HumPRO
Series Master Development System
TM
Quick Start Reference
Remove Contents
1
Remove kit contents including development boards,
antennas, batteries, modules and USB cables.
Install the Software
3
Install the Windows software from the
CD that is included with the kit. If already
installed, skip this step.
Set Up the Programming Docks
2
MDEV-fff-PRO
With the power off, set up boards by inserting EVMs into
sockets on the Programming Docks and attaching the
antennas.
Connect the Programming Docks
4
Connect the Programming Docks to a
computer with the cables included with
the kit. USB drivers are on the CD so
install them if prompted by the computer.
MDEV-A-fff-PRO
Connect the antenna
to the Carrier Board
Start the Software
5
Start the software. It automatically
detects conected modules and reads
their configurations.
Revised 7/27/2017
