STOBAG TARGA/TARGA PLUS
MOTORIZED CONSERVATIVE AWNING SYSTEM

FRONT BAR

END CAP

BOX SIDE COVER

PS625 L
PS619/2

BOX END CAP

PS605/2
RS13/7

ROLLER TUBE

PS627
MOTOR PROTECTION
GUARD
PS603
BOX
TARGA PLUS
PS613/2

GUIDE SUPPORT

PS602/1

FRONT PROFILE

GUIDE

PS616/1

GUIDE RUNNER

PS613/1
PS608 ø70
PS607
PS508 ø45
FRONT BAR
GUIDING ROLLER
PROFILE
PS625 R
FRONT BAR
END CAP
P244/1
BEARING OPPOSITE SIDE
RS14/7
PS605/3
ROLLER GUDGEON
BOX END CAP
PS619/1
BOX SIDE COVER
PS601/1
MOUNTING
BRACKET
PS618/1
GUIDE CAP
PS609/..

GUIDE RAIL

PS601/1
MOUNTING
BRACKET
PS602/1
GUIDE SUPPORT
PS650
ø70
FABRIC SUPPORT
BRACKET
PS650/1 ø45
PS650/1 L
RS14/.
FABRIC
ROLLER
SUPPORT
GUDGEON
PS628
BRACKET
PS630
BOX ROLLER
TUBE SUPPORT
P345
HINGED
BEARING SET
TARGA
P345
HINGED
BEARING SET
PS508 ø45
GUIDING
ROLLER
PROFILE
PS613/1
GUIDE RUNNER
PS650/4
FABRIC SUPPORT
BRACKET
RS13/.
ROLLER TUBE
PS508 ø45
GUIDING ROLLER
PROFILE
PS609/../M
GUIDE RAIL
PS650/1 R
FABRIC SUPPORT
BRACKET
