Gesytec Easylon Mounting Instructions

W
ARNING
• Installation should only performed by qualified and
technical experienced personnel. The device must be
installed in compliance with the relevant DIN/VDE
regulations or the relevant national standards.
• The connection to the supply voltage must be per-
formed in accordance with VDE 0100 and VDE
0160.
• Trouble-free and safe operation of the unit is de-
pendent on proper transport and storage.
I
NSTALLATION
• The Easylon Repeater can be snapped onto DIN rails
(DIN EN 50022-35).
• The Easylon Repeater is only protected by a simple
non-shielded plastic housing. It should not be placed
close to strongly influencing devices.
• Ensure that all wires to be connected are powerless!
• Connect the bus wires to the corresponding LONA+,
LONA-, LONB+ and LONB- connectors.
• The Easylon Repeater does not include a bus termi-
nation. For trouble free operation of the Easylon Re-
peater both segments of the L
must be properly terminated.
• Connect the 24 VAC or 24 VDC power supply. The
Easylon Repeater has a simple filter at the power
input. Therefore it should not be supplied from a
strongly disturbed source.
• Never connect ground to the bus shield and to the
supply voltage (e.g. 0 VDC)
P D
RODUCT
The Easylon Repeater is a signal amplifier in the
L W network. It increases the maximum bus
ON ORKS
length and increases the permissible number of net-
work nodes. It is completely transparent to the net-
work.
Mounting Instructions
Easylon
(Order Code: P.R 10003)
N
OTES
W network
ON ORKS
ESCRIPTION
®
Repeater
T
ECHNICAL
Power Supply
Power consumption
Temperature
Operating 0 - +60 °C
Storage -20 - +85 °C
Relative humidity
Protection class
EMV
Emission EN55022 A/B,
Immunity EN50022-2
Housing
Dimensions 96*45*38 [mm]
Mounting DIN rail
Connectors
S
PECIFICATIONS
DC 12-28 V DC
AC 24 V AC +/-20%
< 1VA
at free convection
Class F (DIN 40 040)
IP 00
EN 55011 A/B,
EN50081-1/2
(EN50022-35*7,5) or
(EN50022-35*15)
Screw-clamp
0.5-2.5 mm²
