KINGTA TECHNOLOGY EXTREME T2 User Manual

Advertisement

Quick Links

Bluetooth speaker
User's Manual
T2, BDY-9087, EXTREME
KINGTA TECHNOLOGY CO.,LTD

Introduction:

you can use this item with tablet,notebook and many types of

Troubleshooting

Smart phone to stream music,and enjoy hands free calling.In order to get
the best results when using the device,please read this manual first before
using.
Feartures
-Volume and song control directly on speaker unit
-Stunning sound clarity
-Ultra portable design
-Great for parties, indoor and outdoor
-Allow you to make and answer phone calls
-TF card can use

Specifications

Loudspeaker: 4Ω 3W*2
Built-in Power:3.7V/2000mA
Dimensions: L166*W62*H68.2MM
SNR:≥80DB
Wireless Working Frequency: 2.402-2.480GHZ
Wireless Transmission Distance: up to 32 ft
Charging Time: 3-4 hours
Weight: 350.3g
Speaker Dimension:40mm
Charging: DC5V±0.5/500MA

Package Contents

USB Charging cable
Audi o Cable
1. Bluetooth
Speaker
2.

Important Safety Precautions

When using your Bluetooth Mobile Speaker, basic safety precautions
should always be followed, including the following:
User's Manual
1. Keep this product and its charging cable away from excessive heat.
2. Do not operate this device with a damaged cable or after it has
malfunctioned or has been damaged in any manner.
3. Do not disassemble your device.

Charging Your Speaker

1. Connect one end of the included USB Charging Cable to the
Charging Port on your speaker. Then plug the other end of the USB
Charging Cable into a suitable USB port on your computer to recharge
your speaker's internal rechargeable battery.
NOTE: The internal battery of your speaker takes approximately four hours
to charge when completely drained.
2. When charging, a red LED light will illuminate to indicate that the unit is
charging. The red light will turn off when your unit is fully charged.

A Quick Look at Your Device

T2
4

Understanding the LED Status Lights

When Charging Your Speaker
Solid red LED = Charging
No red LED = Charge Complete
When Pairing Your Speaker to a Bluetooth Audio Source
Rapid blinking blue LED: Bluetooth not connected. (Ready to pair.)
Solid blue LED: Bluetooth connected.l
3. Bike Buddy
1. Previous
:
Press to access the last track in
playlist.Press and hold to lower the volume
5
2. Phone
:
Press this button to activate the
2
the speaker phone function. When music is
1
playing, press to play or pause a track.
3
3. Next
:
press to access the next track in a
a playlist.Long press and hold to increase the volume.
4. Charging Port
You can plug one end of the included USB Charging
Cable into this jack, while plugging the other end into
a USB port on your computer in order to charge your
speaker's built in lithium battery.
5. ON/OFF Switch
Press and hold the"
"to power on
Press and hold the"
"again to power off

Pairing Bluetooth Devices to Your Speaker

In order to pair your Bluetooth audio device to your Bluetooth Speaker for
the first time, follow the steps below:
1). Make sure your Bluetooth audio source is held within three meters of
your speaker.
2). Press and hold the "
" switch on your speaker to power on
The LED light will blink blue to indicate that you have entered pairing
status.
3). Go to the Bluetooth Manager of your Bluetooth audio source. Please
refer to the User's Manual of your Bluetooth audio source for more
information.
4). Search Bluetooth devices and select "T2".
5). Once paired, the blue LED light will be solid and you can use your
speaker to listen to audio from you Bluetooth sound source.

Using the Hands-Free Function

When an iPhone or other smartphone is connected to your speaker follow
the steps below to take calls hands-free.
1. Press"
"to pick up the call.
2. Press and hold"
"for 2 sec to reject the call.
3. During a call: Press"
"again to hang up the call.
Troubleshooting
Problem
Solution
The speaker doesn't connect
Speaker needs to be connected/paired again
to device
to device
Speaker needs to be charged
A tone is heard every few
seconds
Avoid operating the Bluetooth speaker in areas
Bluetooth connection distance
of strong electromagnetic interference,such as
cannot reach to 32ft.
near indution cookers,large power fans,motors
etc.
Move the speaker closer to Bluetooth
device.Fully charge the speaker and try again.
The speaker will not power on
Speaker needs to be charged
The speaker doesn't control
Speaker needs to be in Bluetooth mode for
track(s)/volume
full control
The speaker sound is distorted
The devices' volume needs to be lowered
at high volume
