are 4 wires: a black wire for the 12V common positive (+), and three is also the curve that is selected with RC4 OneTouch™...

  • Page 8: Advanced Features

    Caring for Your LumenDimM4 The LumenDimM4 is a multifaceted device for users of all experience levels. • The LumenDimM4 should not be used with AC power or with any voltage The features below can be explored further at http://rc4.info/ or by asking us higher than 35VDC.
  • Page 9 North Carolina, USA, Local +44 (0)20 3289 8765 London, UK 1-866-237-6641 Toll Free Fax, North America Email: support@theatrewireless.com Website: www.rc4wireless.com Knowledge Base: http://rc4.info We’re here to help you at any time. James David Smith President and Chief Product Designer RC4 Wireless...
