16
Feature
Typical sensitivity level
(EU868/US915)
3.4

GPS Antenna Performance

3.5

LoRa Antenna Performance

3.6

Operational frequencies

MatchX Gateways are tested to work with regional frequency specifications regulated by the au-
thorities responsible for given region. The user needs to pay attention to the local regulation and
Description
-141 dBm at SF12 BW 125 kHz
-127 dBm at SF7 BW 125 kHz
-111 dBm at FSK 50 kbps
Table 3.3: LoRa Radio specification.
Feature Description
Frequency range 1574 - 1606MHz
Impedance 50ohms
VSWR <1.2:1
Max gain 2.5dbi
Polarization Vertical
Radiation Pattern Omni-directional
Connector SMA(M)
Length 108mm
IP Rating IP66
Table 3.4: GPS Antenna performance
Feature Description
Frequency range 863-873MHz
Or 902-928MHz
Impedance 50ohms
VSWR <1.2:1
Max gain 2.5dbi
Polarization Vertical
Radiation Pattern Omni-directional
Connector SMA(M)
Length 108mm
IP Rating IP66
Table 3.5: Lora Antenna performance
Chapter 3. Product specification
