Forest garden Burford Extended Pavilion Assembly Instructions

RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
ATTENTION :
Assembly of this
Pavilion requires a
minimum of three
MUST PRE DRILL
adults.
REQUIRED TOOLS : (NOT SUPPLIED)
DRILL
POZI DRIVE SCREWDRIVER
SPIRIT LEVEL
TAPE MEASURE
HAMMER
BEPV2PP
plain panel Qty 3
HBGV2RAF rafter Qty 8
BEPV2RHPOST right hand post Qty 2
BEPV2LHPOST left hand post Qty 2
TRADSUMV2UP post Qty 4
BEPV2PLUG floor plug Qty 1
SHARCH
BEPV2APR apex rafter Qty 1
Forest Garden Ltd, Unit 288 Hartlebury Trading Estate, Worcestershire DY10 4JB
B
urford
Thank you for choosing this garden building manufactured by the UK's largest manufacturer of timber garden products. In order to gain the
most benefit from it, please note the following:
- This building is pressure treated to ensure the longevity of all timber components and protect against rot. This may leave a colour difference
on some parts that will even out as the moisture contents stabilize.
- In line with your statutory rights, please check all parts prior to assembly, as assembly of damaged parts may be deemed to be acceptance
and this may affect the remedies you are entitled to. If the product is not constructed in accordance with the instructions, or is altered in anyway
(e.g. painted), the manufacturer cannot be held liable for any resulting damage.
- Timber is a natural material. It will shrink and swell as a result of varying moisture content.
- Please keep all plastic bags and small parts away from children in order to reduce the risk of suffocation.
- This product must be built on a solid level base.
- Important Note : Do not lean or stand on roof during assembly. The roof is not load bearing.
- If there are any technical queries with the product, please contact our customer help line on 0333 7777 089 between the hours of 8.30 am and
5.00 pm Monday to Friday.
Maintenance:
- Regularly check all fixings are tight and secure. - Regularly check structural components for damage.
BGMV2LAT BGMV2BAL
lattice panel Qty 2 baluster panel Qty 2
BEPV2FP
fixing pack Qty 1
(Contents on last sheet)
arch Qty 3
TRADSUMV2LEG
bench leg Qty 20
E P
xtended avilion

Parts List

BEPV2SQFL BEPV2FL
floor section Qty 2 floor panel Qty 6
TRADSUMV2SLAT830
seat slat 830mm Qty 4
TRADSUMV2SLAT955
seat slat 955mm Qty 4
TRADSUMV2SLAT1080
seat slat 1080mm Qty 4
TRADSUMV2BBRA
bench brace Qty 3
This article contains biocidal products to
give protection against wood destroying
insects & wood rotting fungi. Contents may
vary.
May contain : Basic copper carbonate
(Copper (II) carbonate – Copper (II)
hydroxide (1:1), Cupric oxide, Copper
hydroxide carbonate, oxyethyl,
ammoniumpropionate, Copper HDO,
Propiconazole, Tebuconazole, Boric acid,
Benzalkonium chloride.
Wear gloves when handling freshly treated
wood. Avoid breathing dust when cutting
treated or untreated wood. Dispose of off-
cuts responsibly – do not burn.
BEPV2SQRF
HBGV2RF
roof panel Qty 2
roof panel Qty 6
TRADSUMV2FB
TRADSUMV2BB
front brace 735mm Qty 4
back brace 1080mm Qty 4
BEPV2SB
side brace 325mm Qty 4
100191182A2GTRI
loose roof board
Qty 6 (stapled to

roof assembly)

BEPV2BB
board 102 x 1130 Qty 5
Issue 0214
BEPV2FIN
finial Qty 2
TRADSUMV2SB
side brace 330mm Qty 16
BEPV2BBRA
bench brace Qty 1
100191100GTRIPTR
loose roof board
Qty 2 (stapled to
roof assembly)
