GPS Series Master Development System
Quick Start Reference
Remove Contents
1
Remove kit contents including the development board,
antenna, batteries, modules and USB cable.
Turn on Power
3
Slide the Power Switch to the BAT side
to turn on the board.
Set Up the Development Board
2
Install the four AAA batteries and the coin cell battery on the back of the board.
Screw the antenna to the connector on the front of the board.
Turn On the OLED Display
4
Slide the Display Power Switch to the
ON position to activate the display. The
GPS data is shown on the display once
the module gets a position fix.
Install the Software
5
Install the Windows software from
the CD that is included with the kit. If
already installed, skip this step.
Revised 1/27/2017
