Weight Limit: 600 Lb / 272 Kg
V.K. - 2019/4/12
2014 Dorel Home Products All Rights Reserved
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
FF5000BLKS
Metal Arm Futon
Black
Lot Number
B34FF5000BLKS00
1
Advertisement
Table of Contents
Related Manuals for Dorel Home Products FF5000BLKS
Summary of Contents for Dorel Home Products FF5000BLKS
- Page 1 Visit www.dhpfurniture.com/eng/replacement-parts or call Toll-Free 1-800-267-1739 Date of Purchase Lot Number THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. V.K. - 2019/4/12 B34FF5000BLKS00 2014 Dorel Home Products All Rights Reserved...
- Page 2 Warranty Information Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship and Call our toll free number if you need assistance. agrees to remedy any such defect. This warranty covers one year from the date of Work in a spacious area and near where the unit will be used, preferably on a original purchase.
- Page 3 Parts Replacement Parts, visit www.dhpfurniture.com/eng/replacement-parts All in 1 big box! There are inner box(es) that include components required to complete this assembly. Before you throw the package, please use the Mesh Panel Check Box to identify the parts and ensure that T621680 T621690 T621700...
- Page 4 Parts Replacement Parts, visit www.dhpfurniture.com/eng/replacement-parts All in 1 big box! There are inner box(es) that include components required to complete this assembly. Before you throw the package, please use the Retainer Middle Leg Hook End Cap Check Box to identify the parts and ensure that T613540 T621770 T612410...
- Page 5 Hardware Pack Hardware Pack #: TFF5000BLKS-00 3/16" X 3/4" 1/4" X 3/4" 1/4" X 1 1/16" 1/4" X 1 5/16" 1/4" X 1 3/8" 5/16" X 2 7/16" 1/4" #8 X 9/16" 5/16" X 18 X 20 3/16" Please do not completely tighten all the hardware, Wrench until the entire assembly is complete, unless otherwise indicated in the step-by-step...
- Page 6 Step 1 You need an extra hand and a mallet to Insert V1 x 4 into A/B. help with the assembly. A hardboard should be used to prevent V1 from being damaged. Make sure that the tube end of A/B firmly touches with the shoulder of V1.
- Page 7 Step 2 Attach L to A and R to B with Do not reverse the Mechanisms L and R. The top of Mechanisms L & R may look different due to the movable joints. Please determine the orientation based on their bottom sides. Hint: Hold Nut using wrench key and then tighten Bolt...
- Page 8 Step 3 Attach G x 2 to H x 1 with Repeat the same procedure for another G x 2 and H.
- Page 9 Step 4 Attach D x 2 to H x 2 with...
- Page 10 Step 5 Attach G x 4 to A/B with...
- Page 11 Step 6 6.1 Insert E x 2 into O and fasten with 6.2 Insert P onto E x 2 and fasten with Repeat the same procedure for remaining parts E, O and P.
- Page 12 Step 7 Before assembling, place O & P with the wire mesh towards floor. Attach Q to O and P with The Screw head should be facing upward in this step. SEAT FRAME...
- Page 13 Step 8 Before assembling, place O & P with the wire mesh towards floor. 8.1 Attach Q to O and P with 8.2 Attach Q to O and P with The Screw head should be facing upward in this step. and # BACK FRAME...
- Page 14 Step 9 Attach the SEAT FRAME assembled from the step 7 and BACK FRAME assembled from step 8 to L and R with BACK FRAME Orientation for brace Q should be underneath mesh panel. SEAT FRAME...
- Page 15 Step 10 10.1 Attach x 4 to H x 2 at locations 10.1 indicated. 10.2 Attach x 4 to G x 4 at locations indicated. 10.2...
- Page 16 Step 11 Lift the Back Frame to the second position. Second position First position...
- Page 17 Step 12 Attach T x 3 to O x 2 and P x 2...
- Page 18 Step 13 Attach S x 2 to O and P with...
- Page 19 Step 14 14.1 Lay the cover flat and open the two zippers located on each side of the cover. 14.2 Put the Pads into each compartment in the cover and close the zippers. 14.3 Place the sub-assembly Pad/Cover on the frame you just assembled. 14.1 14.2 14.3...
- Page 20 FOR SEATING POSITION HOW TO USE YOUR FUTON Two different positions: Seating Position 1st: Slowly lift the backrest until hearing first Click . 2nd: Push the backrest forward from 1st seating position until hearing a second Click. 1st Click 2nd Click Sleeping Position FOR BED POSITION Bed Position: From the first or second...
- Page 21 Helpful Hints Weight Limit: 600 Lb / 272 Kg Your Mattress has been compressed in an effort to help the environment by reducing packaging and minimizing waste. For optimal results, remove mattress from packing and lasy mattress flat for 24 hours.
- Page 22 FF5000BLKS NO LO REGRESE A LA TIENDA ! Si le faltan piezas o las que se incluyen est n da adas, con Metal Arm Futon mucho gusto le enviaremos sus piezas de reemplazo sin cargo extra. Negro Visite www.dhpfurniture.com/spa/replacement-parts o llame gratis al 1-800-267-1739...
- Page 23 Partes Instrucciones Paso 1 Piezas de reemplazo, visite www.dhpfurniture.com/spa/replacement-parts Insertar V1 x 4 dentro de A/B. Paso 2 Todo se incluye en 1 caja grande! Una L con A con R con B con La parte superior de los mecanismos puede parecer diferente debido a sus Hay 1 caja(s) interna(s) que incluyen los componentes necesarios para partes movible.
- Page 24 Instrucciones L mites de peso: 600 Lb / 272 Kg PARA EVITAR EL VOLTEO DEL SOF , NO SE SIENTE, ACUESTE O Paso 12 PARE EN LOS BORDES DE LA UNIDAD CUANDO EL SOF SE Una T x 3 con O x 2 , P x 2. ENCUENTRA EN POSICI N DE CAMA.
- Page 25 FF5000BLKS NE RETOURNEZ PAS AU MAGASIN ! Si une pi ce est manquante ou endommag e, nous vous Metal Arm Futon exp dierons avec plaisir vos pi ces de remplacement gratuitement. Noir Visitez www.dhpfurniture.com/fre/replacement-parts ou appelez au 1-800-267-1739 Date d'achat Numero de lot CE FEUILLET CONTIENT DES INFORMATIONS DE S CURIT IMPORTANTES.
- Page 26 Pi ces Instructions tape 1 Pi ces de rechange, visitez www.dhpfurniture/fre/replacement-parts Ins rer V x 4 dans A/B. tape 2 Tout dans 1 grosse bo te! Attacher L B avec La partie sup rieure des m canismes peut sembler diff rente en raison de Il y a des bo tes int rieures qui contiennent les composants pour completer leurs parties mobiles.
- Page 27 Instructions Limite de Poids: 600 Lb / 272 Kg POUR VITER LE BASCULEMENT, NE PAS S'ASSEOIR, SE TENIR OU tape12 S'ALLONGER SUR LE BORD DU FUTON, QUAND LE FUTON EST EN Attacher T x 3 O x 2, P x 2. POSITION DE LIT.
