Anti-tip Strap INSTALLATION INSTRUCTION
Please read this instruction carefully before installation .
If you have any questions, please feel free to contact us:
USA E-mail: customerservice@mountingdream.com
Phone call: (626) 604-9048 (USA) Mon - Fri 10am - 6pm (Pacific Time)
EU
E-mail: customercare@mountingdream.com
(A0)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Mounting Dream Anti-tip Strap
Summary of Contents for Mounting Dream Anti-tip Strap
- Page 1 Anti-tip Strap INSTALLATION INSTRUCTION Please read this instruction carefully before installation . If you have any questions, please feel free to contact us: USA E-mail: customerservice@mountingdream.com Phone call: (626) 604-9048 (USA) Mon - Fri 10am - 6pm (Pacific Time) E-mail: customercare@mountingdream.com...
- Page 2 NOTE: Not all hardware included will be used. Installation Tools: 2M 2M Band Tape Bubble Level Screwdriver Part List: Anti-tip Strap 1pc Installation Hardware: For concrete installations ONLY CAUTION: Do not use in drywall or wood stud. - Lag Bolt 1pc - Concrete Anchor 1pc...
- Page 3 Attach one end of the anti-tip strap to table top TV stand by using bolt with Allen key (Bolt and Allen key are both included in the hardware package of MD5109). (Figure 1) Figure 1...
- Page 4 Step 2A Strap attaches to the table See Page 3 Step 2B Strap attaches to the wall See Page 5 Attach the other end of strap to the wooden table by using bolts with screwdriver. (Figure 2) Figure 2...
- Page 5 Adjust the length of strap,make sure it is tightened firmly and safe enough. (Figure 3) Figure 3...
-
Page 6: Option 1 ： Wood Stud Installation
Option 1 ： Wood Stud Installation Use a stud finder to make marks at the edges of one stud, and mark centerline of stud. Then place iron plate along the centerline and use pencil to mark center hole location on the wall. Use 1/16"... - Page 7 Option 2 ： Solid Conrete Wall Installation Use 1/4"(6.4mm) diameter drill bit to drill a hole at marked position to a depth of 1.4". Put anchor into drilled hole, and tap the anchor flush with the wall by using a hammer. Then put lag bolt into the anchor, and tighten bolt by using a screwdriver to mount the wall plate securely.
- Page 8 Adjust the length of strap,make sure it tight and safe. (Figure 6) Figure 6...
